Confi guring User Programmable Buttons

The CL-12 offers three user programmable buttons for quick-access to a wide
range of functions and menus.
To confi gure U1 – U3 buttons:
1. Press MENU.
2. Select CL-12 > User 1-3 buttons.
3. Select an option to assign to the button. The following table shows possible
options and whether they are available with the different 6-Series mixers:
O
PTION
Take List
File List
Play
FFWD
REW
Slate
Tone
FAV
Select
Default Playback Card
Power Menu
Input Delays
Output Delays
LR Linking
X1/X2 Linking
Auto Mixer
Return Loopback
Mode A - C
SLATE ROUTING
TONE ROUTING
Timecode Menu
Daylight Mode
Create Sound Report
Sound Report Info
X1 - X6 Routing
SL-6 Routing
AES Routing
EQ Menu
LF Freq
HF Freq
202
D
ESCRIPTION
Displays the Take List screen.
Displays the File List screen.
Toggles between play and pause.
Fast forward or skip to next fi le.
Rewind or skip to previous fi le.
Toggles slate on and off.
Toggles tone on and off.
Duplicates the action of the FAV switch.
Duplicates the action of pressing the Select
encoder.
Shortcut to FILE STORAGE > Default Play-
back Card sub-menu.
Displays the POWER settings.
Displays the Input Delays screen.
Displays the Output Delays screen.
Toggles linking of L and R.
Toggles linking of X1 and X2.
Toggles the Auto Mixer (MixAssist or Dugan)
on and off.
Three options: Enters Return Loopback
modes for either RTN A, RTN B, or RTN C,
respectively.
Displays the Slate Routing screen.
Displays the Tone Routing screen.
Displays the Timecode/Sync menu.
Toggles daylight mode.
Creates a sound report (.csv fi le).
Displays the Sound Report Info screen.
Six options: Each one is a shortcut to
OUTPUTS > X1-X6 Routing > X1 Routing, X2
Routing, and so forth, respectively.
Displays the SL-6 Routing screen.
Displays the AES Output Routing screen.
Shortcut to CL-12 > EQ sub-menu.
Displays the EQ LF FREQ settings.
Displays the EQ HF FREQ settings.
688 664 633
—
—
—
—
— —
— —
—
—
— X1-X4
only
— —
— —
— —
— —
