Installing an Alarm Option Kit
These technical instructions provide details on installing an Alarm Option Kit on a March Networks 4000
Series recorder. The alarm and switch module, which is included in the Alarm Option Kit, is an external
device that provides additional inputs and outputs for connection to optional alarm and switch devices.
After you connect alarm and switch devices to the module, use the software applications to enable and
configure the devices, as required. For more information, see "Accessing the Recorder and Connected
Devices" on page 4.
WARNING!
Before you install an alarm and switch module, ensure you power down the recorder. For more
information see the installation guide accompanying the unit.
For 4000 Series DVRs, ensure the unit is running release 3.5 or later. For information about
determining the release, see the description of the showvers command in the Provisioning
Interface Technical Instructions. If the unit is running an earlier release, upgrade steps are
provided in the Upgrade Technical Instructions. Both publications are included on your March
Networks software CD.
The switch contact closure is designed to work only with low voltage devices. A rating of 30 volts
DC should never be exceeded. Also, the switch load should never exceed 1 amp. If you are unsure
about these specifications, consult an electrician before installing a switched device.
Unpacking the Alarm Option Kit
Ensure the following items are located within the packaging:
Alarm and switch module (with installed mounting screws and lock washers)
20-pin terminal blocks (qty: 2)
Ω
200
end-of-line resistors (qty: 16)
CD-13887 Rev. 5.0 - February 1, 2006
TECHNICAL INSTRUCTIONS
Installing an Alarm Option Kit
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for March Networks CD-13887
Summary of Contents for March Networks CD-13887
- Page 1 TECHNICAL INSTRUCTIONS Installing an Alarm Option Kit These technical instructions provide details on installing an Alarm Option Kit on a March Networks 4000 Series recorder. The alarm and switch module, which is included in the Alarm Option Kit, is an external device that provides additional inputs and outputs for connection to optional alarm and switch devices.
- Page 2 Figure 2: Alarm and Switch Module Terminal Diagram CO M CO M CO M CO M ALA RMS SW ITCHE S CO M CO M NO 1 NO 4 CO M CD-13887 Rev. 5.0 - February 1, 2006 Installing an Alarm Option Kit Page 2...
- Page 3 If the terminal block is not attached to the alarm and switch module, slide the terminal block into the lower slot. After you connect all of the switch devices, you can turn on the unit. Diagram Terminal Blocks Switch Terminals CD-13887 Rev. 5.0 - February 1, 2006 Installing an Alarm Option Kit Page 3...
- Page 4 Accessing the Recorder and Connected Devices After you connect devices and apply power to the recorder, use the March Networks software applications to enable and configure the devices. Depending on the recorder model, the software applications you use to access the devices vary, as outlined...
