INSTRUCTION MANUAL
Electronic Oil Meter
OM 20
Congratulations on purchase of this World Class Electronic Oil Meter!
• Electronic digital meter featuring an
oval-gear measurement system.
• Designed for easy and precise
measuring of oils and other liquids
compatible with the component
materials.
• Features a non-volatile memory for
storing the dispensing data, even
in the event of a complete power
break for long periods.
• Robust Aluminum Die Cast
construction with a protective
Rubber Shroud
SPECIFICATIONS
Meter Type
Mechanism
Inlet / Outlet Position
Inlet / Outlet
Flow Rate
Accuracy
Repeatability
Max. Working Pressure
Burst Pressure
Pressure Loss
Working Temperature range
Max. Resettable Batch Total
Max. Non Resettable Totalizer
Least Count / Resolution
Filter/ Screen Included
Max. Viscosity of Media
Option to Recalibrate by User
Digital
Oval Gear
In-Line
1/2" BSP (F) or 1/2" NPT (F)
1 to 30 LPM (0.3 to 8 GPM)
+/- 0.50%
+/- 0.30%
1000 PSI (70 BAR)
2000 PSI (140 BAR)
10 PSI (0.7 BAR)
-10°C to 60°C (14°F to 140°F)
99,999 units
9,99,999 units
0.001 units
No
5000 cSt
Yes
1
S1710 , Rev A
Advertisement
Table of Contents
Related Manuals for Groz OM 20
Summary of Contents for Groz OM 20
- Page 1 INSTRUCTION MANUAL S1710 , Rev A Electronic Oil Meter OM 20 Congratulations on purchase of this World Class Electronic Oil Meter! • Electronic digital meter featuring an oval-gear measurement system. • Designed for easy and precise measuring of oils and other liquids compatible with the component materials.
- Page 2 Number Of positions in which display can be rotated Protective Shroud on Meter Weights & Measures Approved Calibration Certificate Included Water Resistance IP55 KNOW ABOUT YOUR FLOWMETER Table of Contents User Buttons - The meter features two buttons (RESET and CAL) which individually perform two main functions and together, A.
- Page 3 MEASUREMENT UNITS CONFIGURATION A few seconds after dispensing has ended, on the lower register, the display switches from Reset Total to General Total: the word RESET above the word TOTAL disappears, and the Reset Total is The METER comes with a menu through which the user can select replaced by the General Total.
- Page 4 IMPORTANT Press CAL key for more than 2 1,000 seconds. The METER enters The METER features a non-volatile memory that keeps the calibration mode and shows FACT data concerning calibration and total dispensed quantity “CAL”. The words “FACT” and stored for an indefinite time, even in the case of a long power “USER”...
- Page 5 The meter value changes in Press RESET key for more than the direction indicated by the 9,860 2 seconds. 0,000 arrow The METER shows “CAL” and • One unit for every short the Batch total at zero. The Cal FIELD Cal FIELD press of CAL key.
- Page 6 MAINTENANCE The meter has been designed to require a minimum amount of BATTERY REPLACEMENT PROCEDURE : maintenance. The only maintenance jobs required are: • Press RESET to update all the totals. • Battery change - Necessary when the batteries have run • Unscrew the battery plug (8).
- Page 7 COMPONENT LIST REFERENCE NUMBER DESCRIPTION QUANTITY Meter Label Plastic Face Electronic Board Screw Meter Housing Battery 1.5V N size O-Ring Battery Plug Conical Spring Oval Gear Pivot Oval Gear Oval Gear with Magnet Seal Cover Screw Battery Protection Spacer for Bulbs Spacer for Key CAUTION To reassemble the meter, take care of the following step :...
- Page 8 Village Kherki Daula, National Highway-8 Gurgaon-122001, Haryana, INDIA TEL +91.124.282.7700 / 221.4050 FAX +91.124.2827986 / 221.4224 FAX (USA) +1.509.271.7848 FAX (UK) +44.870.121.1854 E-MAIL info@groz-tools.com www.groz-tools.com The Groz name, Groz logo and the mark are trademarks of Groz Engineering Tools (P) Ltd. India...
