Billion BiPAC 2073 R2 White Paper

Homeplug av 200mbps ethernet bridge series
Hide thumbs Also See for BiPAC 2073 R2:

Advertisement

Quick Links

Download this manual See also: User Manual
White Paper
HomePlug AV 200Mbps Ethernet Bridge Series
BiPAC 2073 R2/BiPAC 2074 R2
- Extend Your Home Networking through Power Lines
1

Advertisement

loading

Related Manuals for Billion BiPAC 2073 R2

Summary of Contents for Billion BiPAC 2073 R2

  • Page 1 White Paper HomePlug AV 200Mbps Ethernet Bridge Series BiPAC 2073 R2/BiPAC 2074 R2 - Extend Your Home Networking through Power Lines...

  • Page 2: Table Of Contents

    Table of Contents 1. Overview – Power Line Communication (PLC) 2. Introduction of HomePlug AV 3. What’s Unique about Billion’s PLC 3.1. Power Saving feature 3.2. Extra Power Outlet with Noise Filter - AC Pass-Through Power Socket 4. Application of HomePlug AV...

  • Page 3: Overview - Power Line Communication (Plc)

    1. Overview – Power Line Communication (PLC) In recent years Power Line Communication has emerged as a new generation of networking and it has become increasingly popular among residential and small sized office settings. The use of twisted pair cable or optic fiber as transmission media in Ethernet not only costs a fortune in setting up a complicated cabling system, it may also cause some renovation issue.

  • Page 4: Introduction Of Homeplug Av

    2. Introduction of HomePlug AV HomePlug Powerline Alliance is the power line networking alliance and it is also the organization that sets the HomePlug standard. There are currently 50 members in this organization comprised mainly of networking and information technology professionals from some of the renowned companies like Cisco/Linksys, GE, LG, Motorola, Samsung, Sharp, TI, Intel and Conexant.
  • Page 5 Below is the table that shows the specification differences between HomePlug 1.0 and HomePlug AV. HomePlug 1.0 HomePlug 1.0 w/Turbo HomePlug AV (INT5200) (INT5500) (INT6xxx) PHY Rate 14Mbps 85Mbps 200Mbps 8Mbps 35Mbps 105Mbps Peak Throughput Typical Power Line 4-6Mbps 8-12Mbps 40-45Mbps Throughput Typical Coax Throughput...
  • Page 6 Billion BiPAC 2073 R2/2074 R2 uses the Intellon INT6400 HomePlug AV solution that bridges Powerline networking and Ethernet networking. It also incorporates the Orthogonal Frequency Division Multiplexing (OFDM) modulation technique and a noise filter feature that provides an excellent transmission rate as well as high quality and stable transmission.

  • Page 7: What's Unique About Billion's Plc

    3.1. Smart Power Saving feature When the PC is off or during its standby mode, Billion PLC will automatically switch from its regular “working” power mode to power saving mode. With this feature, Billion PLC can help save up to 60% of power consumption - this feature also applies under 264V circumstance.

  • Page 8: Extra Power Outlet With Noise Filter - Ac Pass-Through Power

    3.2. Extra Power Outlet with Noise Filter - AC Pass-Through Power Socket BiPAC 2074 R2 comes with a built-in AC Pass-Through Power Socket and noise filter feature. The AC Pass-Through Power Socket is an extra set of power outlet that can be used by other electrical appliances such as table lamp, hair dryer or power charger.
  • Page 9 Table 1: listing of all the appliances used and their respective locations Table 2: noise tests categorized as - Severe/Moderate/Minor Table 1: Equipment List for the Apartment (APT1) Communication Site Equipment list Location (room) Jensen TV Polaroid DVD player Generic PC Living room HP printer Fluorescent lamp...

  • Page 10: Application Of Homeplug Av

    - just install the bridge utility, which is simple and easy and without extra configuration. If there are two or more BiPAC 2073 R2/2074 R2 devices, connect one of the devices to Billion ADSL router, so the other device(s) is allowed to transfer data (both audio and video) to Billion ADSL router via the electrical wiring and then access ISP's network programs or Internet through your Internet connection.

  • Page 11: Summary

    The HomePlug AV standard provides data transfer rate of up to 200Mbps. Most of the multi-media applications are transferred through the Internet in the house. BiPAC 2073 R2/2074 R2 uses HomePlug AV to establish super fast network connectivity. Additionally, it does not require the time and money needed to install any other device, nor does it require any drilling in the house, thus it helps to avoid problems that might have arisen from signal instability over wireless networks.

This manual is also suitable for:

Bipac 2074 r2
