www.pollardbros.com
Includes:
(1) Stool Seat
4
x
1/4" x 3/4" Hex Head
Machine Screw
Steps:
1
Lay seat on a hard surface with under side up.
2
Turn stool frame upside down and line up holes
in frame with pilot holes in seat fasten with (4)
¼" x ¾" Hex Head Machine Screws, ¼" Lock
Washer, and ¼" Hex nut.
(1) Stool Frame
(4) Leg Extensions
8
x
1/4" x 3/4" Round Head
Machine Screw
312 - Adjustable Height
Steel Shop Stool
Assembly Instructions
Tools Needed:
wrench
at head screwdriver
12
x
1/4" Lock Washer
12
x
1/4" Hex Nut
Advertisement
Table of Contents
Related Manuals for Pollard 312
Summary of Contents for Pollard 312
- Page 1 312 - Adjustable Height Steel Shop Stool Assembly Instructions www.pollardbros.com Tools Needed: Includes: wrench at head screwdriver (1) Stool Seat (1) Stool Frame (4) Leg Extensions 1/4” x 3/4” Round Head 1/4” x 3/4” Hex Head 1/4” Hex Nut 1/4” Lock Washer...
- Page 2 Glides to Leg Extensions using bolts equiped with glides like shown. After all brackets are in place, make sure table is square and then, tighten all screws. Pollard Brothers Manufacturing 5504 N. Northwest Highway Chicago IL 60630 (773)763-6868 (773)763-4466 (800) 551-5566...
