  • Page 2 Following is a guide to quickly install and operate your ServSwitch. Refer to the connection diagram on the following page. 1- Connect your CPUs to the ServSwitch using an appropriate CPU Adapter Cables. Connect the DB25M end of the CPU Adapter Cable to the DB25F connector labeled CPU x on the ServSwitch’s rear panel.
  • Page 3 Below shows a basic example of connecting a CPU, a keyboard. A monitor, and a mouse to the ServSwitch. Connections will vary depending on the types of equipment you are installing.
