User Guide &
General Maintenance
Rainier Summit R1/R2
OUR MISSION
To improve health and wellness by actively restoring indoor air to its pure, natural state where no pollution or
contaminants exist, while reducing energy use and emissions in the process.
PRODUCT SUBMITTAL
Rainier Summit R1
APPLICATION
The AtmosAir Rainier Summit is a standalone self
contained compact unit designed to increase ionization
levels to restore indoor air to its natural state where no
pollution or contaminants exist. The Rainier's patented
active ionization technology has been rigorously tested
and scientifically proven to be extremely effective at
reducing harmful particulates, irritating volatile organic
compounds (VOC's) and odors as well as significantly
reducing mold, bacteria, viruses and germs in the air and
on surfaces.
The R1 model is typically used for spaces up to 58.06
SPECIFIC
General P
Air Flow C
Treatment
Housing M
Weight
Maximum
Temperatu
Electrical
Voltage
Frequency
Power Con
Current Dr
Fuse
AtmosAir.com
CAG-06-21-002
Field Elect
Connectio
Ionization
Advertisement
Table of Contents
Related Manuals for AtmosAir Rainier Summit R1
Summary of Contents for AtmosAir Rainier Summit R1
- Page 1 Weight Maximum Temperatu APPLICATION Electrical The AtmosAir Rainier Summit is a standalone self Voltage contained compact unit designed to increase ionization Frequency levels to restore indoor air to its natural state where no pollution or contaminants exist. The Rainier’s patented...
- Page 2 User Guide & General Maintenance Rainier Summit R1 SERVICE REMINDER This handy reminder is included so you can keep track of needed filter and tube replacements: Date Unit Placed in Service (enter date) Filter Replacement (enter date 3 months from above)
- Page 3 User Guide & General Maintenance Rainier Summit R1 !IMPORTANT! READ THIS BEFORE STARTING MAINTENANCE. DO NOT THROW AWAY THIS GUIDE. For safe maintenance you MUST: ■ Always disconnect power to the unit before handling any of the components. ■ DO NOT connect to the power before the maintenance is complete and personnel are aware of the imminent operation.
-
Page 4: Table Of Contents
User Guide & General Maintenance Rainier Summit R1 Table of Contents 01 OPERATING INSTRUCTIONS Package Contents Choosing Location Unit Setup 02 GENERAL USE GUIDELINES Unit Settings Unit Settings Continued Room Conditions Care and Handling Maintaining Your Unit Maintaining Your Unit Continued... -
Page 5: Operating Instructions
01 OPERATING INSTRUCTIONS Congratulations on your purchase of the AtmosAir Rainier Summit R1/R2 portable air purifier. The Rainier uses state of the art bi-polar ionization technology and high efficiency filtration to provide cleaner healthier indoor air. The following guide will provide you with instructions on how to properly setup and use your unit so you may enjoy its benefits for many years. -
Page 6: General Use Guidelines
User Guide & General Maintenance Rainier Summit R1 02 GENERAL USE GUIDELINES Unit Settings There are 2 control knobs on each unit, one for Ion Control (2) and another for Fan Speed (3). These allow you to adjust the unit to suit spaces small and large up to its maximum effective range. -
Page 7: Unit Settings Continued
User Guide & General Maintenance Rainier Summit R1 Unit Settings continued If during initial adjustment you notice a “sweet” or “metallic” presence in the air, this may be caused by the Ion Control being set too high or the Fan Speed set too low and too many ions for the space the unit is applied to. Adjust the Ion Control down and the Fan Speed up to balance the ions. -
Page 8: Maintaining Your Unit Continued
The filters for this unit are custom designed for the unit and are only purchased your Rainier. The filters for this unit are custom designed for the unit and are only available from an AtmosAir reseller. available from an AtmosAir reseller. -
Page 9: Troubleshooting
User Guide & General Maintenance Rainier Summit R1 03 TROUBLESHOOTING System Not Powering On Power Light Will Not Illuminate ■ Check your power source to be sure there is power to the Follow all the above steps for powering on. The power light will unit. -
Page 10: Tube Replacement
04 TUBE REPLACEMENT This is the procedure for replacing the glass ‘B’ Sized tube in an AtmosAir Rainier R1/R2 ionization unit. At the end of its service life, the ionization tube must be replaced in order to keep the ionization unit working correctly. The End user must remove the old tube and install a new, genuine AtmosAir ionization tube. - Page 11 User Guide & General Maintenance Rainier Summit R1 Identify the 4 Phillips-head machine screws that must be removed in order to open the unit. They are located on the right and left side of the unit towards the bottom. Place the unit standing upright, on one of its sides, preferably on a towel or foam pad in order to not scratch the unit or work surface.
- Page 12 User Guide & General Maintenance Rainier Summit R1 Once the screws on one side are removed, turn the unit over and remove the screws onthe opposite side. CAUTION: REFER TO STEPS 7 & 8 BEFORE PROCEEDING TO STEP 6. DO NOT PULL THE BLACK CHASSIS AWAY FROM...
- Page 13 User Guide & General Maintenance Rainier Summit R1 Turn the unit so that the ionization tube is facing you. To remove the tube, use one hand to gently hold back the metal spring tang. With the other hand, hold the plastic cap of the tube and spin the tube out of the tube holder.
- Page 14 User Guide & General Maintenance Rainier Summit R1 Once the old tube is removed, it may be discarded as it is made of recyclable materials. To begin installing the new ionization tube, use one hand to gently hold back the metal spring tang.
- Page 15 User Guide & General Maintenance Rainier Summit R1 Check that the spring tang is lying flat against the screen without edge contact (as shown under step 18). Needle Nose Pliers can be used to adjust the spring tang to lay flat against the surface of the screen. Assure that the maximum contact area is achieved.
- Page 16 User Guide & General Maintenance Rainier Summit R1 The unit is now ready to be reassembled. Begin by gently sliding the two halves of the chassis together, taking care not to pinch any wires between the metal parts. Tuck the black part of the chassis under the lip of the white part (indicated) and close gently.
- Page 17 User Guide & General Maintenance Rainier Summit R1 Align the holes, use a Phillips no. 2 screwdriver to start screwing in the two screws in one side but leave them loose. Do not tighten them all the way until ALL screws have been inserted.
-
Page 18: Product Warranty
Clean Air Group or the dealer where you purchased the unit. Disclaimer: The air purification technology provided by AtmosAir is intended to improve air quality. It is not intended to replace reasonable precautions to prevent the transmission of airborne contaminants. Customer, its employees, invitees and all persons having access to the serviced premises should comply with all applicable public health laws and guidelines issued by federal, state and local governments and health authorities such as the Centers for Disease Control and Prevention (CDC).
