Billion SG600 User Manual

Smart wireless bridge
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Billion BEsmart Service Packages
SG600 Smart Wireless Bridge
User Manual
Last Revised on Mar. 2013
www.smartgrid.com.tw

Advertisement

Table of Contents
loading

Related Manuals for Billion SG600

Summary of Contents for Billion SG600

  • Page 1 Billion BEsmart Service Packages SG600 Smart Wireless Bridge User Manual Last Revised on Mar. 2013 www.smartgrid.com.tw...

  • Page 2: Table Of Contents

    Table of Contents CHAPTER 1: Introduction ................0 1.1 Introduction of BEsmart ..............1 1.2 BEsmart Application................. 2 CHAPTER 2: Device Description and Installation ........3 2.1 BEsmart Package Content and Specifications ......3 2.2 Device Descriptions ................. 5 2.3 BEsmart Installation ................. 7 2.3.1 Device Configurati ..............

  • Page 3: Federal Communication Commission Interference Statement

    WARNING Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 4: Chapter 1: Introduction

    The issue of environmental protection and energy conservation has been received great attentions since the global warming and energy shortage have become a serious worldwide crisis. Billion BEsmart highlights the importance of energy preservations and managements, and contributes smart solutions for Telco/ISP/SI service providers who dedicate to strengthening customer satisfactions.

  • Page 5: Besmart Application

    1.2 BEsmart Application The SG600 acts the role of coordinator, which processes the power data delivered from smart energy meters connected with electrical appliances by ZigBee to an xDSL cable modem/router and then transmits to the cloud with the internet access. All history information of power usage would be saved on the cloud.

  • Page 6: Chapter 2: Device Description And Installation

    Device Description and Installation This section specifies package contents, device descriptions, BEsmart kit installations, and network connections. 2.1 BEsmart Package Content and Specifications § SG600 Collect power information from each smart meter measure. § Smart Power Plug Energy Management and Remote on/off Control Comprehensive Measurement Capability §...

  • Page 8: Device Descriptions

    Blinking green when wireless client is not working Blinking green quickly when ZigBee pairing mode is working ZigBee/WPS Blinking orange quickly when WPS pairing mode is working Lit green when SG600 is getting internet connection Internet Lit red when wireless in not getting internet connection Power Connect it with the supplied power adapter.
  • Page 9 Push WPS button to trigger ZigBee function, thus smartmeter allowing join in is starting. See ZigBee Config section. ZigBee/WPS Push WPS button more than 5 seconds to trigger Wi-Fi Protected Setup function. See WPS section. SG3015-T1/3010-T1 Power Plug Put the plug in the power socket. Lit green when the meter does not pair with SG6200NXL.

  • Page 10: Besmart Installation

    2.3 BEsmart Installation It’s easy to setup the power meter and power plug simply by following the instructions below. Also this section shows how the SG600 device connects to the SG3010-T1/SG3015-T1. 2.3.1 Device Configuration The Illustration above demonstrates overall structure for device configurations.
  • Page 11 SG600---Internet (Router)---PC Connect a XDSL router to PC with an Ethernet cable and prepare your SG600 and connect it to the router with the supplied RJ45 Ethernet cable or wireless client. Make sure the internet connection is workable (please refer to the next Network Configuration section).

  • Page 12: Network Configuration

    2.3.2 Network Configuration The router can be configured through your web browser. A web browser is included as a standard application in the following operating systems: Linux, Mac OS, Windows 98/NT/2000/XP/Me/Vista/7, etc. The product provides an easy and user-friendly interface for configuration. Please check your PC network components.
  • Page 13 Configuring PC in Windows 7 1. Go to Start. Click on Control Panel. 2. Then click on Network and Internet. 3. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel.
  • Page 14 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address automatically Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 7. Click OK again in the Local Area Connection Properties window to apply the new configuration.
  • Page 15 Configuring PC in Window Vista 1. Go to Start. Click on Network. 2. Then click on Network and Sharing Center at the top bar. 3. When the Network and Sharing Center window pops up, select and click on Manage network connections on the left window column.
  • Page 16 5. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 6. In the TCP/IPv4 properties window, select the Obtain an IP address automatically Obtain Server address automatically radio buttons. Then click OK to exit the setting. 7. Click OK again in the Local Area Connection Properties window to apply the new configuration.
  • Page 17 Configuring PC in Windows XP 1. Go to Start > Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.
  • Page 18 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration.
  • Page 19 Configuring PC in Windows 2000 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.
  • Page 20 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration.
  • Page 21 Configuring PC in Windows 95/98/Me 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP > NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC.
  • Page 22 4. Then select the DNS Configurationtab. Select the Disable DNS radio button and click OK to finish the configuration. 5. 5. Select the Disable DNS radio button and click OK to finish the configuration...
  • Page 23 Configuring PC in Windows NT4.0 1. Go to Start > Settings > Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.

  • Page 24: Factory Default Settings

    Factory Default Settings Before configuring your router, you need to know the following default settings. Web Interface (Username and Password) Username: admin Password: admin The default username and password are “admin” and “admin” respectively. Device LAN IP settings IP Address: 10.10.10.252 Subnet Mask: 255.0.0.0...
  • Page 25 Information from your ISP Before configuring this device, you have to check with your ISP (Internet Service Provider) to find out what kind of service is provided such as PPPoE, Obtain an IP Address Automatically (DHCP), Fixed IP Address (Static IP). Gather the information as illustrated in the following table and keep it for reference.

  • Page 26: Device Connections

    2.3.3 Device Connections Step1: Plug in an electronic appliance that you intend to monitor to the power meter. Step2: Plug in the Power Meter to the wall outlet/socket. Step3: Set up the connection between the power meter and SG6200NXL (Please refer to Device Pairing section for detail)
  • Page 27 NOTE: Please ensure that the power meter has been turned off or the power supply has been cut off before setting up.

  • Page 28: Pairing The Smart Meter

    Step1: After setting up the power connections, please check if the status LED light green before pairing. Step 2: Push ZigBee button on the rear panel of SG600 to make a connection. Step 3: Then, ZigBee/WPS LED in the front panel will blink quickly around 30 seconds.
  • Page 29 blink slowly and steadily, which indicates that the modem and the power meter are successfully connected.

  • Page 30: Un-Pairing The Smart Meter

    2.3.5 Un-pairing your smart meter Before pairing the SG600 with smart power meters, please check if the status LED lights green. If the status LED blinks green, it means that the meter has been paired. Please un-pair the smart meter first then re-pair your own ZigBee Gateway.

  • Page 31: Chapter 3 Installation Of Web Manager

    Let’s start the configurations. Quick Start Step 1 : Hardware setting Connect the SG600 to your PC’s Ethernet interface with supplied RJ-45 Ethernet cable and the other side to a router or modem with Ethernet cable or wireless client for the internet connection.
  • Page 32 Choose “Administrator” from the account type to configure and manage the web settings if your are authorized to access the router. 3. Once you have logged in to your SG600, you can begin to set it up according to your requirements. You would see the main page of basic...
  • Page 33 4. Time Zone Setting First, set up the time to meet the time zone of your country. Click “Continute”. 5. SG600 provides the WAN interface based on your own backbone router. There are 2 Connect Modes: EWAN and Wireless Client.
  • Page 34 Your backbone device is xDSL router and your PC IP is based on Static IP. Enter the information provided by your ISP PPPOE ● If your backbone device is xDSL cable modem, please choose PPPOE. For the detail internet configurations, please refer to SG600 internet settings. Click “Continue” to proceed to the next step.
  • Page 35 7. To set the Wireless configuration, click “Next to Wireless”. 8. Wireless setup WLAN Service: Default setting is Enable. ESSID: The ESSID is the unique name of a wireless access point (AP) to be distinguished from another. For security propose, change to a unique ID name to the AP which is already built-in to the router’s wireless interface.
  • Page 36 Channel ID will be different based on this setting. 9. After clicking “Continue”, the program would start to save the settings. After successfully saving the settings, you would be directed to BEsmart Registration. 10. This is BEsmart Registration for cloud server. Create a username and password and offer the E-mail for the registration, then read the term and check the box “I accept the Term of Service”.
  • Page 37 12. Please wait for 10 seconds for saving the configuration. 13. The easy configurations of your device have been finished. Congratulations! Please ensure that the smart wireless bridge and its backbone router/modem are maintained in a connection status or it may result in different power consumption data between measurement and real condition.
