- Page 1 Release Date: 2014 - 06 - 20 Rear View Camera Interface car-solutions.com support@carsolutions.com...
- Page 2 Rear View Camera Interface Components POWER / CAN Cable CVBS Cable LVDS Cable RVC Cable R04-7G.A3 DIP Switch Settings Setting Mode for VW Golf Buttons Function ON: ▼ OFF: ▲ Enter into the setting menu. (press the button 5 seconds) Select the setting menu and No.1...
- Page 3 Rear View Camera Interface Installation Diagram Head Unit(in the glovebox) – Main connector CAN wires Information GROUND REAR 12V OUT REAR CAMERA Rear View Camera CAMERA IN CVBS IN Front View Camera(or AVM) PAS CAN L (PAS CAN H, L = VW Golf, Audi A3) PAS CAN H (If reverse gear is not detected via CAN data, REVERSE 12V IN...
