Summary of Contents for Shuttle HOT-565
- Page 1 HOT-565 Pentium processor ™ Based PCI MAIN BOARD User's Manual HOT- 565 User's Manual 1...
- Page 2 FCC Notice: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 3: Table Of Contents
Specification....................5 ..........7 HAPTER ARDWARE ONFIGURATION HOT-565 Layout..................7 Jumpers......................8 CPU Clock Speed Selection - JP36, JP23, JP24 and JP42 ......8 Onboard Regulators Output - J100, J101, J103 and JP43 ......10 Flash EPROM Jumper - JP19..............1 1 Clear CMOS - JP40.................. -
Page 4: Preface
RAM, Standard Fast Page DRAM and SDRAM in standard 72-pin SIMM socket and 168-pin 3.3 V DIMM socket. HOT-565 provides a new level of I/O integration. Intel's 82430TX PCIset chipset provides increased integration and improved performance over other chipset designs. The 82430TX PCIset chipset provides an integrated Bus Mastering IDE controller with two high performance Ultra 33 DMA IDE interfaces for up to four IDE devices. -
Page 5: Chapter 1 Introduction
Introduction Chapter Specification CPU Function Pentium P54C/P55C-MMX™ processors : 75~233MHz Cyrix/IBM 6x86/L processors : PR120~PR166 AMD K5/K6 processors : PR75~PR233 Chipset Intel PCIset 82439TX and 82371AB Memory Supports two banks of EDO, Fast Page Mode DRAM or 3.3V Sync. DRAM ranging from 8MB to 256MB Supports 4MB, 8MB, 16MB, 32MB and 64MB 72-pins SIMMs or 8MB, 16MB, 32MB, 64MB and 128MB 168-pin DIMMs... - Page 6 Expansions 32-bit PCI bus slot x 4 16-bit ISA bus slot x 3 2-channel PCI IDE port - Support up to 4 IDE devices - PIO Mode 4, DMA Mode 2 transfers up to 22 MB/sec - Supports "Ultra 33" synchronous DMA mode transfer tup to 33 Mbytes/sec - Integrated 8 x 32-bit buffer for PCI IDE burst transfers One floppy port...
-
Page 7: Chapter 2 Hardware Configuration
Hardware Configuration Chapter HOT-565 Layout HOT- 565 User's Manual 7... -
Page 8: Jumpers
JP36 is a 6-pins jumper which determine the system clock frequency from 50 MHz to 66 MHz. HOT-565 mainboard also provides Jumpers JP23 and JP24 to figure the CPU core clock multiplier. By inserting jumper caps on JP23 and JP24, the user can change the Host Bus Clock/CPU Core Clock ratio from 1 : 1.5 to 1 : 3.5. - Page 9 CPU Clock Configuration Frequency System Processors JP36 Multiplier Clock / Multiplier JP23, JP24 Pentium MMX 233 MHz Pentium 100 MHz 66 MHz AMD-K6 PR2-233 x 1.5 / x 3.5 AMD-K5 PR100/133 Pentium/MMX 200 MHz 66 MHz AMD-K6 PR2-200 AMD-K5 PR200 Pentium/MMX 166 MHz 66 MHz AMD-K6 PR2-166 MHz...
-
Page 10: Onboard Regulators Output - J100, J101, J103 And Jp43
Onboard Regulator Output- J100, J101, J103 and JP43 These jumpers set the voltage supplied to the processor. Intel Pentium processors has only a Single Power Plane and uses the standard 3.3V(STD), AMD K5 and Cyrix/IBM 6x86 has also have a single power plane and use 3.52V. -
Page 11: Flash Eprom Jumper - Jp19
Flash EPROM Jumper - JP19 HOT-565 mainboard supports two types of flash EPROM: 5 volt and 12 volt. By setting up jumper JP19, you can update both types of flash EPROM with new system BIOS files as they come available. -
Page 12: Connectors & Sockets
Connectors & Sockets Connectors & Sockets ITEM FUNCTION ITEM FUNCTION J2, 3, 4, 5 On-board SIMM sockets Power LED and Keylock Connector DIM1, 2 On-board 3.3V DIMM sockets PC Speaker Connector J23, 17, 18, On-board PCI Slots JP12 Hardware Reset Switch Connector J20, 21, 22 On-board ISA Slots JP33... - Page 13 The main board provides a on-board 12V cooling fan power connector for cooling fan. Please make sure the red wire connect to +12V and black wire connect to ground (GND). Do not short 12V and GND pin of JP1 by a Caution : jumper cap or it will cause serve damage to the main board.
-
Page 14: Chapter 3 Memory Configuration
Memory Configuration Chapter The HOT-565 mainboard provides four 72-pin SIMM sockets and two 168- pin DIMM sockets that make it possible to install up to 256MB of RAM. The SIMM socket support 4MB, 8MB, 16MB, 32MB and 64MB 5V single- or double-side fast page or EDO DRAM modules, and DIMM socket support 8MB, 16MB, 32MB, 64MB, and 128MB 3.3V single- or double-side... - Page 15 Table 3-1. Memory Configuration Table SIMM 1 SIMM 2 SIMM 3 SIMM 4 DIMM 1 DIM 2 TOTAL 4 MB 4 MB —— —— —— —— 8 MB 4 MB 4 MB 4 MB 4 MB —— —— 16 MB 8 MB 8 MB ——...
-
Page 16: Chapter 4 Award Bios Setup
Award BIOS Setup Chapter HOT-565 BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed RAM so that it retains the Setup information when the power is turned off. -
Page 17: The Main Menu
The Main Menu Standard CMOS setup This setup page includes all items in a standard compatible BIOS. BIOS features setup This setup page includes all items of Award special enhanced features. Chipset features setup This setup page includes all items of chipset features. Power Management Setup This setup page includes all items of Power Management features. - Page 18 Load Setup Defaults Setup defaults loads the values required by the system for the O.K. performance. However, you can change the parameter through each Setup Menu. Integrated Peripherals This setup page includes all items of peripheral features. IDE HDD auto detection Automatically configure IDE hard disk drive parameters.
-
Page 19: Standard Cmos Setup
Standard CMOS Setup Date The date format is <day>, <month> <date> <year>. Press <F3> to show the calendar. Time The time format is <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example. 5 p.m. is 17:00:00. Hard Disks Type This item identify the types of hard disk drives that has been installed in the computer. - Page 20 drives parameter when system power-on. If a hard disk drive has not been installed select NONE and press <Enter>. Drive A type/Drive B type This item specifies the types of floppy disk drive A or drive B that has been installed in the system.
-
Page 21: Bios Features Setup
BIOS Features Setup CPU Internal/External Cache This item enables CPU internal cache and external cache to speed up memory access. Quick Power On Self Test This item speeds up Power On Self Test (POST) after you power on the computer. If it is set to Enabled, BIOS will shorten or skip some check items during POST. - Page 22 Boot Up NumLock Status When this option enables, BIOS turns on Num Lock when system is powered on. Boot Up System Speed This option sets the speed of the CPU at system boot time. The settings are High or Low. Typematic Rate Setting/Typematic Rate/Typematic Delay This determines if the typematic rate and typematic delay are to be used.
-
Page 23: Chipset Features Setup
Chipset Features Setup Auto Configuration This item auto configures the following items: DRAM Leadoff Timing, DRAM Read Burst, DRAM Write Burst Timing, Fast EDO Lead off and Refresh RAS# Assertion. DRAM Timing This item set the DRAM Read/Write timings that the system uses. When item, "Auto Configuration", is disabled, this item will not show up. - Page 24 Fast EDO Lead off This item is used to defined which fast path is selected for CPU to DRAM read cycles for the leadoff, the options are " E nable" or "Disable". Refresh RAS# Assertion This item is used to set the number of clocks RAS# is asserted for Refresh cycles.
- Page 25 Video BIOS Cacheable This item allows the user to set the video BIOS C000~C7FF areas that are cacheable or non-cacheable. 8 Bit I/O Recovery Time The recovery time is the length of time, measured in CPU clocks, that the system will delay after the completion of an input/output request. This delay takes place because the CPU is operating more than the input/output bus that the CPU must be delayed to allow for the completion of the I/O.
-
Page 26: Power Management Setup
Power Management Setup Power Management This item determines the options of the power management function. Max Saving puts the system into power saving mode after a brief period of system inactivity; Min Saving is the same as Max Saving except the time of the system inactivity period is longer;... - Page 27 HDD Power Down defines the continuous HDD idle time before the HDD enters This item power saving mode (motor off). The options are from 1 min to 15 min and Disabled. VGA Active Monitor If this item is set to Enabled, the VGA activity event will be monitored to reload global timer.
-
Page 28: Pci Configuration Setup
PCI Configuration Setup PNP OS Installed When this item is set to Yes, it will allow the PnP OS(Windows 95) control the system resources except PCI devices and PnP boot devices. Default setting is No. Resources Controlled By The Award Plug and Play BIOS has the capability to automatically configure all of the boot and Plug and Play compatible devices. - Page 29 DMA 0/1/3/5/6/7 assigned to These items allow you to determine the DMA assigned to the ISA bus and is not available for PCI slot. Choices are Legacy ISA and PCI/ISA PnP. PCI IRQ Activated by This item sets the method by which the PCI bus recognize that an IRQ service is being requested by a device.
-
Page 30: Integrated Peripherals
Integrated Peripherals IDE HDD Block Mode This item is used to set IDE HDD Block Mode. If your IDE Hard Disk supports block mode, then you can enable this function to speed up the HDD access time. If not, please disable this function to avoid HDD access error. - Page 31 Onboard FDC Control This item specifies onboard floppy disk drive controller. This setting allows you to connect your floppy disk drives to the onboard floppy connector. Choose the "Disabled" settings if you have a separate control card. Onboard UART1/2 This item is used to define onboard serial port 1/Port2 to 3F8/IRQ4, 2F8/ IRQ3, 3E8/IRQ4, 2E8/IRQ3, Auto or Disabled.
-
Page 32: Password Setting
Password Setting This section describes the two access modes that can be set using the options found on the Supervisor Password and User Password. Supervisor Password and User Password The options on the Password screen menu make it possible to restrict access to the Setup program by enabling you to set passwords for two different access modes: Supervisor mode and User mode. - Page 33 Password Disable If you select System at Security Option of BIOS Features Setup Menu, you will be prompted for the password every time the system is rebooted or any time you try to enter Setup. If you select Setup at Security Option of BIOS Features Setup Menu, you will be prompted only when you try to enter Setup.
