SLIM ZERO
OWNER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for BEMIS bioBidet SLIM ZERO

Summary of Contents for BEMIS bioBidet SLIM ZERO

  • Page 1 SLIM ZERO OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRODUCT INFORMATION Main Unit & Parts............4 Product Diagram............5 PRODUCT INSTALLATION Pre-Installaton..............6 Installation..............8 Water Connection............12 Operation..............16 Night Light Instructions.........17 PRODUCT MAINTENENCE Cleaning & Maintenence........20 Troubleshooting............22 Specifications............24 WARRANTY Warranty..............26...

  • Page 3: Main Unit & Parts

    MAIN UNIT & PARTS PRODUCT DIAGRAM Method 1 Method 2 NOTE: There are two methods for installation. The recommended way is using the rubber expansive nuts. The second option is using the butterfly nuts. Please select the option best suited for your suited for your specific installation needs.

  • Page 4: Pre-Installaton

    PRE-INSTALLATION Please make sure you read the instructions carefully and install it properly. 3. Example of how the bolts fit through the mounting brackets and how they are placed onto the catch plate and secured to Caution the toilet. 1. The water pressure limit is from 10 to 110 PSI. Please use as instructed. 2.

  • Page 5: Installation

    INSTALLATION First Installation Method (Recommended) 3. Attach the catch plate. 4. Install the bidet seat. • • Attach the catch plate in the Line up the bidet with the 1. Completely remove the 2. Install expansion nuts. toilet seat holes. Adjust the catch plate then push the bidet old toilet seat and lid.
  • Page 6 INSTALLATION (CONT.) Second Installation Method 1. Remove the old 2. Attach the catch plate. 3. Install the bidet seat, line toilet seat. up the bidet with the • Put the catch plate over catch plate, you will hear the toilet seat mounting the seat click into place.

  • Page 7: Water Connection

    WATER CONNECTION 1. Close the water supply 2. Unscrew the water 3. Attach the T-valve to the 4. Re-attach the water valve. Flush the toilet. supply hose from the water tank where you supply hose to the water tank. Place a towel removed the water supply bottom of the T-valve.
  • Page 8 WATER CONNECTION (CONT.) 5. Connect the bidet 6. Slowly open the water 7. Wipe the hoses and connectors thoroughly with a towel and supply hose. valve to check if there is carefully observe for any leaks for at least 10 minutes. any leakage.

  • Page 9: Operation

    OPERATION NIGHT LIGHT INSTRUCTIONS 1. Installing the battery Stop • Return the lever to the upright • • position to turn it off. Remove the batter pack. Insert 4AA batteries, and put the battery pack in the control box. Replace the cover firmly. Bidet (Front Feminine Wash) •...
  • Page 10 NIGHT LIGHT INSTRUCTIONS (CONT.) 2. Instructions 3. Replacing the battery. Operation • • Install the bidet onto the toilet. When the light turns red please • Press the button once, the high light is on. replace the battery. • Press again, the low light is on. •...
  • Page 11 CLEANING & MAINTENANCE 1. Cleaning the exterior of 2. Cleaning the 3. Clean the filter 4. Remove the main body. the bidet seat. spray nozzles. and regulator. • • • • Using a sponge/cloth with Pull out the nozzle softly Turn off the water supply, Close the cover.

  • Page 12: Troubleshooting

    TROUBLESHOOTING If any failure still occurs after above troubleshooting, please Status Cause Solution contact support@biobidet.com Water is too Low water pressure of During use, turn the lever low during the unit. forward or backward to WASH/BIDET highest setting Do not disassemble, repair, or remodel the unit, as this will void the warranty.

  • Page 13: Specifications

    SPECIFICATIONS Classifications Description Model Number Slim Zero WASH water flow 0.35-1.8 L/min Feminine water flow 0.35-1.8 L/min Backflow Prevention Check valve Water Supply Direct from water pipes Water Pressure Range 10-110 PSI Dimensions 19.68” (l) x 14.30” (w) x 2.25” (h) Weight 4.85 lbs...

  • Page 14: Warranty

    WARRANTY Your Bio Bidet Slim Zero is warranted against defects in materials or No implied warranty, included any implied warranty of merchantability or workmanship for one (1) year from the date of original purchase. Defective fitness or a particular purpose, applies to Bio Bidet after the applicable period parts or a defective product returned to Bio Bidet will be repaired with new or of the express limited warranty stated above, and no other express warranty comparable rebuilt parts by Bio Bidet at their sole discretion.
  • Page 15 Thank You Technical Support/Customer Service 7900 S Route 31 Crystal Lake, IL 60014 T: 847.458.2334 U.S. TOLL FREE: 877.339.5214 support@biobidet.com www.biobidet.com...
