Summary of Contents for IGS Wonderland

  • Page 3: Table Of Contents

    Table of Contents 1. Hardware ..................2 Hardware Connection ................2 Connecting Touch Panel (Optional) ............3 DIP Switch Settings ................5 36 & 10 PIN Button Layout ..............6 Solving Ticket SSR Error ..............6 Reset ....................7 2. Bookkeeping & Adjustment ...........10 Access Flow Chart ................
  • Page 4: Hardware

    1. Hardware Hardware Connection 10-Pin Connector SD Card Slot 36-Pin Connector Audio Jack A. RS-232 Connects to optional Citizen printer/ticket dispenser. * Use Belkin #F2L044 (serial printer cable/null modem) for Citizen printer. DIP Sw 2 DIP Sw 1 B. RS-232 Connects to Micro Touch compatible touch screen VGA port...
  • Page 5: Connecting Touch Panel (Optional)

    Connecting Touch Panel (Optional) Type A Power +5V Connector Monitor Connector (Female) (15PIN Female) Refer to the diagram below to connect the touch screen.  After the connection, remember to adjust the Pin 1 of DIP SW2 to ON to ...
  • Page 6 Connection Diagram 36 Pins (6 Buttons) 10 Pins (6 Buttons) PARTS SIDE SOLDER SIDE PARTS SIDE SOLDER SIDE SPEAKER_R SPEAKER_L +12V +12V HOP-VCC TICKET OUT TICKET SSR TICKET SWITCH START / ALL STOP STOP4/SMALL/HELP STOP5/PLAY STOP1/TAKE STOP3/DOUBLE/SELECT LINE STOP2/BIG/HOLD PAIR COIN A KEY IN COIN C...
  • Page 7: Dip Switch Settings

    DIP Switch Settings DIP SWITCH 1 SLAVE ID LINK SINGLE MODE LINK...
  • Page 8: 10 Pin Button Layout

    DIP SWITCH 2 TOUCH 36 & 10 PIN Button Layout 6 Buttons START TAKE BI G DOUBLE SMALL PLA Y ALL STOP STOP1 STOP 2 STOP 3 STOP 4 STOP 5 TAKE (H OLD) (SELECT (HELP) LINE) Solving Ticket SSR Error After powering on the machine, if the ticket dispenser keeps working and can’t be stopped, it could be that the Ticket SSR’s jump setting is incorrect.
  • Page 9: Reset

    Reset Power off the machine and then power on. Press and hold the 【 TEST 】 button until the game enters the CHECKING SYSTEM page. Enter the 「 TEST 」 page. Press the 【 PLAY 】 button to enter the 「 TEST 2 」 PAGE (PAGE 2).
  • Page 10 Press the 【 STOP3 】 button to enter the 「 RESET 」 page. Press the 【 PLAY 】 button to RESET the game to default value.
  • Page 11 Press the 【 PLAY 】 button again to confirm RESET or press ANY button to EXIT. After RESET is completed, it displays SYSTEM RESET COMPLETED on the screen. Power off the machine and then power on to complete the Reset procedure.
  • Page 12: Bookkeeping & Adjustment

    2. Bookkeeping & Adjustment Access Flow Chart [RECORD] [STOP2] [STOP3] [STOP4] LAST HAND SHORT-TERM SYSTEM LAST CURRENT Enter DATA DATA Password Default password: Press [START] 8 times [STOP3] [STOP2] DOUBLE GAME MAIN GAME [STOP1] [STOP2] [STOP3] [STOP4] INTERFACE MAIN GAME DOUBLE GAME ADJUSTMENT [STOP2]...
  • Page 13: System Settings

    System Settings ITEMS SETTING SELECTION DEFAULT MAX. LINE PLAY 2, 4, 8, 10, 15, 20 MIN. PLAY(TOTAL) 1, 5, 10, 15, 25, 50, 75, 100, 125, 150 MIN. PLAY FOR 1, 5, 10, 15, 25 JACKPOT 15000, 20000, 50000, 70000, 100000, JACKPOT MAX 50000 150000, 200000...
  • Page 14: Chance Settings

    Chance Settings ITEMS SETTING SELECTION DEFAULT LEVEL1(Easiest), LEVEL2,LEVEL3, MAIN GAME LEVEL LEVEL 6 LEVEL4,LEVEL5,LEVEL6(Hardest) DOUBLE GAME LEVEL 85%, 90%, 95% Touch Screen Calibration 1. If a touch screen is connected, press [RECORD]> [SYSTEM]>[INTERFACE]> [TOUCH] and follow the on-screen prompts to enter the calibration screen.
  • Page 15: Game Introduction

    Press Hold-Pair button to swap the Symbols. Touch screen / Auto play support.  Main Game Feature / 1 Free Game / 2 Bonus Games  Main Game Wonderland is a 5 Reels & 25 Lines game. 3 sets of Jackpots 25 Lines Symbol Zone Credit...
  • Page 16: Jackpot

    Jackpot With 5 symbols on the screen, players win the JACKPOT 1.  With 4 symbols on the screen, players win the JACKPOT 2.  With 3 symbols on the screen, players win the JACKPOT 3.  Main Game Features The Cheshire Cat Feature : When the Cheshire Cat appears in ...
  • Page 17: Scatter Game

    Scatter Game  symbols appear in a game to trigger the Scatter Games. In the Scatter Game, players may  have a chance to enter Fire Queen Bonus Game, or Tea Party Bonus Game, or Drink Me Free Game. Fire Queen Bonus Game: A Player has 5 times in the Bonus ...
  • Page 18 Tea Party Bonus Game: Players can pick as many tea cups  as they can to win prizes. The Bonus Game end when  been picked. Drink Me Free Game : With MAX. LINE PLAY >= 50, the  will be held on the screen until there is a win paid with that During the FREE GAME,...
  • Page 19: Double Game

    Double Game After winning in a game, a player can press button to play Double  Game. Press button to select Red or Blue.  Double your wins if your guess is correct. The game ends if your guess is ...
  • Page 20: Wins Rules

    4. Wins Rules Encouraging Higher Play MIN. TOTAL PLAY JACKPOT 100% With MAX. LINE PLAY >= 50, win paid from left to right and right to left.  Odds Table...
  • Page 21: Line Chart

    Line Chart...
  • Page 22 NOTES:...
  • Page 23 NOTES:...
  • Page 24 S100US...
