- Page 1 March Networks 8724 V Tribrid NVR Installation Guide...
- Page 2 Copyright © 2019. March Networks Corporation. All rights reserved. Information in this document is subject to change without notice. MARCH NETWORKS, March Networks Command, March Networks Searchlight, March Networks RideSafe, and the MARCH NETWORKS logo are trademarks of March Networks Corporation. All other trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Model Definition Information....................9 Chapter 2: Feature Overview.............10 Key Features......................... 11 Configuration Options ....................11 Internal Storage Options ....................11 Features......................... 11 Packaging/Shipment Contents ..................12 Installation and Maintenance Warning................12 Related User Guides ......................12 8724 V Tribrid NVR Installation Guide... - Page 4 Lithium Battery ........................31 Chapter 3: Unit Setup..............32 Accessing the Internal Components of the Recorder............33 Mounting the Recorder ......................34 Mounting Location ......................34 Installing or Replacing the Hard Drives ................37 Installing or Replacing Video Input Modules ..............40 8724 V Tribrid NVR Installation Guide...
-
Page 5: Chapter 1: Mandatory Regulations
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Europe This equipment complies with the following EU directives: 2014/30/EU, 2014/35/EU, and 2011/ 65/EU. A Declaration of Conformity is available upon request. 8724 V Tribrid NVR Installation Guide... -
Page 6: Environmental Directive Compliance
Mandatory Regulations Environmental Directive Compliance March Networks is committed to doing our part to protect the environment. March Networks is compliant with current RoHS and WEEE directives: • RoHS 2 or RoHS recast (directive 2011/65/EU) and its amendments • WEEE recast (directive 2012/19/EU) and its amendments Further details on corporate environmental policies and on RoHS and WEEE compliance are available from March Networks customer support. -
Page 7: Avis Pour Les Batteries
Avis pour les batteries ATTENTION: Il y a un risque d’explosion si une batterie est remplacée par un autre type de batterie. Assurez-vous d’utiliser le bloc de batterie NiCd et la batterie Lithium de March Networks. Avis sur le bloc de batterie NiCd L’unité... -
Page 8: Avis De Sécurité
Si cela n’est pas possible, l’unité peut être installé dans un endroit à accès non restreint seulement si elle est installée de façon à ce que le derrière de l’unité (ou les câbles sont dirigés) ne soit pas accessible. 8724 V Tribrid NVR Installation Guide... -
Page 9: Anti-Static Precautions
Model Definition Information The Certification Regulatory Model is HNVR HV SERIES. The model information is outlined in the following table. Certification Regulatory Model Includes the following NVRs HNVR HV series • 8724V 8724 V Tribrid NVR Installation Guide... -
Page 10: Chapter 2: Feature Overview
Chapter 2 Feature Overview The March Networks 8724 V Tribrid NVR is a secure and scalable recording platform able to support analog, HDoC (High Definition over Coax), and PoE (Power over Ethernet) cameras. These recorders offer outstanding video compression and storage. The recorders are managed using the Command video management software suite and configured using the Visual Intelligence Administrator Console software application. -
Page 11: Key Features
• QR code (front of recorder). Use the free GURU smartphone app to scan the recorder’s QR code for instant product information. 8724 V Tribrid NVR Installation Guide... -
Page 12: Packaging/Shipment Contents
Related User Guides Additional user guides related to the 8724 V Tribrid NVR and the software used to configure it are available in PDF format from the March Networks Partner Portal website. If you cannot access the Partner Portal, contact your March Networks representative. -
Page 13: Specifications
The recorder has an external power supply. The following values are for the base unit, without cameras connected. • Power input: 100-240 volts AC input (auto-sensing) • Current rating: 1.7 A typical • Frequency range: 50-60 Hz • Power consumption: 20 W typical, 60 W maximum 8724 V Tribrid NVR Installation Guide... -
Page 14: Video Inputs - Hdoc And Poe
8 HDoC inputs) 8 PoE video inputs Slot 2 (Slot alternatively has 8 HDoC inputs) 8 HDoC video inputs Slot 1 (Slot alternatively has 8 PoE inputs) Video Inputs in unit Video Inputs isolated view 8724 V Tribrid NVR Installation Guide... -
Page 15: Video Module Location And Numbering
The numbering for the inputs on the HDoC module (when the module is installed in a slot and the unit is correctly mounted) is as follows: Top of unit Input 8 Input 4 Input 7 Input 3 HDoC module Input 6 Input 2 Input 5 Input 1 Bottom of unit 8724 V Tribrid NVR Installation Guide... -
Page 16: Video Capture Rates
The procedure for this and for adding the High Definition and analog video channels from the HDoC module to the 8724 V Tribrid NVR are all described in the 8724 V Tribrid NVR - HDoC Module User Guide, available from the March Networks Partner Portal website. -
Page 17: Poe Modules
64 W at any time. If you require a PoE camera configuration that does not meet these camera power recommendations, please contact March Networks customer support. Current Limits for the PoE Ethernet Ports Each port has a current limit of 350 mA. This current limit allows the use of Class 0, 1, 2, and 3 PoE powered devices. -
Page 18: Status Leds
Use the Administrator Console or Command Client software application to review the health alert and determine a possible resolution. For more information, see the Administrator Console User Manual or Command Enterprise User Guide, available from the March Networks Partner Portal website. 8724 V Tribrid NVR Installation Guide... -
Page 19: Qr Code
Command or Visual Intelligence). For more information, see the Command Enterprise User Guide or the Administrator Console User Manual, available from the March Networks Partner Portal. QR Code There is a QR code on the front of the unit, under the USB ports and the status LEDs. -
Page 20: Two External Usb Ports
Each port provides up to 500 mA to power peripherals with a USB cable. The ports support USB version 2.0. Note: The unit also has two USB ports available inside. For details, see “Two Internal USB Ports” on page 26. 8724 V Tribrid NVR Installation Guide... -
Page 21: Main Circuit Board
“Audio Terminals” on page 24 • “HD Monitor Output” on page 25 • “Ethernet Network Port” on page 26 • “Two Internal USB Ports” on page 26 • “LAN USB Adapter” on page 26 8724 V Tribrid NVR Installation Guide... -
Page 22: Alarm And Switch Terminals
Depending on the switch’s default state, connect the normally-open or normally-closed wire to the normally-open (NO) or normally-closed (NC) terminal, respectively. After you connect the alarm and/or switch devices, you can turn on the unit. 8724 V Tribrid NVR Installation Guide... -
Page 23: Rs-232 Interface
Main circuit board in unit RS-232 Interface The RS-232 interface allows you to provide text capture, with the following pins: Definition Input Ground Output Note: You cannot use the RS-232 interface to control a PTZ camera. 8724 V Tribrid NVR Installation Guide... -
Page 24: Audio Terminals
(whether intercom or speaker) includes a built-in amplifier. Audio Out pin 1 is the signal for audio output channel 1. Connect the return to the “G” beside the audio output. Output specification: unbalanced, 600 Ω, 1Vp-p (line level) 8724 V Tribrid NVR Installation Guide... -
Page 25: Hd Monitor Output
Instructions, available for download from the March Networks Partner Portal. For more information on Local Control, see the 8724 V Tribrid NVR Local Control Addendum, or the Local Control for the 8000 Series NVR Quick Start Guide, available for download from the March Networks Partner Portal. -
Page 26: Ethernet Network Port
USB3 USB4 (main circuit board rotated 90 degrees) USB4 is connected to the LAN USB adapter This port is configured using the Administrator Console software (for more information, see the Administrator Console User Manual). 8724 V Tribrid NVR Installation Guide... -
Page 27: Power Supply And Connection
If the unit has a PoE video input module installed in any of the 3 slots, a loss of AC power causes the unit to reboot immediately. After the reboot (unless power is restored) the unit shuts down. For the unit’s power ratings, see “Specifications” on page 13. 8724 V Tribrid NVR Installation Guide... -
Page 28: Ground Connection
Connecting the ground wire to the recorder ground stud Ground wire from earth ground source (18 gauge) Keps nut Recorder ground stud 8724 V Tribrid NVR Installation Guide... -
Page 29: Cable Routing
If you are using the optional cable knockout holes, there are two widths available: • Small knockout hole: 34.925 mm (1.375”) – fits 1” cable • Large knockout hole: 44.45 mm (1.75”) – fits 1.25” cable 8724 V Tribrid NVR Installation Guide... -
Page 30: Hard Drives
One or two internal hard drives (depending on your model configuration) come pre-installed in each recorder. You can install one or two hard drives in the unit. The individual drive capacity depends on your model. 8724 V Tribrid NVR Installation Guide... -
Page 31: Nicd Battery Pack And Lithium Battery
Used by the unit to allow graceful shut down during power outages. The unit will perform a graceful shut down if AC power is removed for more than 15 seconds. Custom NiCd battery pack for each unit supplied by March Networks. Lithium Battery Provides backup power for the unit’s clock. -
Page 32: Chapter 3: Unit Setup
Then, specify basic device configurations using the March Networks Administrator Console. The Administrator Console application is included with the provided software. For more information, see the Administrator Console User Manual, available for download from the March Networks Partner Portal. 8724 V Tribrid NVR Installation Guide... -
Page 33: Accessing The Internal Components Of The Recorder
Unit Setup Accessing the Internal Components of the Recorder The 8724 V Tribrid NVR is designed for security, so the majority of the connections are only available after you open the lockable cover. Hinge along Keyed entry: left side allows... -
Page 34: Mounting The Recorder
Note: If you are mounting the unit on a wall where it is not possible to cut a hole for cabling (for example, a concrete wall) or attach the unit to metal or wood, contact March Networks for alternate mounting instructions. - Page 35 You must mount the recorder so that the door hinge is on the left side and the key hole for the door is on the right side. The recorder cannot be mounted in any other orientation. Hinge on Key hole left side on right side 8724 V Tribrid NVR Installation Guide...
- Page 36 Mark the opening of the cable routing box in the back of the unit, using the recorder unit as a template. Mark the upper and lower mounting screw locations, using the recorder unit as a template. upper mounting hole Cable routing box (door lower open) mounting hole 8724 V Tribrid NVR Installation Guide...
-
Page 37: Installing Or Replacing The Hard Drives
If both the mounting locations are in a wall stud, thread the screws directly into the wall stud. Note: March Networks recommends that the screws that hold the mounting bracket and the unit itself are inserted into wall studs (metal or wood support), not drywall. - Page 38 Data cable for hard drive in position 2 connected to main circuit board Data cable for hard drive in position 1 connected to main circuit board Tail of Y power cable for both hard drives connected to main circuit board 8724 V Tribrid NVR Installation Guide...
- Page 39 Install the hard drive tray back into the recorder unit and secure the tray to the recorder using the thumbscrews. Close and lock the door of the recorder. Apply power by plugging in the recorder. 8724 V Tribrid NVR Installation Guide...
-
Page 40: Installing Or Replacing Video Input Modules
March Networks recommends that you export any essential archive video from the analog module before replacing it. To retrieve archive video from the analog module after it has been replaced, contact March Networks technical support. - Page 41 March Networks recommends that you export any essential archive video from the analog module before replacing it. To retrieve archive video from the analog module after it has been replaced, contact March Networks technical support.
- Page 42 Discovery Browser software (accessible from the Administrator Console software). For information on provisioning the HDoC modules, see the 8724 V Tribrid NVR - HDoC Module User Guide, available from the March Networks Partner Portal website.
- Page 43 The SATA standard is based on serial signaling technology. SMART Self-Monitoring Analysis and Reporting Technology. An interface between the recorder and the hard drive. Universal serial bus. An interface between the recorder and add-on devices. 8724 V Tribrid NVR Installation Guide...
- Page 44 Companies worldwide use our software solutions to improve efficiency and compliance, reduce losses and risk, enhance customer service and compete more successfully. With deep roots in video security and networking, March Networks is also recognized as the leader in scalable, enterprise-class video management and hosted services.
