Page 1
Installation & MECHANICAL FUEL Operation Manual METER Inlet/Outlet: 3/4” (F) Inlet/Outlet: 1” (F) IMPORTANT! This manual contains important warnings and other information. READ AND KEEP FOR REFERENCE. S1420, Rev A July 2009...
Page 2
Arising out of the application and use of the equipment described. Should the equipment be used in a manner not specified by Groz the protection provided by the equipment may be impaired and the warranty voided. Questions or Service Assistance...
Table of Contents DISCLAIMER ..............Back of front cover QUESTIONS or SERVICE ASSISTANCE ......Back of front cover PRODUCT IDENTIFICATION INFORMATION ....Back of front cover General information ..................Introduction ....................1 Before Installation ..................1 Installation....................2 . Daily Operations ....................2 Maintenance ....................3 Calibration.....................3 Repair ......................4...
If you feel you need further assistance, Observe precautions against fire or feel free to write to Groz at explosion when dispensing fuel. info@groz-tools.com Avoid prolonged skin contact with Meters are factory calibrated in litres petroleum fuels.
DAILY OPERATIONS Any components such as hose, 1. Before use, visually check the meter to nozzle, or pump added to your me- ensure it is securely fitted to other system ter must be statically grounded and components and there is no leakage at approved for use with petroleum connections.
1. The large meter display represents the Figure 3 Batch Total for each fuel delivery. Before dispensing fuel, reset the Batch Total to zero by turning the reset knob on the side of the meter counterclockwise. (Figure 2) Figure 2 2.
3. Fill a graduated calibration container to a 2. Remove the two screws connecting the counter cover to the counter assembly. specified quantity. For the greatest accuracy, be sure the container is placed on Remove the counter cover. a level surface and a consistent flowrate is used.
3. Misaligned nutator disc Disassemble meter and align nutator disc pin with the counter assembly. 4. Broken nutator disc pin or Disassemble meter and install new defective nutator assembly nutator assembly. 5. Missing or jammed counter Contact Groz Customer Service. bevel gear...
It may be possible to diagnose the trouble and Shipping Weight 1.8 kg identify needed parts in a telephone call or letter. Groz can also inform you of any special Dimensions handling requirements you will need to follow Width 13.9 cm...
Drain the meter using Do not return meters or parts without procedures in the Repair Section. specific authority from the Groz Customer Service Department. Due to strict regulations governing shipment of flammable liquids, meters may be refused and returned to the sender if sent without authorization.
