Summary of Contents for IGS Mega Play
-
Page 3: Table Of Contents
Table of Contents 1. Hardware ..................2 Hardware Connection ..................2 Connecting Touch Panel (Optional) ..............3 Connection Diagram ..................4 DIP Switch Settings................... 5 36 & 10 PIN Button Layout................5 Solving Ticket SSR Error................... 6 Reset ......................... 7 2. -
Page 4: Hardware
1. Hardware Hardware Connection 10-Pin Connector SD Card Slot 36-Pin Connector Audio Jack A RS-232 Connects to optional Citizen printer/ticket dispenser. * Use Belkin #F2L044 (serial printer cable/null modem) for Citizen printer. DIP Sw 2 DIP Sw 1 B RS-232 Connects to Micro Touch compatible touch screen VGA port... -
Page 5: Connecting Touch Panel (Optional)
Connecting Touch Panel (Optional) Type A Power +5V Connector Monitor Connector (Female) (15PIN Female) Refer to the diagram below to connect the touch screen. After the connection, remember to adjust the Pin 1 of DIP SW1 to ON to enable touch mode. -
Page 6: Connection Diagram
Connection Diagram 36 Pins (6 buttons) 10 Pins (6 buttons) PARTS SIDE SOLDER SIDE PARTS SIDE SOLDER SIDE SPEAKER_R SPEAKER_L +12V +12V HOP-VCC TICKET OUT TICKET SSR TICKET SWITCH START / ALL STOP HELP / STOP4 PLAY / STOP5 TAKE / MENU / STOP1 SELECT LINE / STOP 3 STOP 2 COIN A... -
Page 7: Dip Switch Settings
DIP Switch Settings DIP SWITCH 1 TOUCH 36 & 10 PIN Button Layout 6 Buttons S TA R T S T O P 5 S T O P 1 S T OP 2 S T O P 3 ST OP 4 A LL STO P P LAY TA K E... -
Page 8: Solving Ticket Ssr Error
Solving Ticket SSR Error After powering on the machine, if the hopper keeps working and can’t be stopped, it could be that the Ticket SSR’s jump setting is incorrect. How to solve: 1. Locate the Ticket SSR jump (JP12) on the PC board. Then identify current TICKET SSR is at HIGH ACTIVE or LOW ACTIVE. -
Page 9: Reset
Reset Power off the machine and then power on. Press and hold the 【 TEST 】 button until the game enters the CHECKING SYSTEM page. Enter the 「 TEST 」 page. Press the 【 PLAY 】 button to enter the 「 TEST 2 」 PAGE (PAGE 2). - Page 10 Press the 【 STOP4 】 button to enter the 「 RESET 」 page. Press the 【 PLAY 】 button to RESET the game to default value.
- Page 11 Press the 【 PLAY 】 button again to confirm RESET or press ANY button to EXIT. After RESET is completed, it displays SYSTEM RESET COMPLETED on the screen. Power off the machine and then power on to complete the Reset procedure.
-
Page 12: Bookkeeping & Adjustment
2. Bookkeeping & Adjustment Access Flow Chart [RECORD] [STOP2] [STOP3] [STOP4] LAST HAND SHORT-TERM SYSTEM LAST CURRENT Enter DATA DATA Password Default password: Press [START] 8 times [STOP3] [STOP2] [STOP4] HALLOWIN ROBIN HOOD WILD RIDER [STOP4] [STOP3] [STOP2] INTERFACE ADJUSTMENT MAIN GAME [STOP1] [STOP2]... -
Page 13: System Settings
System Settings ITEMS SETTING SELECTION DEFAULT 1, 1 x MAX LINE, 2 x MAX LINE, 3 x MAX LINE, MIN. PLAY / TOTAL 1 x MAX LINE 4 x MAX LINE, 5 x MAX LINE, 6 x MAX LINE MAX. PLAY / TOTAL 100,200,300,400,500 40,60 MIN. -
Page 14: Chance Settings
Chance Settings ITEMS SETTING SELECTION DEFAULT LEVEL1(Easiest), LEVEL2,LEVEL3, MAIN GAME LEVEL LEVEL 6 LEVEL4,LEVEL5,LEVEL6(Hardest) Touch Screen Calibration 1. If a touch screen is connected, press [RECORD]> [SYSTEM]>[INTERFACE]> [TOUCH] and follow the on-screen prompts to enter the calibration screen. 2. Touch center of the cross on the screen for 3 seconds. -
Page 15: Introduction
3. Introduction Common Features Max. Win up to 500,000. When collecting 3 Jackpot Symbols in the main game reel, players win the Jackpot. Touch screen / Auto play support. Lobby MegaPlay is a 3 in 1 multigame . 2 sets of Jackpots Games Credit... -
Page 16: Game 1) Robin Hood
4. (Game 1) Robin Hood Main Game Robin Hood is a 5 Reels & 25 Liners game. After collecting winning values, the winning symbols will be cleared with new symbols dropped above to fill all empty spaces, and then re-collect again if there is a win. -
Page 17: Feature
Feature Golden Arrow When the Golden Arrow appears on the 5 reel, the symbols shot by Robin Hood will be replaced with WILD symbols to increase the winning possibility. - Page 18 Free Game 3 SCATTER symbols appear in a game to trigger Free Game and 10 free games will be awarded. winning times will accumulated in each free game. When the accumulated times reach the following terms, the designated symbols will become WILD symbols in a game to increase the winning possibility.
-
Page 19: Win Rules
Win Rules Odds Table Line Chart... -
Page 20: Game 2) Hallowin
5. (Game 2) HalloWin Main Game HalloWin is a 5 Reels & 20 Liners game. only appears in the Main Game and substitutes for all symbols. -
Page 21: Feature
Feature Free Game 3 or more trigger FREE GAME. only appears in the Free Game and substitutes symbols except When appears in the FREE GAME, moves forward each spin and collect the wins until jumps out from the first reel FREE GAME finished. -
Page 22: Win Rules
Win Rules Odds Table Line Chart... -
Page 23: Game 3) Wild Rider
6. (Game 3) Wild Rider Main Game Wild Rider is a 15 Reels & 20 Liners game. -
Page 24: Feature
Feature Respin Feature 、 、 When one of the symbols ( 、 、 ) appear on the left 3 reels to trigger RESPIN FEATURE. The defined symbol and WILD symbol will be held on screen after each respin, and then other symbols will re-spin again. - Page 25 Wild Rider Feature appears on the first 3 reels to trigger WILD RIDER FEATURE, and then RESPIN. The symbol after RESPIN will make the same symbols on screen become WILD symbols to increase the winning possibility.
-
Page 26: Win Rules
Win Rules Odds Table All Same Odds... - Page 27 Line Chart...
- Page 28 V106US...
