Summary of Contents for IGS LEGENDARY TRIO
-
Page 3: Table Of Contents
Table of Contents 1. Hardware....................3 Hardware Connection................. 3 Connecting Touch Panel (Optional)............. 4 Connection Diagram................... 5 DIP Switch Settings..................6 36 & 10 PIN Button Layout................6 Solving Ticket SSR Error ................6 Reset ......................7 2. Bookkeeping & Adjustment............10 Access Flow Chart ................... - Page 4 Free Game....................25 Venus Help....................25 Double Game ..................26 Win Rules....................27 Encouraging Higher Play................27 Odds Table ....................27 Line Chart....................28 6. (Game 3) Captain Jack2..............29 Main Game....................29 Golden Cannon Feature ................30 Wild Wave Feature................... 31 Scatter Game ..................
-
Page 5: Hardware
1. Hardware Hardware Connection 10-Pin Connector SD Card Slot 36-Pin Connector Audio Jack A. RS-232 Connects to optional Citizen printer/ticket dispenser. * Use Belkin #F2L044 (serial printer cable/null modem) for Citizen printer. DIP Sw 2 DIP Sw 1 B. RS-232 Connects to Micro Touch compatible touch screen VGA port... -
Page 6: Connecting Touch Panel (Optional)
Connecting Touch Panel (Optional) Type A Power +5V Connector Monitor Connector (Female) (15PIN Female) Refer to the diagram below to connect the touch screen. After the connection, remember to adjust the Pin 1 of DIP SW2 to ON to enable touch mode. -
Page 7: Connection Diagram
Connection Diagram 36 Pins (6 Buttons) 10 Pins (6 Buttons) SOLDER SIDE PARTS SIDE SOLDER SIDE PARTS SIDE SPEAKER_R SPEAKER_L +12V +12V HOP-VCC T ICKET OUT T ICKET SSR T ICKET SWIT CH ST ART / ALL ST OP ST OP4/SMALL/HELP ST OP5/PLAY ST OP1/T AKE/ MENU ST OP3/DOUBLE/SELECT LINE... -
Page 8: Dip Switch Settings
DIP Switch Settings DIP SW ITCH 2 TOUCH Y ES 36 & 10 PIN Button Layout 6 Buttons S TA RT TAK E DO UBL E S M AL L P LAY A L L ST OP S TOP 1 S TOP 2 S TOP 3 S TO P 4... -
Page 9: Reset
Reset Power off the machine and then power on. Press and hold the 【 【 【 【 TEST 】 】 】 】 button until the game enters the CHECKING SYSTEM page. Enter the 「 「 「 「 TEST 」 」 」 」 page. Press the 【... - Page 10 Press the 【 【 【 【 STOP3 】 】 】 】 button to enter the 「 「 「 「 RESET 」 」 」 」 page. Press the 【 【 【 【 PLAY 】 】 】 】 button to RESET the game to default value.
- Page 11 Press the 【 【 【 【 PLAY 】 】 】 】 button again to confirm RESET or press ANY button to EXIT. After RESET is completed, it displays SYSTEM RESET COMPLETED on the screen. Power off the machine and then power on to complete the Reset procedure.
-
Page 12: Bookkeeping & Adjustment
2. Bookkeeping & Adjustment Access Flow Chart [RECO RD] [STOP2] [STOP3] [STOP4] LAST HAND SHORT-TERM SYSTEM LAST CURRENT Enter DATA DATA Pas swor d Default pass word: Press [START] 8 times [ STOP2] [ STOP3] [ STOP4] SHERWOOD HERCULES CAPTAIN JACK2 [STOP2] [STOP2] [STOP2]... -
Page 13: System Settings
System Settings ITEMS SETTING SELECTION DEFAULT MA X. LINE PLAY 2, 4, 8, 10, 15, 20 MIN. PLAY (TOTAL) 1, 5, 10, 15, 25, 50, 75, 100, 125, 150 MIN. PLAY FOR 1, 5, 10, 15, 25 JACKPOT 15000, 20000, 50000, 70000, 100000, 150000, JACKPOT MAX 50000 200000... -
Page 14: Chance Settings
Chance Settings ITEMS SETTING SELECTION DEFAULT LEVEL1(Easiest), LEVEL2,LEVEL3, MAIN GAME LEVEL LEVEL 6 LEVEL4,LEVEL5,LEVEL6(Hardest) DOUBLE GAME LEVEL 85%, 90%, 95% Touch Screen Calibration 1. If a touch screen is connected, press [RECORD]> [SYSTEM]>[INTERFACE]> [TOUCH] and follow the on-screen prompts to enter the calibration screen. -
Page 15: Introduction
3. Introduction Common Features Max. Win up to 500,000. Touch screen / Auto play support. Lobby Legendary Trio is a 3 in 1 multigame . Game Menu Credit Payout Button... -
Page 16: Game 1) Sherwood Forest
4. (Game 1) Sherwood Forest Main Game Sherw ood Forest is a 5 Reels & 25 Liners game. After collecting winning values, the winning symbols will be cleared with new symbols dropped above to fill all empty spaces, and then re-collect again if there is a win. -
Page 17: Feature
Feature Golden Arrow When the Golden Arrow appears on the 5 reel, the symbols shot by Robin Hood will be replaced with WILD symbols to increase the winning possibility. -
Page 18: Bonus Game
Bonus Game 3 SCATTER symbols appear in a game to trigger 「 「 「 「 Archery Bonus Game 」 」 」 」 Pick a money bag to shoot and win either prizes or multiplier The Bonus Game ends when “Exit” has been picked... -
Page 19: Free Game
Free Game 3 SCATTER symbols appear in a game to trigger Free Game and 10 free games will be awarded. winning times will accumulated in each free game. When the accumulated times reach the following terms, the designated symbols will become WILD symbols in a game to increase the winning possibility. -
Page 20: Double Game
Double Game After winning in a game, a player can press [DOUBLE] button to play Double Game. Press [START] button to select Robin Hood or Noble. Double your wins if your guess is correct. The game ends if your guess is wrong... -
Page 21: Win Rules
Win Rules Encouraging Higher Play MIN. PLAY JACKPOT 100% Odds Table... -
Page 22: Line Chart
Line Chart... -
Page 23: Game 2) Hercules
5. (Game 2) Hercules Main Game Hercules is a 5 Reels & 25 Liners game. can substitute for all symbols except , and symbols. -
Page 24: Feature
Feature Labours of Hercules 3 or more feature symbols in a game will trigger Labours of Hercules feature and there is a chance to win the Jackpot 1. The strength of Hercules When a player misse s the 3rd Scatter symbol in a game, there is a chance to trigger “The strength of Hercules”... -
Page 25: Scatter Game
Scatter Game symbols in a game will trigger The Choice of Hercules A player can select either BONUS GAME or FREE GAME in The Choice of Hercules... -
Page 26: Bonus Game
Bonus Game Mission： ： ： ： Lernaean Hydra There are 3 stages in the BONUS GAME & score directly. Hit Hydra to double your win and enter to the next stage! The BONUS GAME ends when EXIT is hit... -
Page 27: Free Game
Free Game Venus Help Select FREE GAME to enter the FREE GAME and 5 free spins will be awarded In each free spin, it must include one whole reel WILD in a game. If there is another whole reel WILD appears in a game, 2 whole reels WILD will be combined to in the next... -
Page 28: Double Game
Double Game After winning in a game, a player can press [DOUBLE] button to play Double Game. Press [START] button to select Hercules or Hydra. Double the wins if guess right. The game ends if guess wrong... -
Page 29: Win Rules
Win Rules Encouraging Higher Play MIN. PLAY JACKPOT 100% Odds Table... -
Page 30: Line Chart
Line Chart... -
Page 31: Game 3) Captain Jack2
6. (Game 3) Captain Jack2 Main Game Captain Jack2 is a 5 Reels & 25 Liners game. Win paid from left to right to increase the winning possibility 、 、 、 、 can substitute for all symbols except... -
Page 32: Golden Cannon Feature
Golden Cannon Feature Golden Cannon feature will be triggered when symbol appears in a game. The main game symbols hit by the pirate ship will be replaced by the displayed symbol on the pirate ship. -
Page 33: Wild Wave Feature
Wild Wave Feature Wild Wave Feature will be randomly triggered in a game and the symbols flushed by sea wave will be replaced by... -
Page 34: Scatter Game
Scatter Game symbols in a game trigger the Scatter Game. In the Scatter Game, players can select either Bonus Game or Free Game. -
Page 35: Bonus Game Stage 1
Bonus Game Stage 1 Players can pick any item on the screen and win prizes. to enter the next stage. The game ends when is picked. -
Page 36: Bonus Game Stage 2
Bonus Game Stage 2 Select one of doors and win prizes. Rescue Anne and win the biggest prize in the Bonus Game. Players can select either TAKE or RETRY in the Bonus Game and there is only one chance to RETRY. -
Page 37: Free Game
Free Game Select FREE GAME to enter the FREE GAME and 10 free spins will be awarded When the helm is rotating left or right, the symbols dropped in the sea will be replaced by There is a chance to trigger WILD WAVE feature in the FREE GAME... -
Page 38: Double Game
Double Game After winning in a game, a player can press [DOUBLE] button to play Double Game. Press [START] button to select Double your wins if your guess is correct. The game ends if your guess is wrong. -
Page 39: Win Rules
Win Rules Encouraging Higher Play MIN. PLAY JACKPOT 100% Odds Table... -
Page 40: Line Chart
Line Chart... - Page 41 V200US...
