- Page 1 March Networks 8000 Series Hybrid NVR - 32/16 Channel Models 8732 R, 8532 R or S, 8516 R or S INSTALLATION GUIDE...
- Page 2 Information in this document is subject to change without notice. MARCH NETWORKS, March Networks Command, March Networks Searchlight, March Networks RideSafe, and the MARCH NETWORKS logo are trademarks of March Networks Corporation. Infinova is a trademark of Infinova Corporation. All other trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Contents Chapter 1: Mandatory Regulations ..........5 Electromagnetic Interference (EMI) Information ..............5 Canada - Industry Canada ......................... 5 United States - Federal Communications Commission ..............5 EU Directive Compliance......................5 Battery Notices ........................... 6 NiCd Battery Pack Notice........................6 Lithium Battery Notice ........................ - Page 4 Contents 12-Volt Out, RS-485, and RS-232....................18 12-Volt Out............................18 RS-485 Interface ........................... 18 RS-232 Interface ........................... 18 Alarm and Switch Terminals ....................19 Connecting an Alarm or Switch Device ....................19 Audio Terminals ........................20 Audio Input ............................20 Audio Output............................20 Ethernet Ports, USB Ports, Video and HD Monitor Output ............21 Two Ethernet Ports and LEDs ......................
-
Page 5: Chapter 1: Mandatory Regulations
Chapter 1 Mandatory Regulations You must be familiar with the following mandatory regulations governing the product’s operations. You should also adhere to these instructions to ensure the installation meets regulatory compliance. Electromagnetic Interference (EMI) Information Canada - Industry Canada This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. -
Page 6: Battery Notices
Mandatory Regulations Battery Notices NiCd Battery Pack Notice The unit contains an internal NiCd battery pack that is used during power shortages. The NiCd battery pack may explode, leak, or get hot, causing personal injury if the following precautions are not followed: •... -
Page 7: Anti-Static Precautions
Environmental EU Directive Compliance March Networks is committed to doing our part to protect the environment. As a result, we have embraced the RoHS and WEEE Directives in the design and manufacture of our products. -
Page 8: Chapter 2: Feature Overview
Note: You can manage an 8000 Series Hybrid NVR using either of the management platforms offered by March Networks. You should familiarize yourself with the differences between the platforms prior to deploying the recorders. For more information, see the documentation available from the March Networks Partner Portal. -
Page 9: Key Features
Key Features The 32/16 channel 8000 NVR comes in two distinct types: the R Series (8732 R, 8532 R, 8516 R models) and the S Series (8532 S, 8516 S models). The R Series comes with a docking station and can be mounted in a rack, the S Series has a backplane and is intended to be placed on a flat surface such as a desktop. -
Page 10: Packaging/Shipment Contents
Data and power cables for the hard drives • Software DVD — The software can also be downloaded from the March Networks Partner Portal. • Technical publications — Included on the software DVD, or you can also download hardware and software technical publications from the March Networks Partner Portal. -
Page 11: Specifications
Feature Overview Specifications This section contains the dimensions, weight, temperature ranges, and power ratings of the unit. Dimensions of the R Series (with Docking Station) 17.4 inches/44.2 centimeters 14.6 inches/37.1 centimeters 16.0 inches/40.6 centimeters 0.8 inches/2.0 centimeters 3.1 inches/8.0 centimeters 19.2 inches/48.8 centimeters Dimensions of S Series (with Backplane) 16.9 inches/43.0 centimeters... -
Page 12: Operating And Storage Temperature
Feature Overview Operating and Storage Temperature ° ° • Operating temperature: 41 to 104 Fahrenheit / 5 to 40 Celsius ° ° • Storage temperature: -40 to 158 Fahrenheit / -40 to 70 Celsius WARNING: The recorder and docking station (if required) must be mounted in accordance with the mounting guidelines in this publication to ensure the unit remains within the recommended operating temperature range. -
Page 13: Video Inputs
Video Termination Video termination for the 8000 series is controlled through the Visual Intelligence software. You can use the March Networks Administrator Console application to view and modify the analog video termination. For more information, see the Administrator Console User Manual or online Help. -
Page 14: Video Capture Rates
Feature Overview Video Capture Rates This section details the video inputs and associated video capture rates. The 32/16 channel 8000 series supports the following resolutions for analog cameras: • 4CIF — 704 x 480 (NTSC) or 704 x 576 (PAL) •... -
Page 15: Front Panel Leds
Use the Administrator Console or Command Client software application to review the health alert and determine a possible resolution. For more information, see the Administrator Console User Manual Command Enterprise User Guide , available from the March Networks Partner Portal website. Green... - Page 16 LED) can be retrieved using the Command Client or the Administrator Console (depending on which software platform you are using, Command or Visual Intelligence). For more information, see the Command Enterprise User Guide or the Administrator Console User Manual, available from the March Networks Partner Portal. 8000 Series 32/16 Channel Hybrid NVR Installation Guide...
-
Page 17: Keyed Power Switch And Front Usb Ports
Feature Overview Keyed Power Switch and Front USB Ports There is a keyed power switch and two USB ports on the front of the unit. 2 USB Ports Keyed Power Switch Keyed Power Switch If the unit has a docking station (R Series), when the unit is powered on, the locking mechanism prevents the unit from being undocked. -
Page 18: 12-Volt Out, Rs-485, And Rs-232
12-Volt Out This connection is for powering external devices with a battery backed up source. It is intended for use with the March Networks 2316 Encoder. Maximum 12 Watts. The G indicates the ground connection pin and the + indicates the 12-volt positive connection pin. -
Page 19: Alarm And Switch Terminals
Feature Overview Alarm and Switch Terminals There are alarm and switch terminals on the back of the unit. Alarm and switch devices can connect to these. Alarm Terminals Switch Terminals Connecting an Alarm or Switch Device Using the following procedure, you can connect alarm and switch devices to the terminals at the back of the unit. -
Page 20: Audio Terminals
Feature Overview Audio Terminals Audio in and out terminals are available on the back of the unit. These terminals provide line level audio input and output. Audio In Audio Out Pinout Description Audio Signal for audio input channel 1. Connect the return to the “G” between audio input 1 and 2. Signal for audio input channel 2. -
Page 21: Ethernet Ports, Usb Ports, Video And Hd Monitor Output
Feature Overview Ethernet Ports, USB Ports, Video and HD Monitor Output There are two Ethernet ports, two USB ports, and a video output available on the back of the unit. HD Monitor Output 2 USB Ports 2 Ethernet Ports and LEDs Video Output Two Ethernet Ports and LEDs There are two gigabit Ethernet ports on RJ-45 connectors with LEDs to... -
Page 22: Hd Monitor Output
Video Output. For more information on the Provisioning Interface, see the Provisioning Interface Technical Instructions, available for download from the March Networks Partner Portal. For more information on using Local Control, see the 8000 Series NVR Local Control Addendum or the Local Control for the 8000 Series NVR Quick Start Guide, available for download from the March Networks Partner Portal. -
Page 23: Power Connector And Fuse Compartment
Feature Overview Power Connector and Fuse Compartment The power connector and fuse compartment are located on the back of the unit. Power Connector Fuse Compartment Power Connector Connects the docking station to a power source via a connected power cord. For the unit’s power ratings, see “Specifications”... -
Page 24: Hard Drives
Feature Overview Hard Drives You can install up to four hard drives inside the unit. Hard Drive installed in position 1 at the bottom of the bracket. Position 2 at the top of the bracket is empty. One installed hard drive. Position 3 at the bottom of the bracket is empty. -
Page 25: Nicd Battery Pack And Lithium Battery
Used by the unit to allow graceful shut down during power outages. The unit will perform a graceful shut down if power is removed for more than 15 seconds. Custom NiCd battery pack supplied by March Networks. Lithium Battery Provides backup power for the unit’s clock. -
Page 26: Chapter 3: Unit Setup
Then, specify basic device configurations using the March Networks Administrator Console. The Administrator Console application is included on the provided software DVD. For more information, see the Administrator Console User Manual, available for download from the March Networks Partner Portal. -
Page 27: Rack-Mounting
Unit Setup Rack-Mounting Rack-mount the docking station in a standard 19-inch rack (R Series only). To rack-mount the docking station Position the docking station in the appropriate position. Attach the docking station to the rack using four screws. For details about recommended screws, consult the documentation accompanying the rack. -
Page 28: Wall-Mounting With A Docking Station
Unit Setup Wall-Mounting with a Docking Station If your NVR unit includes a docking station (R Series only), you attach the brackets and drip trays to the docking station, which holds the NVR unit on the wall. To attach the docking station mounting brackets Use the large countersunk screws provided in the wall-mounting kit to attach the brackets to the docking station. -
Page 29: Attaching The Drip Trays To The Docking Station
Unit Setup Attaching the Drip Trays to the Docking Station Because the cooling fans are at the bottom of the recorder when wall-mounted, two drip trays are required. The drip trays and four small countersunk screws required to attach the trays to the docking station are included in the wall-mounting kit. - Page 30 Unit Setup Install the upper mounting screws at the marked locations. • If the upper mounting location is in a wall stud, thread the screw directly into the wall stud. • If the upper mounting location is in drywall, first install a drywall anchor, and then thread the screw into the drywall anchor.
-
Page 31: Wall-Mounting Without A Docking Station
Unit Setup Wall-Mounting without a Docking Station If your NVR does not include a docking station (S Series), you attach the brackets and drip trays directly to the recorder unit. To attach the mounting brackets to the recorder Use the large pan head screws provided in the wall-mounting kit to attach the brackets to the recorder. -
Page 32: Attaching The Drip Trays To The Recorder
Unit Setup Attaching the Drip Trays to the Recorder Because the cooling fans are at the bottom of the 8000 NVR when wall-mounted, two drip trays are required. The drip trays and four small pan head screws required to attach the trays to the recorder are included in the wall-mounting kit. -
Page 33: Desk-Mounting
Unit Setup Install the upper mounting screws at the marked locations. • If the upper mounting location is in a wall stud, thread the screw directly into the wall stud. • If the location is in drywall, first install a drywall anchor, then thread the screw into the anchor. Do not thread the mounting screws all the way in. -
Page 34: Installing Hard Drives
Unit Setup Installing Hard Drives This section describes how to install a hard drive, or install additional drives (up to four). Note: You can transfer a SATA hard drive from a 4000 C series NVR into a 32/16 channel 8000 series NVR, if you require. - Page 35 Unit Setup Remove the cover of the recorder. There are four hard drive positions in two hard drive trays. Position 1 is at the bottom of the right-hand tray, position 2 is at the top of the right-hand tray, position 3 is at the bottom of the left-hand tray, and position 4 is at the top of the left-hand tray.
- Page 36 Unit Setup Loosen the four screws at the bottom of the hard drive bracket (two each side) and remove it from the recorder. Note: Set the screws aside - you will use them to re-attach the bracket. Screws at bottom of bracket If you are only installing one or two hard drives, you will only need the right bracket, if you are installing three or four hard drives, you can start with the right bracket (for positions 1 and 2), then the left bracket (for positions 3 and 4).
- Page 37 Unit Setup Install and tighten the two screws on one side of a hard drive before installing and tightening the two screws on the other side. Note: When tightening the screws, use 5.3 in-lbs (inch pounds) of torque. Screws securing hard drive in bracket For each position where you are installing a hard drive, locate the data and power cables and connect both cables to the hard drive before you install the bracket back in the unit.
- Page 38 Unit Setup Ensure that both cables are connected to the main PCBA. The power cables are connected to the PCBA with the power cable for the hard drive in position one on the far right, and the power cable for the hard drive in position four on the far left, as shown in the photos below. (back of unit) Power Power...
- Page 39 (3) screws. Use 3.0 in-lbs (inch pounds) of torque. 11 If the unit has a docking station (8732 R, 8532 R), replace the unit in the docking station. 8000 Series 32/16 Channel Hybrid NVR Installation Guide...
-
Page 40: Turning The Unit On And Off
Unit Setup Turning the Unit On and Off Before turning the unit on, first ensure that the AC power cord is plugged into the power connector on the back of the docking station (R Series) or back plane (S Series). The power connector is shown in section “Power Connector and Fuse Compartment”... - Page 41 Glossary Administrator Console A configuration and maintenance tool that lets security and IT staff customize and maintain recorders in a central or local manner. Docking Station A metal frame that holds the recorder in place. All main device connections, including the required connection to a camera and power source are made to the docking station —...
- Page 42 Glossary Phase Alternation Line. The analog television display standard used in Europe and other parts of the world. PCBA Printed Circuit Board Assembly. Pan tilt zoom. A camera that you can remotely control using either a device controller connected to your computer, or using software controls.
- Page 43 The steps we have taken affect all aspects of our organization and involve our senior management team, employees, suppliers, partners and customers. Visit the March Networks website for more information about our company and our commitment to social responsibility and environmental sustainability.
