TE Connectivity 1213819-1 Customer's Manual

Straight- action adapter battery powered crimp tool kit

Advertisement

Quick Links

E2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company
All Rights Reserved
*Trademark
TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Other logos, product and/or Company names may be trademarks of their respective owners.
Straight- Action Adapter Battery
Powered Crimp Tool Kit 1213819- [ ]
SAFETY PRECAUTIONS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safeguards are designed into this application equipment to protect operators and
maintenance personnel from most hazards during equipment operation. However,
certain safety precautions must be taken by the operator and repair personnel to
avoid personal injury, as well as damage to the equipment. For best results,
application equipment must be operated in a dry, dust- -free environment. Do not
operate equipment in a gaseous or hazardous environment.
D ALWAYS wear appropriate ear protection.
D ALWAYS wear appropriate eye protection.
D ALWAYS wear approved eye protection when operating powered equipment.
D ALWAYS keep guard(s) in place during normal operation.
D NEVER wear loose clothing or jewelry that may catch in moving parts of the
application equipment.
D NEVER insert hands into installed application equipment.
D NEVER alter, modify, or misuse the application equipment.
TOOLING ASSISTANCE CENTER
1--800--722--1111
READ THIS FIRST !
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at www.te.com
Customer Manual
409- - 10058
13 JUL 11 Rev E
2
4
5
5
6
6
6
6
6
7
7
7
7
7
8
8
1 of 8
LOC B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1213819-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TE Connectivity 1213819-1

  • Page 1: Table Of Contents

    All Rights Reserved 1--800--722--1111 For latest revision and Regional Customer Service, *Trademark visit our website at www.te.com LOC B TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Other logos, product and/or Company names may be trademarks of their respective owners.
  • Page 2 409- 10058 SAFETY PRECAUTIONS - - IMPORTANT SAFETY INFORMATION DANGER CAUTION DANGER CAUTION DANGER DANGER CAUTION DANGER CAUTION This unit should only be used by trained DANGER competent personnel. Read and understand the entire manual before using the equipment. NOTE: Keep all decals clean and legible, and replace when necessary.
  • Page 3 409- 10058 TOOLING ASSISTANCE CENTER CALL TOLL FREE 1- 800- 722- 1111 (CONTINENTAL UNITED STATES AND PUERTO RICO ONLY) The Tooling Assistance Center offers a means of providing technical assistance when required. In addition, Field Service Specialists are available to provide assistance in the adjustment or repair of the application equipment when problems arise which your maintenance personnel are unable to correct.
  • Page 4: Introduction

    Kit 1213819--[ ] is designed to accept various crimping die assemblies that are sold separately and are available from TE Connectivity. For crimping die set information concerning wire preparation, crimping procedures, maintenance, inspection, and repair, refer to the applicable instructions for the appropriate crimping die set.
  • Page 5: Receving/Inspection

    409- 10058 CRIMP TOOL (with Battery Installed) Length 343 mm [13.5 In.] Width 60 mm [2 3/8 In.] Depth 80 mm [3 1/8 In.] Mass/Weight (w/Battery) 1.3 kg [2.9 lb.] Sound Level 75 dBA at 1 Meter Vibration < 2.5 m/s2 Hydraulic Oil Shell Tellus...
  • Page 6: Die Set Installation

    409- 10058 3.1. Die Set Installation (Figure 3 ) If dies to be installed in the tool require insulation adjustment, refer to the instruction sheet packaged with the dies for adjustment, then proceed as follows: 1. Remove the battery from the tool. 2.
  • Page 7: Preventive Maintenance

    409- 10058 To avoid personal injury, keep fingers clear of the crimping area. DANGER To operate the Straight--Action Adapter Battery Powered Crimp Tool 1213819--[ ]: 1. Insert the terminal into the dies. 2. Depress the trigger to advance the moving jaw in order to hold the terminal in place. Do NOT deform the terminal body.
  • Page 8: Return/Repair

    409- 10058 PROBLEM PROBABLE CAUSE REMEDY Dirt, contaminants, etc, in ram area of tool Return tool to TE. Crimp tool battery contacts damaged Reform the contacts. Tool is inoperative. Tool components are worn or damaged. Return tool to TE. Oil level is low. Return tool to TE.
  • Page 9 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: TE Connectivity 1213819-3...

This manual is also suitable for:

213819-2213819-3213819-4213819-5
