  • Page 1 CL5708 / CL5716 8 / 16-Port VGA Single Rail LCD KVM Switch User Manual...

  • Page 2: Compliance Statements

    CL5708 / CL5716 User Manual Compliance Statements FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 3: About This Manual

    RoHS This product is RoHS compliant. About this Manual This manual is provided to help you get the most out of your CL5708 / CL5716. It covers all aspects of the device, including installation, configuration, and operation. The LCD KVM switch models covered in this manual include:...

  • Page 4: Conventions

    PC to Sun keyboard emulation mappings. Chapter 7, The Firmware Upgrade Utility, explains how to upgrade the CL5708 / CL5716's firmware to the latest available versions using firmware upgrade utility. Appendix, provides specifications and other technical information at the end of the manual.

  • Page 5: Product Information

    * Features may have been added to the CL5708 / CL5716 since this manual was released. Please visit our website to download the most up-to-date version of the manual.

  • Page 6: Telephone Support

    CL5708 / CL5716 User Manual Telephone Support For telephone support, call this number: International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 1-949-428-1111 User Notice All information, documentation, and specifications contained in this manual are subject to change without prior notification by the manufacturer. The...

  • Page 7: Table Of Contents

    CL5708 / CL5716 User Manual Contents Compliance Statements ........ii About this Manual .
  • Page 8 CL5708 / CL5716 User Manual Changing Station Positions ....... . . 27 Hot Plugging KVM Ports .
  • Page 9 Connection Tables ......... . 74 CL5708 to Compatible 8-Port Switches ..... . . 74 CL5708 to Compatible 16-Port Switches .
  • Page 10 CL5708 / CL5716 User Manual This Page Intentionally Left Blank...

  • Page 11: Introduction

    (See Compatible Products on the product web page for a list of compatible ATEN switches.) The CL5708 / CL5716 is built on a modular design. The KVM section can be detached from the switch section for convenient maintenance and repair.

  • Page 12: Features

    There is no better way to save time and money than with a CL5708 / CL5716 installation. By using the CL5708 / CL5716’s sliding LCD console to manage...

  • Page 13: External Console

    Chapter 1. Introduction  Keyboard and mouse emulation (PS/2 and USB) for smooth switching and simultaneous booting of multiple computers even when the console focus is elsewhere  Superior video quality — supports resolutions of up to 1280 x 1024 @ 75 ...

  • Page 14: Requirements

    LCD monitor's maximum resolution.  PS/2 mouse and keyboard ports (6-pin Mini-DIN), or at least one USB port.  Direct support for Sun USB systems; or, for Sun legacy systems, an ATEN CV130A Sun Console Converter is required.

  • Page 15: Cables

    Chapter 1. Introduction Cables Substandard cables may damage the connected devices or affect the installation’s overall performance. For optimum signal integrity and a simplified layout, we strongly recommend that you use the high-quality CS custom cable sets described below: Function Length Part Number KVM switch to KVM switch...

  • Page 16: Components

    CL5708 / CL5716 User Manual Components Front View Note: The CL5716 is pictured in the diagrams of this chapter. However, the CL5708 is the same as the CL5716, except that it has 8 KVM ports.
  • Page 17 Firmware upgrade port: The firmware upgrade cable that upgrade transfers the firmware upgrade data from the administra- section tor's computer to the CL5708 / CL5716 plugs into this RJ- 11 connector.  Firmware upgrade switch: During normal operation this switch should be in the NORMAL position. (See The Firm- ware Upgrade Utility, page 55 for firmware upgrading details.)

  • Page 18: Rear View (Ac Power)

    The grounding wire used to ground the switch attaches here. terminal external console For flexibility and convenience, the CL5708 / CL5716 port supports an independent, external, KVM console. The external console keyboard, monitor, and mouse cables plug in here.

  • Page 19: Hardware Setup

    Chapter 2 Hardware Setup Overview For convenience and flexibility, the CL5708 / CL5716 allows mixing of PS/2 and USB interfaces with custom KVM cables that serve as the medium between the KVM switch and the connected computers. A separate custom KVM cable is required for each computer connection, and the various types available are listed in the Cables section on page 5.

  • Page 20: Standard Rack Mounting

    CL5708 / CL5716 User Manual Standard Rack Mounting A standard rack mount kit is provided with your CL5708 / CL5716. The kit enables the switch to be mounted onto a rack with a depth of 42.0 – 77.0 cm. left & right L-shaped brackets...
  • Page 21 Chapter 2. Hardware Setup 2. While the first person still holds the unit in place, the second person slides the left & right L-shaped brackets into the unit’s side mounting brackets from the rear, installing four screws in the brackets to secure them in place. 3.

  • Page 22: Optional Rack Mount Kits

    To prevent damage to your installation it is important that all devices are properly grounded. Use a grounding wire to ground the CL5708 / CL5716 by connecting one end of the wire to the grounding terminal, and the other end of the wire to a suitable...

  • Page 23: Single Level Installation

    AC Power Models 1. Ground the unit. 2. If you choose to connect an external console to the CL5708 / CL5716, use the console cable provided to plug a keyboard, monitor, and mouse into the console port. See Cabling Diagrams, page 15.
  • Page 24 CL5708 / CL5716 User Manual AC Power Installation Diagram...

  • Page 25: Cabling Diagrams

    Chapter 2. Hardware Setup Cabling Diagrams Use the following diagrams as a guide for attaching cables to an external console and/or computers you will be connecting to the CL5708 / CL5716. Console Cable Installation Diagram PS/2 KVM Cable Installation Diagrams...

  • Page 26: Daisy Chain Installations

    1. For setting the LCD KVM switch CL5708 / CL5716 as the first station, connect the Chain Out port of CL5708 / CL5716 to the chain in port of the next station using a daisy chain cable set (described in the Cables section, page 5).
  • Page 27 Chapter 2. Hardware Setup Daisy Chain Installation Diagram CHAIN OUT CL5708 / CL5716 CHAIN OUT CHAIN IN COMPATIBLE SWITCH CHAIN OUT CHAIN IN COMPATIBLE SWITCH TO NEXT STATION...
  • Page 28 CL5708 / CL5716 User Manual This Page Intentionally Left Blank...

  • Page 29: Basic Operation

    Basic Operation Opening the Console The CL5708 / CL5716's console is located under the top cover. To access the console, slide the console module out and raise the cover. Note: As a safety precaution, to keep the console from accidentally sliding out, the console is locked into the In position.

  • Page 30: Closing The Console

    CL5708 / CL5716 User Manual Closing the Console To slide the console module back in, close the cover and do the following: 1. Pull the safety catches on the unit's side rails toward you and push the module in until it stops.

  • Page 31: Operating Precautions

    Chapter 3. Basic Operation Operating Precautions The maximum load bearing capacity of the keyboard module is 30kg. Failure to heed the information below can result in damage to the keyboard module. Right! Rest your hands and arms lightly on the keyboard module as you work.

  • Page 32: Powering Off And Restarting

    CL5708 / CL5716 User Manual Powering Off and Restarting If it becomes necessary to power off the CL5708 / CL5716, do the following before restarting it: 1. Shut down all the computers that are attached to the CL5708 / CL5716.

  • Page 33: Lcd Osd Configuration

    Chapter 3. Basic Operation LCD OSD Configuration The LCD Buttons The LCD OSD allows you to set up and configure the LCD display. Four buttons are used to perform the configuration, as described in the table, below: Button Function  MENU When you have not entered the LCD OSD Menu function, pressing this button invokes the Menu function, and brings up...

  • Page 34: Lcd Adjustment Settings

    CL5708 / CL5716 User Manual LCD Adjustment Settings An explanation of the LCD OSD adjustment settings is given in the table below: Setting Explanation Brightness Adjusts the background black level of the screen image. Contrast Adjusts the foreground white level of the screen image.

  • Page 35: Hot Plugging

    Chapter 3. Basic Operation Hot Plugging The CL5708 / CL5716 supports hot plugging - components can be removed and added back into the installation by unplugging their cables from the ports without the need to shut the unit down. In order for hot plugging to work...

  • Page 36: Port Selection

    This number is displayed on the front panel station ID LED.  The Port Number is a two digit number of the port on the CL5708 / CL5716 station that a computer is connected to. This number is displayed on the front panel port ID LED.

  • Page 37: Usb Peripheral Devices

    The front panel USB port is available to connect a USB peripheral device (flash drive, CD-ROM drive, printer, etc.) to the CL5708 / CL5716. Any computer connected to the CL5708 / CL5716 can access the USB peripheral on a one-at- a-time basis. The peripheral device is available to computers connected to the CL5708 / CL5716 on the same level only, and is not available to computers connected to daisy chained switches.
  • Page 38 CL5708 / CL5716 User Manual This Page Intentionally Left Blank...

  • Page 39: Osd Operation

    ATEN’s factory and technical support staff to identify products. This number does not affect products’ warranty. If your product requires after-sales services, you may provide the MFG Number to ATEN’s sales or technical support staff to identify the product and model number.

  • Page 40: Osd Hotkey

    OSD on the LCD or an external console monitor while also viewing the display of any port on the CL5708 / CL5716 by pressing [Scroll Lock] or [Ctrl] twice. Note: To enable and set the OSD hotkey, see OSD Hotkey, page 33..

  • Page 41: Osd Main Screen Headings

    Chapter 4. OSD Operation OSD Main Screen Headings The table below describes the OSD main screen headings. Heading Description SN--PN This column lists the port ID numbers (station number - port number) for all the KVM ports on the installation. The simplest method to access a particular computer is move the highlight bar to it, then press [Enter].

  • Page 42: Osd Functions

    CL5708 / CL5716 User Manual OSD Functions OSD functions are used to configure and control the OSD. For example, you can rapidly switch to any port, scan selected ports, limit the list you wish to view, designate a port as a quick view port, create or edit a port name, or make OSD setting adjustments.

  • Page 43: F2: List

    Chapter 4. OSD Operation F2: LIST This function lets you broaden or narrow the scope of which ports the OSD displays on the main screen. The submenu choices and their meanings are given in the table below. Choice Meaning Lists all of the ports on the installation that have been set accessible by the administrator for the current logged in user.
  • Page 44 CL5708 / CL5716 User Manual PORT ID Allows each user to customize the position where the port ID DISPLAY appears on the screen. The default is the upper left corner, but POSITION users can choose to have it appear anywhere on the screen.
  • Page 45 SCREENSAVER Prevents the OSD screen from a burn-in on the LCD panel when a user leaves the OSD on for a long period of time. The SCREENSAVER function will float the ATEN logo on the screen when enabled.  Set the wait time from 1 ~ 60 minutes. Setting 0 disables the SCREENSAVER function.

  • Page 46: F4: Adm

    CL5708 / CL5716 User Manual F4: ADM F4 is an administrator only function. It allows the administrator to configure and control the overall operation of the OSD. To change a setting double-click it, or use the up and down arrow keys to move the highlight bar to it then press [Enter].
  • Page 47 Chapter 4. OSD Operation (Continued from previous page.) Setting Function SET USER To record a fingerprint: LOGIN 1. Select an item from the list and double-click it, or move the high- (continued) light bar to it and press [Enter]. 2. Swipe the selected finger across the reader 3 times as directed. 3.
  • Page 48 CL5708 / CL5716 User Manual (Continued from previous page.) Setting Function EDIT PORT To help remember which computer is attached to a particular port, NAMES every port can be given a name. This function allows the administrator to create, modify, or delete port names. To edit a port name: 1.
  • Page 49 3. Press [Esc] to exit. The operating system you selected is assigned to the KVM port. FIRMWARE In order to upgrade the CL5708 / CL5716 firmware (see page 55), UPGRADE you must first enable Firmware Upgrade mode with this setting.

  • Page 50: F5: Skp

    CL5708 / CL5716 User Manual F5: SKP Clicking the F5 field or pressing [F5] invokes Skip mode. This function enables you to easily skip backward or forward – switching the console focus from the currently active computer port to the previous or next available one.

  • Page 51: F6: Brc

    Chapter 4. OSD Operation F6: BRC F6 is an administrator only function. Clicking the F6 field, or pressing [F6], invokes Broadcast (BRC) mode. When this function is in effect, commands sent from the console are broadcast to to all available computers on the installation.

  • Page 52: F8: Lout

    CL5708 / CL5716 User Manual  To exit Auto Scan mode, press the [Spacebar] or [Esc]. F8: LOUT Clicking the F8 field, or pressing [F8] logs you out of OSD control of the computers, and blanks the console screen. This is different from simply pressing [Esc] when you are at the main screen to deactivate the OSD.

  • Page 53: Keyboard Port Operation

    Keyboard Port Operation Hotkey Port Control Hotkey port control allows you to provide KVM focus to a particular computer directly from the keyboard. The CL5708 / CL5716 provides the following hotkey port control features:  Selecting the Active Port  Auto Scan Mode Switching ...

  • Page 54: Invoke Hotkey Mode

    CL5708 / CL5716 User Manual Invoke Hotkey Mode All hotkey operations begin by invoking Hotkey mode. There are two possible keystroke sequences used to invoke Hotkey mode, though only one can be operational at any given time: Number Lock and Minus Keys 1.

  • Page 55: Select The Active Port

    Chapter 5. Keyboard Port Operation Select the Active Port Each KVM port is assigned a port ID (see Port ID Numbering, page 25). You can directly access any computer on the installation with a hotkey combination that specifies the port ID of the KVM port that a computer is connected to. To access a computer using hotkeys: 1.

  • Page 56: Auto Scan Mode

    CL5708 / CL5716 User Manual Auto Scan Mode Auto Scan automatically switches, at regular intervals, among all the KVM ports that have been set as accessible under Scan–Skip Mode, so that their activity can be monitored automatically. See Scan–Skip Mode on page 34 for more information.

  • Page 57: Skip Mode

    Chapter 5. Keyboard Port Operation Skip Mode This feature allows you to switch between computers in order to monitor them manually. You can dwell on a particular port for as long as you like – as opposed to auto-scanning, which automatically switches after a fixed interval. To invoke Skip mode, key in the following hotkey combination: 1.

  • Page 58: Computer Keyboard / Mouse Reset

    CL5708 / CL5716 User Manual Computer Keyboard / Mouse Reset If the keyboard or mouse cease to function on the computer connected to the currently selected port, you can perform a keyboard / mouse reset on the computer. This function is essentially the same as unplugging and replugging the keyboard and mouse on the target computer.

  • Page 59: Quick Hotkey Control

    Chapter 5. Keyboard Port Operation Quick Hotkey Control The Quick Hotkey (see HOTKEY, page 35) can be toggled between [Num Lock] + [-], and [Ctrl] + [F12]. To toggle the Quick Hotkey: 1. Invoke hotkey mode with the [Num Lock] + [-] or [Ctrl] + [F12] combination.

  • Page 60: Port Os Control

    CL5708 / CL5716 User Manual Port OS Control A port’s operating system can be changed to match that of the computer attached to the port. To change a port’s operating system, key in the following hotkey combination: 1. Invoke hotkey mode with the [Num Lock] + [-] or [Ctrl] + [F12] combination.

  • Page 61: Restore Default Values

    Chapter 5. Keyboard Port Operation Restore Default Values This administrator only hotkey restores the CL5708 / CL5716 default values. See RESTORE DEFAULT VALUES, page 38. To restore the default values, key in the following hotkey combination: 1. Invoke hotkey mode with the [Num Lock] + [-] or [Ctrl] + [F12] combination.

  • Page 62: Hotkey Summary Table

    CL5708 / CL5716 User Manual Hotkey Summary Table [Num Lock] + [-] [A] [Enter] Invokes Auto Scan mode. When Auto Scan mode is in effect, [P] or [Ctrl] + [F12] [Q] [Enter] left-click pauses auto-scanning. When auto-scanning is paused, pressing any key or another left-click resumes auto- scanning.

  • Page 63: Keyboard Emulation

    Chapter 6 Keyboard Emulation Mac Keyboard The PC compatible (101/104 key) keyboard can emulate the functions of the Mac keyboard. The emulation mappings are listed in the table below. PC Keyboard Mac Keyboard [Shift] Shift [Ctrl] Ctrl [Ctrl] [1] [Ctrl] [2] [Ctrl] [3] [Ctrl] [4] [Alt]...

  • Page 64: Sun Keyboard

    CL5708 / CL5716 User Manual Sun Keyboard The PC compatible (101/104 key) keyboard can emulate the functions of the Sun keyboard when the Control key [Ctrl] is used in conjunction with other keys. The corresponding functions are shown in the table below.

  • Page 65: The Firmware Upgrade Utility

    Introduction The purpose of the Windows-based firmware upgrade utility is to provide an automated process for upgrading the CL5708 / CL5716 and compatible adapter cable firmware. The program comes as part of a firmware upgrade package that is specific for each device.

  • Page 66: Preparation

    CL5708 / CL5716 User Manual Preparation To prepare for the firmware upgrade, do the following: 1. Use the firmware upgrade cable (provided with this unit), to connect a COM port on your computer to the firmware upgrade port of your switch.

  • Page 67: Starting The Upgrade

    Chapter 7. The Firmware Upgrade Utility Starting the Upgrade To upgrade the firmware: 1. Run the downloaded firmware upgrade package file either by double- clicking the file icon, or by opening a command line and entering the full path to it. The Firmware Upgrade Utility welcome screen appears: Note: The screens shown in this section are for reference only.
  • Page 68 CL5708 / CL5716 User Manual The Firmware Upgrade Utility main screen appears. The devices capable of being upgraded are listed in the Device List panel: 4. Click Next to perform the upgrade. If you enabled Check Firmware Version, the utility compares the device's firmware level with that of the upgrade files.

  • Page 69: Upgrade Succeeded

    Chapter 7. The Firmware Upgrade Utility Upgrade Succeeded After the upgrade has completed, a screen appears to inform you that the procedure was successful: Click Finish to close the firmware upgrade utility.

  • Page 70: Upgrade Failed

    CL5708 / CL5716 User Manual Upgrade Failed If the firmware upgrade fails (Upgrade Succeeded screen does not appear), you can recover the situation. Possible reasons for firmware upgrade failure are:  When a firmware upgrade was manually aborted.  When the unit’s firmware becomes corrupted for some reason and you are unable to operate it.

  • Page 71: Appendix

    Appendix Safety Instructions General  This product is for indoor use only.  Read all of these instructions. Save them for future reference.  Follow all warnings and instructions marked on the device.  Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result.
  • Page 72 CL5708 / CL5716 User Manual electrician to replace your obsolete outlet. Do not attempt to defeat the purpose of the grounding-type plug. Always follow your local/national wiring codes.  Do not allow anything to rest on the power cord or cables. Route the power cord and cables so that they cannot be stepped on or tripped over.

  • Page 73: Rack Mounting

    Appendix Rack Mounting  Before working on the rack, make sure that the stabilizers are secured to the rack, extended to the floor, and that the full weight of the rack rests on the floor. Install front and side stabilizers on a single rack or front stabilizers for joined multiple racks before working on the rack.

  • Page 74: Consignes De Sécurité

    CL5708 / CL5716 User Manual Consignes de sécurité Général  Ce produit est destiné exclusivement à une utilisation à l’intérieur.  Veuillez lire la totalité de ces instructions. Conservez-les afin de pouvoir vous y référer ultérieurement.  Respectez l’ensemble des avertissements et instructions inscrits sur l’appareil.
  • Page 75 Appendix  L’unité est équipée d’une fiche de terre à trois fils. Il s’agit d’une fonction de sécurité. Si vous ne parvenez pas à insérer la fiche dans la prise murale, contactez votre électricité afin qu’il remplace cette dernière qui doit être obsolète.
  • Page 76 CL5708 / CL5716 User Manual  N’essayez pas de réparer l’unité vous-même. Confiez toute opération de réparation à du personnel qualifié.  Si les conditions suivantes se produisent, débranchez l’unité de la prise murale et amenez-la à un technicien qualifié pour la faire réparer: ...

  • Page 77: Montage Sur Bâti

    Appendix Montage sur bâti  Avant de travailler sur le bâti, assurez-vous que les stabilisateurs sont bien fixées sur le bâti, qu’ils sont étendus au sol et que tout le poids du bâti repose sur le sol. Installez les stabilisateurs avant et latéraux sur un même bâti ou bien les stabilisateurs avant si plusieurs bâtis sont réunis, avant de travailler sur le bâti.

  • Page 78: Technical Support

    CL5708 / CL5716 User Manual Technical Support International  For online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com  For telephone support, see Telephone Support, page vi: North America Email Support support@aten-usa.com Online Troubleshooting http://support.aten.com Technical Documentation...

  • Page 79: Specifications

    Appendix Specifications Function CL5708 CL5708M 17” CL5708N 19” Computer Direct Connections 256 (via daisy chain) Port Selection OSD, Hotkeys, Pushbuttons Connectors External Console Port 1 x SPHD Male (Yellow) External Mouse Port 1 x USB Type-A Female (Front) KVM Ports...
  • Page 80 CL5708 / CL5716 User Manual Function CL5708 Environment Operating Temp. CL5708M 0–40 C / CL5708N 0–50 Storage Temp. -20–60 Humidity 0–85% RH, Non-condensing Physical Housing Metal + Plastic Properties Weight 17”: 13.47 kg 19”: 13.39 kg Dimensions (L x W x H) 17”: 48.00 x 64.27 x 4.40 cm...
  • Page 81 Appendix Function CL5716 Emulation Keyboard / Mouse PS/2, USB Video 1280 x 1024 @ 75 Hz; DDC2B Scan Interval (OSD Select) 1–255 sec. I/P Rating 100–240 VAC, 50/60 Hz, 1 A Power Consumption 17”: 120V, 17W / 230V, 18W 19”: 120V, 26W / 230V, 26.8W Environment Operating Temp.

  • Page 82: Connection Tables

    CL5708 / CL5716 User Manual Connection Tables The following tables indicate the relationship between the number of units and the number of computers that they control on a daisy chained installation. CL5708 to Compatible 8-Port Switches Computers Computers Computers Computers 1–8...

  • Page 83: Cl5716 To Compatible 8-Port Switches

    Appendix CL5716 to Compatible 8-Port Switches Computers Computers Computers Computers 1–16 73–80 137–144 201–208 17–24 81–88 145–152 209–216 25–32 89–96 153–160 217–224 33–40 97–104 161–168 225–232 41–48 105–112 169–176 233–240 49–56 113–120 177–184 241–248 57–64 121–128 185–192 249–256 65–72 129–136 193–200 257–264 CL5716 to Compatible 16-Port Switches...

  • Page 84: Supported Kvm Switches

    CL5708 / CL5716 User Manual Supported KVM Switches The table below lists KVM switches that are compatible with the CL5708 / CL5716 and the type of expansion that they use. (KVM switches listed below are sold separately. Contact your dealer for details.)

  • Page 85: Clear Login Information

    Appendix Clear Login Information If you are unable to perform an Administrator login (because the Username and Password information has become corrupted, or you have forgotten it), you can clear the login information with the following procedure. 1. Power off the switch and remove the top cover from the unit chassis. 2.

  • Page 86: Osd Factory Default Settings

    CL5708 / CL5716 User Manual OSD Factory Default Settings The factory default settings are as follows: Setting Default OSD Hotkey Port ID Display Position Upper Left Corner Port ID Display Duration 3 Seconds Port ID Display Mode Port Number plus the Port Name...

  • Page 87: Troubleshooting

    The distance between the external console and the the external monitor. CL5708 / CL5716 is too great. The maximum VGA cable distance should not exceed 20m and, in some cases, may need to be shorter. Replace the VGA cable with one...

  • Page 88: Keyboard Invocation Keys

    CL5708 / CL5716 User Manual Keyboard Invocation Keys Two dedicated keys are provided on the keyboard module to make it easy to invoke Hotkey mode and the OSD, as shown in the diagram, below Note: These keys are toggles. Press them once to invoke the feature, press them again to exit.

  • Page 89: Limited Warranty

    © Copyright 2021 ATEN® International Co., Ltd. Released: 2021-05-27 ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners.
