  • Page 1 Update Date 2014.04.25 Model QVI-LVTX-1CH-V7.1 Firmware Date...
  • Page 2 Warning / Caution  When installing the main unit, do not remove or alter existing vehicle fasteners, including nuts, bolts, screw, clips, and fittings. Never detach, move or alter existing vehicle wiring, including electrical grounds and straps. Alteration of existing vehicle Warning components may make vehicle unsafe to operate.

  • Page 3: Table Of Contents

    Table of Contents 1. Specifications 1.1 Main Specifications 1.2 Features 1.3 System Diagram 1.4 Components 1.5 Exterior 2. Installation 2.1 Installation Diagram 2.2 Cautions on Installation 2.3 Installation 3. Setting 3.1 DIP Switch 3.2 Remote Control 3.3 FACTORY MODE 3.3.1 IMAGE, PARK 3.3.2 UTIL 3.4 OSD(ON SCREEN DISPLAY) 3.4.1 ANALOG RGB MODE...

  • Page 4: Specifications

    1. Specification 1.1 Main Specification 1. Car Compatibility - Renault Model : Master, Trafic, Scenic, Laguna, Megane, Clio - Opel Model : Movano, Vivaro 2. Components Multimedia Interface * 1 Sub-board * 1 3. MULTIMEDIA INTERFACE input specification 3 * A/V (NTST&PAL) Input 1 * CVBS(Rear Camera) Input 2 * Analog RGB 1 * LCD input (Car system input)

  • Page 5: Features

    1. Specification 1.2 Features  Possible to move the displayed position of DVD and Navigation.  Improved Display Screen (convenience-oriented Interfaces for users)  Add a safe function (show the main screen while driving)

  • Page 6: System Diagram

    1. Specification 1.3 System diagram Switch for source toggle Remote control OEM Navi Button (Can Signal) NAVIGATION Input (Analog RGB) RGB 2 Input DISPLAY Car Installation A/V 1 OEM LCD VIDEO MUX A/V 2 VIDEO CIRCUIT A/V 3 CVBS (Rear camera) Car Screen Input (CAR MAIN BOARD) POWER...

  • Page 7: Components

    1. Specification 1.4 Components FFC cable*1ea FFC cable* 1ea FFC cable* 1ea (FFCBAL0045) (FFCBAL0044) (SCREWS0068) LVDS cable * 1ea (HLVDSC0018) Sub-bard * 1ea (QCPASS0510) POWER cable (24P) * 1ea A/V cable * 1ea (HPOWER0011) (HAVCAB0002) REAR CAMERA POWER cable * 1ea (HARETC0002) IR cable * 1ea MODE cable * 1ea...

  • Page 8: Exterior

    1. Specification 1.5 Exterior Dimension ⑥ ⑦ ⑧ Horizontal Length 125mm Vertical Length 105mm Height 21mm ① LED ② POWER ③ RGB IN-2 ④ R-CAM ⑤ AV(IN/OUT) ⑥ DIP SWITCH ⑦ TOUCH OUT TO NAVI ① ② ③ ④ ⑤ ⑧...

  • Page 9: Installation

    2. Installation 2.1 Installation Diagram Same side FFC cable <COMMAND> Opposite side FFC cable <LCD> LVDS cable ※ Please make sure that the installation should be carefully conducted to avoid from the damage of a monitor by ESD(Electrostatic discharge) and misalignment while connecting the module of a monitor with cables.

  • Page 10: Cautions On Installation

    2. Installation 2.2 Cautions on installation Ignition key should be taken off before starting installation, interface  power connection must be the last step in installation. Power cable should be separated when connecting interface.   Should be no any electronic devices or magnetic pole around installation place.

  • Page 11: Installation

    2. Installation 2.3 Installation ① Please dismantle the monitor and LCD as above.
  • Page 12 2. Installation 2.3 Installation 1. Disconnect a FPC cable connected between a command and a monitor. 2. Connect same sides FFC cable to the command. 3. Please connect opposite sides FFC cable to the LCD.
  • Page 13 2. Installation 2.3 Installation ① Tape up the FFC cable connected to the command and turn over the FFC cable as above.. ② Tape up the FFC cable connected to the LCD and turn over the FFC cable as above. -10-...
  • Page 14 2. Installation 2.3 Installation - Connect FFC cable connected with the Command to Command In of Sub-board. - Connect FFC cable connected with the LCD to LCD out -11-...
  • Page 15 2. Installation 2.3 Installation ① Please screw up a provided sub-board as above. -12-...

  • Page 16: Setting

    3. Setting 3.1 DIP Switch ※ DIP S/W usage example - Input Mode : A/V3, Navigation (RGB) - Select 5.8inch monitor - When original Navigation is not installed - Rear camera : When to be installed on CVBS 4 ▷ DIP S/W : 1 ...

  • Page 17: Remote Control

    3. Setting 3.2 Remote Control *FACTORY MODE (Interface setting for installer) : Operated by pressing ▲ → ▼ → ▲ →MENU button or press ◀ more than 5seconds long on the remote control. Function POWER & PIP Unavailable MENU Activating OSD menu Making a selection, changing image display Moving upward ▲...

  • Page 18: Image, Park

    3. Setting 3.3.1 FACTORY MODE-IMAGE, PARK Menu of FACTORY Menu of FACTORY IMAGE PARK ENABLE IMAGE H-POSITION PARK PARK SETUP PARK V-POSITION UTIL REAR SELECT UTIL INFO SAFE ENABLE INFO MENU to Return SEL to Select/Save MENU to Return SEL to Select/Save ...
  • Page 19 3. Setting 3.3.1 FACTORY MODE-IMAGE, PARK FACTORY mode – Press ◀ button 2 seconds long on the remote control. In Factory Menu, Adjusting the position of the parking guide line (available in PARK SETUP -> V-POSITION, H-POSITION)  H-POS “H_POS’’ will be shown on the right and control moving in horizontal direction ...

  • Page 20: Util

    3. Setting 3.3.2 FACTORY MODE-UTIL FACTORY mode – Press ◀ button 2 seconds long on the remote control. Menu of FACTORY Menu of FACTORY IMAGE NAVI MODEL IMAGE NAVI MODEL PARK AVOUT SELECT PARK AVOUT SELECT UTIL IR MEMORY UTIL IR MEMORY UTIL2 DVD TYPE...
  • Page 21 3. Setting 3.3.2 FACTORY MODE-UTIL2 FACTORY mode – Press ◀ button 2 seconds long on the remote control. Menu of FACTORY Menu of FACTORY IMAGE OEM SKIP IMAGE OEM SKIP PARK HDMI SKIP PARK HDMI SKIP UTIL FACTORY RESET UTIL FACTORY RESET UTIL2 UTIL2...

  • Page 22: Osd(On Screen Display)

    3. Setting 3.4.1 OSD (On Screen Display) / Analog RGB Mode  IMAGE  COLOR * BRIGHTNESS * RED : Adjusting red * CONTRAST * GREEN : Adjusting green * SHARPNESS * BLUE : Adjusting blue * USER IMAGE * USER COLOR : Selecting one among : Selecting a color option among 4 color options.

  • Page 23: Video Mode

    3. Setting 3.4.2 OSD (On Screen Display) / Video Mode  IMAGE  OSD * BRIGHTNESS * LANGUAGE : Choosing interface * CONTRAST language while changing mode between * SATURATION A/V and DVD * HUE * TRANS : Adjusting transparency of OSD * SHARPNESS * H-POSITION * USER IMAGE...

  • Page 24: Trouble Shooting

    4. Trouble Shooting Q. I can not switch A/V sources A. Check IR or Ground cable connection. Check LED lamps in the interface, if it is not on, check power cable. Q. All I got on the screen is black. A.
