Motore tipo
Motor type
A2FE 28÷32 (A) 6.1
H0
A6VE 28 (A) 6.0
F12-030 (C-C)
A2FE 45÷63 (Z) 6.1
A6VE 55 (Z) 6.0/6.1
H1
F12-040÷060 (C-C)
V12-060 (C-C)
SAUER 51C60
A2FE 80÷90 (A) 6.1
H2
A6VE 80 (A) 6.0
SAUER 51C80
H2
A2FE 80÷90 (A) 6.1
A
H3
A2FM 23÷28 (Z) 6.1
H4
A2FM 32 (A) 6.1
A6VM 55 (Z) 6.0
H5
A2FM 45÷56 (Z) 6.1
A2FE 107÷125 (Z) 6.1
A6VE 107 (Z) 6.3
H6
F12-110 CHC
51C110 (SAUER)
H7
A6VE 80 (H) 6.1
A2FM 63 (A) 6.1
I5
V12-060 (I-D)
J0
A6VE 28 (A) 6.1/6.3
J1
A6VE 55 (A) 6.0
A6VE 107 (A) 6.0
J2
A6VE 160 (Z) 6.1
A2FE 125 (A) 6.1
J3
A16VE 80 (H) Serie 60
A6VE 160 (A) 6.1/6.3
J4
A2FE 160
J9
A6VM 200 (A) 6.3
R2
A10FE 45
R5
A10VE 28
R7
A10VE 63
L
L1
BOSCH REXROTH / PARKER VOAC
125,0÷125,8
89,9÷90,7
128,2÷129,0
93,2÷94,0
156,4÷157,2
111,4÷112,2
156,4÷157,2
111,4÷112,2
68,8÷69,6
25.7÷26,5
60,8÷61,6
25,7÷26,5
67,9÷68,7
32,7÷33,5
168,7÷169,5
123,9÷124,7
143,4÷144,2
111,4÷112,2
72,9÷73,7
32,7÷33,5
125,0÷126,0
90,0÷91,0
133,2÷134,0
93,2÷94,0
173,8÷174,6
123,9÷124,7
143,4÷144,2
111,4÷112,2
179,0÷180,0
123,9÷124,7
95,8÷96,6
40,7÷41,5
127,6÷128,8
115,6÷116,4
140,2÷141
d
DIN 5480 30x2 z14
DIN 5480 30x2 z14
DIN 5480 40x2 z18
DIN 5480 40x2 z18
DIN 5480 25x1,25 z18
DIN 5480 30x2 z14
DIN 5480 30x2 z14
DIN 5480 40x2 z18
DIN 5480 40x2 z18
DIN 5480 35x2 z16
DIN 5480 30x2 z14
DIN 5480 35x2 z16
DIN 5480 45x2 z21
DIN 5480 40x2 z18
DIN 5480 50x2 z24
DIN 5480 50x2 z24
SAE 16/32 z15
SAE 16/32 z13
SAE 12/24 z14
-11-
Vite
N°
(Nm)
Screw
M12x35-8.8
2
M16x40-8.8
2
M20x50-8.8
2
M20x50-8.8
2
M10x35-8.8
2
M10x35-8.8
2
M12x35-8.8
4
M20x45-8.8
2
M20x50-8.8
2
M12x35-8.8
4
M12x35-8.8
2
M16x40-8.8
2
M20x50-8.8
2
M20x50-8.8
2
M20-8.8
2
M20x60-10.9
4
M12x35-8.8
2
M12x35-8.8
2
M12x30-8.8
4
86
215
415
415
50
50
86
415
415
86
86
215
415
415
415
585
86
86
86
