MANUAL DE INSTALACIÓN DGLPMWLC - DGLIMWLC Lectores Mifare 13,56 MHz Wiegand ® Gracias por confiar en CDVI con la adquisición de este producto. 1] PRESENTACIÓN DE PRODUCTOS DGLPMWLC Wiegand 26, 30 o 44 bits. Versiones disponibles: - Acero inoxidable (DGLIMWLC).
Page 3
MANUAL DE INSTALACIÓN DGLPMWLC - DGLIMWLC Lectores Mifare 13,56 MHz Wiegand ® 5] ESQUEMA DE CONEXIONADO DGLPMWLC ST5-ST6: LED ST1-ST2: Formato de salida Wiegand Formato de salida: Comando por nivel - Standard: 26 bits Wiegand. «O» (OV) - ST1: 30 bits Wiegand.
Page 4
MANUAL DE INSTALACIÓN DGLPMWLC - DGLIMWLC Lectores Mifare 13,56 MHz Wiegand ® 5] ESQUEMA DE CONEXIONADO DGLIMWLC POSICIONAMIENTOS POSICIONAMIENTO DIPSWITCH 1 Y 2 DIPSWITCH 3 Puede controlar el buzzer OFF/OFF y los LED a través del 26 bits lector o un dispositivo externo.
Page 5
MANUAL DE INSTALACIÓN DGLPMWLC - DGLIMWLC Lectores Mifare 13,56 MHz Wiegand ® 6] FORMATO DE SALIDA WIEGAND 26, 30 Y 44 BITS Cronogramas Lógica 0 Lógica 1 \DATA1 \CLOCK \DATA0 50 μs 50 μs Salidas en colector abierto con pull ups internos de 1 K a +5 V o +12 V según posición de dipswitch ST4.
Page 6
MANUAL DE INSTALACIÓN DGLPMWLC - DGLIMWLC Lectores Mifare 13,56 MHz Wiegand ® Formato Wiegand 30 bits Formato de 30 bits hexadecimal. La comunicación se efectúa por una conexión Wiegand de 30 bits (señales: DATA1, DATA0 y CLOCK) en la que la trama se descompone de la siguiente manera: 1 - Primera paridad: 1 bit –...
MANUAL DE INSTALACIÓN DGLPMWLC - DGLIMWLC Lectores Mifare 13,56 MHz Wiegand ® 7] MONTAJE Asegúrese de que todas las piezas necesarias están incluidas en la caja del pro- ducto. Utilice las herramientas adecuadas para cada tipo de instalación (taladro, destornilladores, cinta métrica...) y siga las instrucciones de montaje del lector.
1] PRODUCTS OVERVIEW DGLPMWLC Wiegand 26, 30 ou 44 bits. Available in version: - Stainless steel (Réf : DGLIMWLC), - Polycarbonate (Réf : DGLPMWLC). PCB sealed in epoxy. Audible and visual feedback. Surface mount. Technologie : 13,56 Mhz. Connecting by 6/40 4-pair cable.
Page 9
30 BITS 44 BITS No pull up 30 BITS 44 BITS Select the output voltage 44 BITS according to the installation. DGLPMWLC - Terminal (8 pins) : Input voltage 12VDC Clock Data 0 Data 1 Buzzer Green LED Red LED...
Page 10
INSTALLATION MANUAL DGLPMWLC - DGLIMWLC 13.56 MHZ Mifare Card Readers - Wiegand Output ® 5] WIRING DIAGRAM : DGLIMWLC DIPSWITCH 1 & 2 DIPSWITCH 3 POSITIONNING POSITIONNING The buzzer and the LED’s OFF/OFF can be controlled by the 26 bits reader or by an external device.
Page 11
INSTALLATION MANUAL DGLPMWLC - DGLIMWLC 13.56 MHZ Mifare Card Readers - Wiegand Output ® 6] OUTPUT FORMATS 26, 30 ET 44 BITS WIEGAND Chronograms 0 logic 1 logic \DATA1 \CLOCK \DATA0 50 μs 50 μs Open collector output with internal pulls up 1K at +5V or +12V according the ST4 position.
Page 12
INSTALLATION MANUAL DGLPMWLC - DGLIMWLC 13.56 MHZ Mifare Card Readers - Wiegand Output ® 30-bit Wiegand Output Structure and description of the code Signals output in open collectors with pull up in 30-bit hexadecimal format. The output format from the proximity reader is 30-bit wiegand (Signal: DATA1, DATA0 and CLOCK) and is structured as follow: 1 - First parity : 1 bit –...
INSTALLATION MANUAL DGLPMWLC - DGLIMWLC 13.56 MHZ Mifare Card Readers - Wiegand Output ® 7] MOUNTING INSTRUCTIONS Make sure that there are no pieces missing in the mounting kit. Get the right tools according to the installation type (Drill, screw drivers, metre tape,...) and follow the mounting instructions of the reader.
