Summary of Contents for IGS Aladdin's Adventure

  • Page 3: Table Of Contents

    Table of Contents 1. Hardware ..................2 Hardware Connection ..................2 Connecting Touch Panel (Optional) ..............3 Connection Diagram ..................4 DIP Switch Settings................... 5 36 & 10 PIN Button Layout................6 Solving Ticket SSR Error................... 6 Reset ......................... 7 2.

  • Page 4: Hardware

    1. Hardware Hardware Connection 10-Pin Connector SD Card Slot 36-Pin Connector Audio Jack A. RS-232 Connects to optional Citizen printer/ticket dispenser. * Use Belkin #F2L044 (serial printer cable/null modem) for Citizen printer. DIP Sw 2 DIP Sw 1 B. RS-232 Connects to Micro Touch compatible touch screen VGA port...

  • Page 5: Connecting Touch Panel (Optional)

    Connecting Touch Panel (Optional) Type A Power +5V Connector Monitor Connector (Female) (15PIN Female) Refer to the diagram below to connect the touch screen. After the connection, remember to adjust the Pin 1 of DIP SW2 to ON to enable touch mode.

  • Page 6: Connection Diagram

    Connection Diagram 36 Pins (6 Buttons) 10 Pins (6 Buttons) SOLDER SIDE PARTS SIDE SOLDER SIDE PARTS SIDE SPEAKER_R SPEAKER_L +12V +12V HOP-VCC TICKET OUT TICKET SSR TICKET SWITCH START / ALL STOP STOP4/SMALL/HELP STOP5/PLAY STOP1/TAKE STOP3/DOUBLE/SELECT LINE STOP2/BIG/HOLD PAIR COIN A KEY IN COIN C...

  • Page 7: Dip Switch Settings

    DIP Switch Settings DIP SWITCH 1 SLAVE ID LINK SINGLE MODE LINK...

  • Page 8: 10 Pin Button Layout

    DIP SWITCH 2 TOUCH 36 & 10 PIN Button Layout 6 Buttons S TA R T TA K E B I G D OU B L E S M A L L P L AY A L L ST O P S T O P 1 S T OP 2 S T OP 3...

  • Page 9: Reset

    Reset Power off the machine and then power on. Press and hold the 【 TEST 】 button until the game enters the CHECKING SYSTEM page. Enter the 「 TEST 」 page. Press the 【 PLAY 】 button to enter the 「 TEST 2 」 PAGE (PAGE 2).
  • Page 10 Press the 【 STOP3 】 button to enter the 「 RESET 」 page. Press the 【 PLAY 】 button to RESET the game to default value.
  • Page 11 Press the 【 PLAY 】 button again to confirm RESET or press ANY button to EXIT. After RESET is completed, it displays SYSTEM RESET COMPLETED on the screen. Power off the machine and then power on to complete the Reset procedure.

  • Page 12: Bookkeeping & Adjustment

    2. Bookkeeping & Adjustment Access Flow Chart [RECORD] [STOP2] [STOP3] [STOP4] LAST HAND SHORT-TERM SYSTEM LAST CURRENT Enter DATA DATA Password Default password: Press [START] 8 times [STOP3] [STOP2] DOUBLE GAME MAIN GAME [STOP1] [STOP2] [STOP3] [STOP4] INTERFACE MAIN GAME DOUBLE GAME ADJUSTMENT [STOP2]...

  • Page 13: System Settings

    System Settings ITEMS SETTING SELECTION DEFAULT MAX. LINE PLAY 2, 4, 8, 10, 15, 20 MIN. PLAY(TOTAL) 1, 5, 10, 15, 25, 50, 75, 100, 125, 150 MIN. PLAY FOR 1, 5, 10, 15, 25 JACKPOT 15000, 20000, 50000, 70000, 100000, 150000, JACKPOT MAX 50000 200000...

  • Page 14: Chance Settings

    Chance Settings ITEMS SETTING SELECTION DEFAULT LEVEL1(Easiest), LEVEL2,LEVEL3, MAIN GAME LEVEL LEVEL 6 LEVEL4,LEVEL5,LEVEL6(Hardest) DOUBLE GAME LEVEL 85%, 90%, 95% Touch Screen Calibration 1. If a touch screen is connected, press [RECORD]> [SYSTEM]>[INTERFACE]> [TOUCH] and follow the on-screen prompts to enter the calibration screen.

  • Page 15: Game Introduction

    3. Game Introduction Features 25 Lines. Max. Win Up to 600,000. When 5/4/3 Jackpot symbols appear in a game, players win the Jackpot 1/2/3. Hold Pair Feature: Select the desired Hold Symbol and Re-spin the symbols you don ’ t want. Press Hold-Pair button to swap the Symbols. Touch screen / Auto play support.

  • Page 16: Jackpot

    Jackpot With 5 symbols on the screen, players win the JACKPOT 1. With 4 symbols on the screen, players win the JACKPOT 2. With 3 symbols on the screen, players win the JACKPOT 3. Main Game Features Lamp Genie Feature : Lamp Genie will appear during the main game and randomly hit symbols.

  • Page 17: Scatter Game

    Aladdin Feature : Aladdin will appear randomly in the main game and gives players a surprise. Scatter Game Lamp Scatter Game will be activated when 3 or more symbols appear in a game. In the Lamp Scatter Game, players may have a chance to win prizes directly, or enter the Aladdin’s Gold Bonus Game or Lamp Genie Free Game.
  • Page 18 Aladdin’s Gold Bonus Game: The First Stage ： players can pick golden Jars and win prizes until “Exit” has been picked. Get “UP” or “TAKE ALL” to enter to the Second Stage. The Second Stage ： players can pick the golden chests for bigger prizes until “Exit”...
  • Page 19 Lamp Genie Free Game : During the Lamp Genie Free Game, all the appeared will be collected in the right upper corner. When the free game is finished, all the collected will become Wild symbols and return randomly to the reels for one more last spin.

  • Page 20: Double Game

    Double Game Choose Lamp Genie or Aladdin to double the winning.

  • Page 21: Wins Rules

    4. Wins Rules Encouraging Higher Play Jackpot Odds Table...

  • Page 22: Line Chart

    Line Chart...
  • Page 23 S102US...
