- Page 1 Robot Vacuum Cleaner C30B English Deutsch Français Español Scan to download Português Română Pусский manuals in more languages Robot Vacuum Cleaner Instruction Manual Please read this manual carefully before using the product and keep it safe.
-
Page 2: Table Of Contents
Contents Download APP APP Using Safety Regulation and Warning Product Composition / Package Contents Product Composition / Part Name 11-12 Product Usage / Preparation Product Use / Host Charging Product Use / Start Cleaning 15-16 Product Use / Pause, Wake up and Shut down Product Use / Schedule Settings Product Usage / Water Tank Use Component Maintenance / Dust Box... -
Page 3: Download App
Please read this manual carefully before use. Please follow up the manual during operation for your safe. There are wifi-version and non-wifi version of our C30B model. If your robot is wifi-version, please read the Quick Guide for APP Using in the next page; If your robot is non-wifi version, please skip the page of Quick Guide for APP Using. -
Page 4: App Using
Quick Guide for App Using For Wifi-version C30B only 1. App Downloading Search “Tuya” from your APPSTORE or google play; download the APP [Fig 1]; Open “Tuya” on your cellphone after download [Fig 2]; Register an account via email or cell phone number [Fig 3] (tap the right Verification Code and Set up a password for your Tuya ID [Fig 4]);... - Page 5 Quick Guide for App Using For Wifi-version C30B only Tap + on the top right corner to add device [Fig 6]; Tap Small Home Appliance [Fig 7]; Choose Robot Vacuum [Fig 8]; Click Confirm indicator rapidly blink [Fig 9]; Type your WIFI Password [Fig 10] and start device connection [Fig 11]; Adding device succeeded [Fig 12].
- Page 6 Quick Guide for App Using For Wifi-version C30B only Rename your device, e,g. Robot C30B [Fig 13]; Start using App to control your robot [Fig 14]. Fig 11 Fig 12 Fig 13 Fig 14 Fig 15...
- Page 7 Quick Guide for App Using For Wifi-version C30B only 2. APP Operation You may click "Auto cleaning", "Recharge mode", "Room cleaning", "Edge cleaning", "Spot cleaning" as you want to start certain cleaning mode [Fig 15] [Fig 16]; Choose Cleaning strength to enter suction power setting interface [Fig 17];...
- Page 8 Quick Guide for App Using For Wifi-version C30B only 4. Start / Pause / Standby / Sleeping mode Press “ ” / “ ” to start / pause the robot [Fig 21]; Note: When the robot pauses over 10 minutes, it will enter sleeping mode;...
- Page 9 Quick Guide for App Using For Wifi-version C30B only 6. Find robot You may not know where the robot is when it finishes cleaning and stops. Then press “Positioning of ” [Fig 24]; then there is “Ding Dong” sound prompt for you to find the robot.
- Page 10 Quick Guide for App Using For Wifi-version C30B only 8. Supported Third-party Control The robot works with Amazon Alexa, Google Assistant, and some other third part control devices.Tap in the top right corner [Fig 27], then find "Supported Third-party Control" and tap corresponding icon to learn connection way [Fig 28].
-
Page 11: Safety Regulation And Warning
Safety Regulation Before using this product, please read the following safety instructions and follow all the safety precautions. Please read the instructions carefully. Please keep this instuctions. Any operation inconsistent with this instruction manual may cause damage to this product. Note: Warning: Only authorized technicians can disassemble this product. -
Page 12: Product Composition / Package Contents
Product Composition / Package Contents Host Charging Station Dust Box Side Brushes... -
Page 13: Product Composition / Part Name
Product Composition / Part Name Bottom Ground Sensor Left Side Brush Right Side Brush Left Wheel Right Wheel Start / Pause key Dust box Surface Cover Omnidirectional Lens Charging Pole Piece Dust Box / Water Tank Button Universal Wheel Battery Cover Rolling Brush Assembly... - Page 14 Dust box Charging Station Signal lndicator HEPA Filter HEPA Filter Cover Primary Filter Strainer DC Socket Conductive Shrapnel Dust Box Metal Sheet Dust Box Side Cover Charging Pole Piece Water Tank and Mop Assembly Remote Control Display Screen Water lnjection Auto Cleaning Mode / Powerful Mode Switching (Mopping Mode /...
-
Page 15: Product Usage / Preparation
Product Usage / Preparation Remove Protection Before using the host, remove the protective strip on the host and the protective film on the charging station. Remove the protective strip Remove protective film... -
Page 16: Product Use / Host Charging
Product Use / Host Charging Charging attention: Placing and charging: The charging station is against the wall and placed on a flat ground. Do not place articles within the 1. Charging: Place the host on the charging station for charging. range of 0.5m left and right and 1.5m ahead. -
Page 17: Product Use / Start Cleaning
Product Use / Start Cleaning According to different cleaning needs, the product has a Mopping Mode variety of cleaning modes to choose from. You can start Applicable scenario: Used to do wet & dry mopping. various cleaning modes through a host, remote control or app. Setting method: Install the water tank to the host and press the Automatic Cleaning start button... - Page 18 Border Sweeping Applicable scenario: For indoor border cleaning, the host cleans along the perimeter of fixed objects (such as walls), and returns to the charging station after the border cleaning finished. Setting method: Click the remote control mode switch button ) to select the border cleaning mode to start the border cleaning.
-
Page 19: Product Use / Pause, Wake Up And Shut Down
Product use / pause, wake up and shut down Pause: During the operation of the host, press the host button or the pause button on the remote controller or app to pause the host. Wake up: If the host stops working for more than ten minutes, it will automatically enter into sleep mode (all the host lights are off). You can wake up the host by pressing the host button or any button on the remote controller, or the button on app. -
Page 20: Product Usage / Water Tank Use
Product Use / Water Tank Use Do not use the floor mopping function on carpets. After mopping the floor, please empty the water tank in time and remove the mop. Add water Install the Water Tank Assembly Install Mop Start Mopping the Floor... -
Page 21: Component Maintenance / Dust Box
Component maintenance / dust box C. Dumping the rubbish. A．Press the dust box button to take out the dust box; B．Open the dust box side cover; D. Open the HEPA Filter cover;... - Page 22 G．The dust box should be scrubbed with mop; Open the HEPA filter cover and take out the HEPA filter and the primary filter. It is not recommended to wash the HEPA filter by water. Tap gently to remove the dust; F．Rinse the primary filter;...
- Page 23 H．Dry the dust box and filter assembly and keep it dry to ensure its service life; I. Replace the primary filter and the HEPA filter into the dust box; Note: 1. Before installing the filters, please ensure that the HEPA filter and the primary filter are in dry state. 2.
-
Page 24: Component Maintenance / Water Tank And Mop
Component maintenance / water tank and mop How to clean the rubbish in the dustbin of the water tank 1.Take out the water tank 4.Washing mop; 1. Put the water tank horizontally with the assembly; dustbin port upside. 2. Clean up the rubbish in the dustbin of the 5. -
Page 25: Component Maintenance / Roller Brush And Side Brushes
Component maintenance / roller brush and side brush 1．Open the roller brush cover assembly; 3. Use the cleaning brush to cut off the hair tangled on the roller brush; 2．Take out the roller brush shaft; 4. Clean the side brush. -
Page 26: Component Maintenance / Charging Pole Pieces, Ground Sensors, Drive Wheels And Universal Wheel
Component maintenance / charging pole pieces, ground sensors, drive wheels and universal wheel Friendly Reminder: The interior of the charging pole pieces, the ground sensors and the front bumper all contain sensitive electronic components. Please use dry mop to clean the above parts and do not use wet mop to prevent damage caused by water inflow. Clean the charging pole pieces. -
Page 27: Trouble Shooting And Resolutions
Investigation of common problems Prompt Tone Cause of Failure Solution Please put the host back to the ground and press the Wheels off the ground. Host suspended. cleaning key again. Replace the dustbin to the host and press the cleaning Dust box not installed. -
Page 28: Product Parameter
Product Parameter Parameter Classification Item 330 mm Diameter Structural class 74mm Height 2.7 kg Net weight 14.4 volts Voltage Battery 2500 mah rechargeable lithium battery pack Battery 600 ml Bin capacity Automatic charging / manual charging Charging type Sweeping parameter Auto/ Schedule/ Single room/ Fixed point/ Border/ Mop floor Cleaning mode About 300 minutes... -
Page 29: Harmful Substances
Harmful Substances Description: This form is prepared in accordance with the provisions of SJ/T 11364. Indicates that the content of the hazardous substance in all homogeneous materials of the part is below the limit requirement specified in the current valid version of GB/T26572. It indicates that the content of the hazardous substance in at least one of the homogeneous materials of the part exceeds the limit requirement stipulated in the current effective version of GB/T26572, and there is no mature alternative in the industry, which meets the environmental protection requirements of the EU RoHS Directive.
