- Page 2 •Specification Car Compatibility : 2016 AUDI Q7 Components : Interface* 1ea, Sub-board*1ea Multimedia interface Input/output spec Input : HDMI*2, Analog RGB*1, A/V*1, CVBS(Rear Camera)*1 CVBS(Front Camera)*1 Output : To LCD*1 Power spec Input power : 8VDC ~ 18VDC Consumption : 5WATT Switch input mode ...
- Page 3 •Product exterior Length-90mm Height-18mm Width-140mm 5V-OUT(Power supply for Mirroring device) | HDMI-1 | HDMI-2 | MULTI | RGB-IN(RGB Navigation Input) LVDS-OUT(Connection to Sub-board) | CAP T/S INPUT(Original touch cable connection) | RES T/S OUT(NOT FOR USE) | CAP T/S OUT(Provided touch cable connection) | TEST(NOT FOR USE) | LED | POWER/CAN(Power/ CAN connection) | DIP S/W(DIP switch setting) •Components Sub-board * 1ea...
- Page 4 •DIP SWITCH ※ ON : DOWN / OFF : UP FUNCTION Dip S/W SETTING OFF : RGB DISPLAY RGB INPUT MUTE ON : Skipping RGB Mode OFF : HDMI1 DISPALY HDMI1 MODE MUTE ON : Skipping HDMI1 Mode OFF : AV DISPLAY AV MODE MUTE ON : Skipping AV Mode OFF : Front camera function on...
- Page 5 •Factory setting Adjust a current screen position and size. H-POSITION : Move display horizontally V-POSITION : Move display vertically Adjust rear view camera setting. PAS TYPE : Select type of parking guide line - NOT USED : No use parking guide line - PAS ON : Selecting Dynamic parking guide line - PAS OFF : Selecting fixed parking guide line PAS SETUP : Adjusting the position of the parking guide line...
- Page 6 •Factory setting Navigation & Car model setting up NAVI MODEL : Setting up RGB Navigation. (Default, Q-roi RGB, WP9230, HDMI(WVGA)) HDMI MODEL : Setting up HDMI1 Navigation. (Q-roi RGB, WP9230) CAR MODEL : Selecting the model of car. HDMI2 SKIP : Skipping HDMI mode when switching modes.
- Page 7 •How to use OEM buttons ※ Able to switch modes via NAV button of MMI. * Long press : Switching modes (RGB→HDMI1→HDMI2→A/V→OEM Mode) * Short press : Switching to OEM Mode.
- Page 8 •Installation Diagram Original Command Provided LCD cable Original LCD Cable Dashboard Monitor HDMI NAVI BOX NAVI BOX CAN-H(MMI) CAN-L(MMI) CAN-H(GEAR) CAN-L(GEAR) LVDS Cable NAVI BOX Mirroring Device HDMI NAVI BOX ※ HDMI NAVI must be connected to HDMI-1.
- Page 9 •CAN cable connection CAN-H(GEAR) CAN-L(MMI) CAN-H(MMI) CAN-L(GEAR) ※ Find the original cable at the back side of command. - Provided CAN-H(MMI) wire (Yellow+White) → Original CAN-H wire #1 pin (Orange+Black) - Provided CAN-L (MMI) wire (Yellow) → Original CAN-L wire #7 pin (Orange+Brown) - Provided CAN-H(GEAR) wire (White) →...
-
Page 10: Troubleshooting
•Trouble shooting Q. I cannot change mode A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not check connection of POWER cable. Q. All I got on the screen is black. A. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well.
