  • Page 3: Table Of Contents

    Table of Contents 1. Hardware ..................2 Hardware Connection ..................2 Connecting Touch Panel (Optional) ..............3 Connection Diagram ..................4 DIP Switch Settings ................... 5 36 & 10 PIN Button Layout................6 Solving Ticket SSR Error ................... 6 Reset ......................... 7 2.

  • Page 4: Hardware

    1. Hardware Hardware Connection 10-Pin Connector SD Card Slot 36-Pin Connector Audio Jack A. RS-232 Connects to optional Citizen printer/ticket dispenser. * Use Belkin #F2L044 (serial printer cable/null modem) for Citizen printer. DIP Sw 2 DIP Sw 1 B. RS-232 Connects to Micro Touch compatible touch screen VGA port...

  • Page 5: Connecting Touch Panel (Optional)

    Connecting Touch Panel (Optional) Type A Power +5V Connector Monitor Connector (Female) (15PIN Female) Refer to the diagram below to connect the touch screen. After the connection, remember to adjust the Pin 1 of DIP SW2 to ON to enable touch mode.

  • Page 6: Connection Diagram

    Connection Diagram 36 Pins (6 Buttons) 10 Pins (6 Buttons) SOLDER SIDE PARTS SIDE SOLDER SIDE PARTS SIDE SPEAKER_R SPEAKER_L +12V +12V HOP-VCC TICKET OUT TICKET SSR TICKET SWITCH START / ALL STOP STOP4/SMALL/HELP STOP5/PLAY STOP1/TAKE STOP3/DOUBLE/SELECT LINE STOP2/BIG/HOLD PAIR COIN A KEY IN COIN C...

  • Page 7: Dip Switch Settings

    DIP Switch Settings DIP SWITCH 1 SLAVE ID SINGLE LINK MODE LINK...

  • Page 8: 10 Pin Button Layout

    DIP SWITCH 2 TOUCH 36 & 10 PIN Button Layout 6 Buttons S TA R T TA K E B IG D O U B L E S M A L L P L AY A L L S T O P S T O P 1 S T O P 2 S T O P 3...

  • Page 9: Reset

    Reset Power off the machine and then power on. Press and hold the 【 【 【 【 TEST 】 】 】 】 button until the game enters the CHECKING SYSTEM page. Enter the 「 「 「 「 TEST 」 」 」 」 page. Press the 【...
  • Page 10 Press the 【 【 【 【 STOP3 】 】 】 】 button to enter the 「 「 「 「 RESET 」 」 」 」 page. Press the 【 【 【 【 PLAY 】 】 】 】 button to RESET the game to default value.
  • Page 11 Press the 【 【 【 【 PLAY 】 】 】 】 button again to confirm RESET or press ANY button to EXIT. After RESET is completed, it displays SYSTEM RESET COMPLETED on the screen. Power off the machine and then power on to complete the Reset procedure.

  • Page 12: Bookkeeping & Adjustment

    2. Bookkeeping & Adjustment Access Flow Chart [RECORD] [STOP2] [STOP3] [STOP4] LAST HAND SHORT-TERM SYSTEM LAST CURRENT Enter DATA DATA Password Default password: Press [START] 8 times [STOP3] [STOP2] DOUBLE GAME MAIN GAME [STOP1] [STOP2] [STOP3] [STOP4] INTERFACE MAIN GAME DOUBLE GAME ADJUSTMENT [STOP2]...

  • Page 13: System Settings

    System Settings ITEMS SETTING SELECTION DEFAULT MAX. LINE PLAY 2, 4, 8, 10, 15, 20 MIN. PLAY(TOTAL) 1, 5, 10, 15, 25, 50, 75, 100, 125, 150 MIN. PLAY FOR 1, 5, 10, 15, 25 JACKPOT 15000, 20000, 50000, 70000, 100000, 150000, JACKPOT MAX 50000 200000...

  • Page 14: Chance Settings

    Chance Settings ITEMS SETTING SELECTION DEFAULT LEVEL1(Easiest), LEVEL2,LEVEL3, MAIN GAME LEVEL LEVEL 6 LEVEL4,LEVEL5,LEVEL6(Hardest) DOUBLE GAME LEVEL 85%, 90%, 95% Touch Screen Calibration 1. If a touch screen is connected, press [RECORD]> [SYSTEM]>[INTERFACE]> [TOUCH] and follow the on-screen prompts to enter the calibration screen.

  • Page 15: Introduction

    Hold Pair Feature: When there is no win in a game, a player can press Hold Pair button to keep the desired symbol and then re-spin again with the same played amount Main Game DAY OF THE DEAD is a 5 Reels & 25 Lines game 3 sets of Jackpots 25 Lines...

  • Page 16: Shuffle Feature

    Shuffle Feature Shuffle feature is randomly triggered. Once triggered, various combinations appear and a new one will replace the current result to give bigger prizes.

  • Page 17: Catrina Feature

    Catrina Feature Catrina Feature will be triggered when appears in a game. When it triggers, and the selected symbols will respin which may have a chance to turn them into WILDs. After respin, the Catrina feature will be triggered again when appears again.

  • Page 18: Scatter Game

    Scatter Game 3 or more symbols can trigger Scatter Game. Players can select to play Bonus Game or Free Game.

  • Page 19: Bonus Game

    Bonus Game award 3 spin times in the Bonus Game. award 4 spin times in the Bonus Game. award 5 spin times in the Bonus Game. Each spin players win the prize pointed by the indicator. After each spin, winning grid and the grids next to winning grid will be added the winning points before next spin.

  • Page 20: Free Game

    Free Game award 5 free games. award 7 free games. award 10 free games. During the Free Games, Catrina Feature may trigger more frequently.

  • Page 21: Double Game

    Double Game After winning in a game, a player can press [DOUBLE] button to play Double Game. Press [START] button to select Double your wins if your guess is correct. The game ends if your guess is wrong.

  • Page 22: Win Rules

    Win Rules Encouraging Higher Play MIN. PLAY JACKPOT 100% Odds Table...

  • Page 23: Line Chart

    Line Chart...
  • Page 24 S100US...
