Page 2: Product Information
PRODUCT INFORMATION Important Safeguards Overview & Parts Wireless Remote GETTING STARTED Registration and Functions & Features Installation Resources INSTALLATION Installation Guide MAINTENANCE Questions? Cleaning Tips We’re here to help. Replacing The Deodorizer Removing The BB-1000 847.458.2334 Draining The Warm Water Tank support@biobidet.com Troubleshooting Guide www.biobidet.com... - Page 3 PLEASE OBSERVE THE FOLLOWING PRECAUTIONS AND INSTRUCTIONS BEFORE INSTALLATION AND USE. • This product must be connected to a grounded 120V GFCI (Ground Fault Circuit Interrupt) outlet. Do not connect the power cord if it is damaged or broken. Do not plug the product into a loose electric outlet. •...
- Page 4 BB-1000 BB-1000 Parts List T-Valve (2) Nuts 1/2 Conversion Nut Deodorizer Operation LED Window *Rubber washer inside *Rubber washer inside *installed in unit Side Control Panel Warm Air Dryer (2) Cone (2) Bolt (2) Mounting Catch Packings Guides Bolts Plate Deodorizer Drain/Quick Release Nozzle...
-
Page 5: Functions And Features
Functions & Features Sit Down On The Seat This product includes a built-in seat sensor that must be activated with skin contact in order to operate bidet functions. When you sit down on the seat and activate the seat sensor, the corresponding LED will light up on the main unit and the deodorizer fan will start. - Page 6 Adjustable Water Pressure Nozzle Oscillation MOVE Press “High” or “Low” (+, -) to adjust the pressure of the Press "Move" during a wash cycle to move the nozzle back and forth for water spray to your desired comfort level. a wider cleaning experience. Change the nozzle position by pressing the “Front”...
- Page 7 3. Install Catch Plate BEFORE INSTALLATION Place the catch plate and guides over each mounting hole. Insert the mounting bolts through the guides, catch plate, and mounting holes. Slide the cone packing Do not plug the power cord in until installation is complete. and washers onto the bolts and fasten to secure the bidet.
- Page 8 5. Connect the Water Hoses Install the t-valve onto the toilet tank. Ensure the rubber gasket is properly seated inside the t-valve. Toilet Tank Connect the provided toilet hose to the water shut-off valve and t-valve. You may also use your existing toilet hose. Connect the bidet hose to the bidet seat and t-valve.
-
Page 9: Cleaning The Nozzle
Cleaning the Nozzle Replacing the Deodorizer Hold the “Posterior Wash” button for 3 seconds without occupying the seat to extend the nozzle for manual cleaning. It can be cleaned using a toothbrush or Cover soft cloth. After cleaning the nozzle, push the “Stop” button once again and the nozzle will retract. -
Page 10: Water Filter Maintenance
Draining the Warm Water Tank Removing the BB-1000 *Close shut-off valve Disconnect the power plug. Close water supply shut-off valve. Drain the water from the bidet by holding the drain button as shown above. Remove the bidet seat from toilet as illustrated. If you do not intend to use this product for 14 days or longer, drain the water from this product’s warm water tank. -
Page 11: Specifications
Trouble Cause Solution Specifications BB-1000 Water does not Power Rating • • The water tank Wait about one minute. 120Vac, 60Hz, 660W spray is not filled. Press the desired washing button once again. • The shut-off valve Water Inlet Pressure 0.04 ~ 0.74MPa (0.4 ~ 7.5 kgf/cm) •... - Page 12 This warranty does not apply to the following items: • Damage or loss sustained in a natural calamity such as fire, WARRANTY SUMMARY earthquake, flood, thunder electrical storm, etc. • Damage or loss resulting from any unreasonable use, misuse, abuse, negligence, or improper maintenance of the product. 3 Year Limited Warranty •...
- Page 13 Customer Support 7900 S Route 31 Crystal Lake, IL 60014 T: 847.458.2334 U.S. TOLL FREE: 877.339.5214 support@biobidet.com www.biobidet.com...
Need help?
Do you have a question about the bioBidet BB-1000 SUPREME and is the answer not in the manual?
Questions and answers
The remote doesn’t work Brand new installation, brand new batteries, the damn thing won’t shut off, and the water is cold.
The remote may not work right after installation because the seat occupied sensor is not activated. To test functions, you need to move your hand over the sensor to simulate someone sitting. Once the sensor is triggered, the remote functions will respond.
