E-type Prophy Angle Handpiece
Ultimate BA-102, BA-103
Operation Manual
The EU directive 93/42/EEC was applied in the design
and production of this medical device.
AUTOCLAVABLE
Caution before use
• The BA Brand Ultimate prophy angle handpiece is intended for use by
dental professionals only.
• Read this Operation Manual carefully before using the prophy angle
handpiece. Be sure to follow all the operating instructions, including
all cautions and warnings.
• Keep this Operation Manual for future reference.
Specifications
Head Configuration
Backend Configuration
Spindle
Installation/Removal of Brush/Rubber Cup
• Install/remove Brush/Rubber Cup onto/from prophy angle handpiece,
following the manufacturers' instructions.
Installation of Prophy Angle Handpiece on
BA-102 E-type Prophy Handpiece
• Make sure that the motor on to which the prophy angle handpiece is
attached is an ISO E-type.
• Insert the E-type fitting of the motor into the back-end of the prophy
angle handpiece.
• Make sure that the prophy handpiece is securely installed on to the
motor, by pulling it gently with fingers, and then make a trial run be-
fore use.
to E-type Motor
ENGLISH
BA-102 BA-103
9792874
Rev.2016/08
BA-102, BA-103
Screw Type
ISO E-type
-
9792923
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for B.A. International Ultimate BA-102
Summary of Contents for B.A. International Ultimate BA-102
- Page 1 ENGLISH BA-102 BA-103 9792874 9792923 E-type Prophy Angle Handpiece Ultimate BA-102, BA-103 Operation Manual The EU directive 93/42/EEC was applied in the design and production of this medical device. AUTOCLAVABLE Rev.2016/08 Caution before use • The BA Brand Ultimate prophy angle handpiece is intended for use by dental professionals only.
- Page 2 Caution • Never install/remove the prophy angle handpiece onto/from the motor while the motor is in operation. • Whenever abnormality in performance, sound level, heat level, func- tion, etc. is sensed, stop using the prophy angle handpiece immedi- ately and consult BA International Ltd. or an accredited BA certified Service Centre.
-
Page 3: Service And Repair
Removal/Connection of Head from/ to E-type shank The head of BA-102 E-type prophy angle handpiece is replaceable. Removal • Turn union nut counterclockwise with fingers. • Pull the head out. Connection • Insert the transmission gear into the head, and then rotate it with the fingers so that the gear of the transmission gear engages with that of the head. -
Page 4: Specifications
ESPAÑOL BA-102 BA-103 9792874 9792923 Pieza de mano Prophy Angle tipo-E Ultimate BA-102, BA-103 Manual de instrucciones En el diseño y la producción de este dispositivo médico se aplicó la directiva de la Unión Europea 93/42/EEC. AUTOCLAVABLE Rev.2016/08 Advertencias antes de usar •... - Page 5 Precaución • No instale/extraiga nunca la pieza de mano Prophy Angle en/de el motor mientras el motor esté en funcionamiento. • Si se percibe alguna anomalía en el rendimiento, nivel de sonido, nivel de temperatura, función, etc. deje de utilizar de inmediato la pieza de mano Prophy Angle y consulte a BA International Ltd.
-
Page 6: Reparación Y Servicio Técnico
Extracción/Conexión del cabezal de/al mango tipo E El cabezal de la pieza de mano Prophy Angle BA-102 tipo E es reem- plazable. Extracción • Gire la tuerca de unión en sentido con- trario de las agujas del reloj con los de- dos. -
Page 7: Spécifications
FRANCAIS BA-102 BA-103 9792874 9792923 Pièce à main E-type Prophy Angle Ultimate BA-102, BA-103 Mode d‘emploi La conception et la production de ce dispositif médical ont été faites dans le respect des exigences de la direc- tive européenne 93/42/CEE. AUTOCLAVABLE Rev.2016/08... - Page 8 Attention • Ne jamais installer/retirer la pièce à main Prophy Anglesur le/du mo- teur lorsque celui-ci est en cours d’utilisation. • Lorsque vous jugez que le dispositif fonctionne anormalement, que ce soit en termes de performances, de niveau sonore, de niveau ther- mique, de fonctionnement, etc., arrêtez immédiatement le moteur de la pièce à...
-
Page 9: Service Et Réparation
Retrait/connexion de la tête de/sur la tige E-type La tête de la pièce à main Prophy Angle BA-102 E-type est rempla- çable. Retrait • Tourner le filetage dans le sens antiho- raire avec les doigts. • Retirer la tête. Connexion •... -
Page 10: Technische Daten
DEUTSCH BA-102 BA-103 9792874 9792923 Prophy-Angle-Handstück, Typ E Ultimate BA-102, BA-103 Bedienungsanleitung Bei der Konzeption und Herstellung dieses Medizinpro- dukts wurde EU-Richtlinie 93/42/EWG angewandt. AUTOKLAVIERBAR Rev.2016/08 Vorsicht vor Inbetriebnahme • Das Ultimate Prophy-Angle-Handstück der Marke BA ist ausschliess- lich für die Verwendung durch Dentalfachleute vorgesehen. - Page 11 Vorsicht • Das Prophy-Angle-Handstück nie bei Rotation des Motors aufsetzen/ abziehen. • Ist die Leistung, Lautstärke, Wärmeentwicklung, Funktion usw. anders als normal, schalten Sie das Prophy-Angle-Handstück sofort aus und wenden Sie sich an BA International Ltd. oder ein akkreditiertes, von BA zertifiziertes Service-Center. •...
-
Page 12: Wartung Und Reparatur
Abziehen/Aufsetzen des Kopfes vom/ auf den Schaft, Typ E Der Kopf des Angle-Handstücks, BA-102 Typ E, ist austauschbar. Entfernen • Drehen Sie die Anschlussmutter mit den Fingern gegen den Uhrzeigersinn. • Ziehen Sie den Kopf heraus Aufsetzen • Führen Sie das Getriebe in den Kopf ein und drehen Sie es dann mit den Fingern so weit, bis die Rastnase im Kopf ein- rastet. - Page 13 ITALIANO BA-102 BA-103 9792874 9792923 Contrangolo per profilassi Tipo E Ultimate BA-102, BA-103 Manuale operativo Per la progettazione e la produzione di questo dispositivo medico è stata applicata la Direttiva UE 93/42/CEE. AUTOCLAVABILE Rev.2016/08 Avvertenze per l’uso • Il contrangolo per profilassi BA Brand Ultimate è da intendersi desti- nato esclusivamente a professionisti del settore odontoiatrico.
- Page 14 Attenzione • Non installare/rimuovere mai il contrangolo per profilassi sul/dal mo- tore mentre questo è in funzione. • Se si notano irregolarità di funzionamento, livello sonoro, livello di riscaldamento, funzionalità, ecc., interrompere immediatamente l’uso del contrangolo per profilassi e consultare BA International Ltd. o un centro di assistenza autorizzato e accreditato BA.
-
Page 15: Assistenza E Riparazione
Rimozione/collegamento della testina da/ su anello tipo E La testina del contrangolo per profilassi tipo E BA-102 può essere sostituita. Rimozione • Ruotare il dado di accoppiamento con le dita in senso antiorario. • Estrarre la testina. Collegamento • Inserire l’ingranaggio di trasmissione nella testina e quindi ruotarla con le dita facendo in modo che l’ingranaggio della trasmissione si incastri con quello della testina.
