- Page 1 Installation Manual HDMI Interface for New SKODA...
- Page 2 Compatibility: VW, Skoda, Polo 2017~ Components: Interface*1 Sub Board*1 Ex Board*1 Interface Input / Output specification: Input: HDMI*2 Analog RGB*1 A/V*2 CVBS(Rear camera)*1 CVBS(Front camera)*1 Output: To LCD*1 Power Spec: Input Power: 8VDC ~ 18VDC Consumption: 5WATT Switch input mode: External video sources skip function: Able to control input videos on and off via Dip switches Able to switch videos via the remote and button switch...
- Page 3 MAIN BOARD POWER CABLE CAN CABLE ADC CABLE QCPASS1239 HPOWER0209 HARETC0128 HARETC0267 AV CABLE MULTI CABLE REMOTE CONTROL REAR CABLE HAVCAB0056 HARETC0240 REMOTE0001 HARETC0002 IR CABLE 4P RGB CABLE EX CABLE S/W CABLE HIRCAB0002 HRGBCA0013 HARETC0249 HARETC0001 VW-MIB2GP-5CH-SUB SUBARU-5CH-EX LVDS CABLE QCPASS1305 QCPASS1283 HLVDSC0066...
-
Page 4: Rear Camera
※ ON : DOWN / OFF : UP FUNCTION DIP S/W SELECT OFF : RGB MODE ON : RGB MODE SKIP OFF : HDMI1 MODE HDMI1 ON : HDMI1 MODE SKIP OFF : AV1 MODE ON : AV1 MODE SKIP OFF : AV2 MODE ON : AV2 MODE SKIP No use... - Page 5 To Sub board ADC No Use RGB NAVI BOX A/V CABLE...
- Page 6 Please be careful the connector on sub B/D doesn’t touch to OEM bracket in Red circle. ① ② Please disassemble the Please put the supplied sub monitor as above picture. board like above. ③ ④ Please connect OEM FPC Please connect supplied FFC cable cable to supplied sub board.
- Page 7 ⑨ ⑩ Please do supplied LVDS cable as Please do supplied LVDS cable as same same as above picture. as above picture. ⑪ ⑫ Please assemble OEM cover Please assemble HU and like above. Monitor...
- Page 8 Please solder provided wires as same as above picture. (Follow the wires’ colors) 1. Please remove the registers in red circle. 2. Solder provided wires as same as beside picture. (Follow the wires’ colors)
- Page 9 Menu of FACTORY IMAGE SETTING IMAGE H-POSITION PARK V-POSITION H-POSITION: Move the screen left and right. UTIL H-SIZE(NAVI) INFO V-POSITION: Move the screen up and down. H-SIZE (NAVI): Adjust the left and right size of navigation. MENU to Return SEL to Select/Save Menu of FACTORY PARK SETTING IMAGE...
-
Page 10: System Version Information
Menu of FACTORY UITL1 IMAGE NAVI MODEL NAVI MODEL: RGB navigation setting PARK CAR MODEL UTIL1 AVOUT SELECT CAR MODEL: Car model setting UTIL2 HDMI SKIP INFO OEM SKIP AVOUT SELECT: Select audio channel FACTORY RESET transmitted through AUX (HDMI1, HDMI2, AV) MENU to Return SEL to Select/Save HDMI SKIP:... - Page 11 Q. I cannot change mode A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not check connection of POWER cable. Q. All I got on the screen is black. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well.
