Billion BIPAC-741 GE V2.0 User Manual

Adsl firewall router with 4-port 10/100m switch
Hide thumbs Also See for BIPAC-741 GE V2.0:
Table of Contents

Advertisement

Quick Links

Download this manual
BIPAC-741 GE V2.0
ADSL Firewall Router
with 4-port 10/100M switch
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIPAC-741 GE V2.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billion BIPAC-741 GE V2.0

Summary of Contents for Billion BIPAC-741 GE V2.0

  • Page 1 BIPAC-741 GE V2.0 ADSL Firewall Router with 4-port 10/100M switch User’s Manual...

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 ................. 1 ........................... 1 NTRODUCTION 1.1 An Overview of BIPAC-741 GE V2.0................... 1 1.2 Package Contents ........................2 1.3 BIPAC-741 GE V2.0 Features ....................2 1.4 BIPAC-741 GE V2.0 Application..................4 CHAPTER 2 ................. 5 BIPAC-741 GE V2.0 ......................
  • Page 4 Billion BIPAC-741 GE V2.0 ADSL Firewall Router Problems with the WAN Interface ..................... 42 Problems with the LAN Interface ....................42 APPENDIX A ..............43 ..........................43 PECIFICATION APPENDIX B ..............44 ........................... 44 RODUCT UPPORT...

  • Page 5: Chapter 1

    Chapter 1 Introduction 1.1 An Overview of BIPAC-741 GE V2.0 The BIPAC-741 GE V2.0 router provides a high-speed ADSL port, a 4-port 10/100M Base-T Ethernet switch for high-speed Internet browsing. It can support downstream transmission rates of up to 8Mbps and upstream transmission rates of up to 1024Kbps. It also supports rate management that allows ADSL subscribers to select an Internet access speed suiting their needs and budgets.

  • Page 6: Package Contents

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router dedicated local web server, even though the server now has a different IP address. In this example, the product is on the Internet and vulnerable to attacks, but the server is protected. Virtual Server can also be used to re-task services to multiple servers. For instance, the product can be set to allow separated FTP, Web, and Multiplayer game servers to share the same Internet-visible IP address while still protecting the servers and LAN users from hackers.
  • Page 7 Chapter 1 Introduction Firewall: Supports SOHO firewall with NAT technology. Automatically detects and blocks the Denial of Service (DoS) attack. The URL-blocking, packet filtering and SPI are also supported. The hacker’s attack will be recorded associated with timestamp in the security logging area. More firewall features will be added continually, please visit our web site to download latest firmware.

  • Page 8: Bipac-741 Ge V2.0 Application

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router Web based GUI: supports web based GUI for configuration and management. It is user-friendly with an on-line help, providing necessary information and assist user timing. It also supports remote management capability for remote users to configure and manage this product. Firmware Upgradeable: the device can be upgraded to the latest firmware through the WEB based GUI.

  • Page 9: Chapter 2

    Chapter 2 Using BIPAC-741 GE V2.0 2.1 Cautions for using the BIPAC-741 GE V2.0 Do not place the BIPAC-741 GE V2.0 under high humidity and high temperature. Do not use the same power source for BIPAC-741 GE V2.0 with other equipment. Do not open or repair the case yourself.

  • Page 10: The Rear Ports

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router Lit when connected to Ethernet device LAN port 4 Green for 100Mbps; Orange for 10Mbps Blinking when data transmit/received Lit when there is email in the email account MAIL Lit when there is a PPPoA/PPPoE connection Lit when successfully connected to an ADSL ADSL DSLAM...

  • Page 11: Cabling

    Chapter 2 Using BIPAC-741 GE V2.0 2.4 Cabling The most common problem is bad cabling or ADSL line. Make sure that all connected devices are turned on. On the front of the product is a bank of LEDs. As a first check, verify that the LAN Link and ADSL line LEDs are lit.

  • Page 12: Chapter 3

    Chapter 3 Configuration The BIPAC-741 GE V2.0 can be configured with your Web browser. The web browser is included as a standard application in the following operation systems, UNIX, Linux, Mac OS, Windows 98/NT/2000/Me, and etc. The product provides a very easy and user-friendly interface for configuration.

  • Page 13: Configuring Pc In Windows

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router 3.3 Configuring PC in Windows 3.3.1 For Windows 98/ME 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP / IP -> NE2000 Compatible, or the name of any Network Interface Card (NIC) in your PC.
  • Page 14 Chapter 3 Configuration 5. Then select the DNS Configuration tab. 6. Select the Disable DNS radio button and click “OK” to finish the configuration.

  • Page 15: For Windows Nt4.0

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router 3.3.2 For Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.

  • Page 16: For Windows 2000

    Chapter 3 Configuration 3.3.3 For Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click LAN Area Connection. 3. In the LAN Area Connection Status window, click Properties.
  • Page 17 Billion BIPAC-741 GE V2.0 ADSL Firewall Router 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration.

  • Page 18: For Windows Xp

    Chapter 3 Configuration 3.3.4 For Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections. 2. Double-click Local Area Connection 3. In the LAN Area Connection Status window, click Properties.
  • Page 19 Billion BIPAC-741 GE V2.0 ADSL Firewall Router 4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons 6. Click OK to finish the configuration.

  • Page 20: Factory Default Settings

    Chapter 3 Configuration 3.4 Factory Default Settings Before configurating this BIPAC-741 GE V2.0 , you need to know the following default settings. 1. Web Configurator Username: admin Password : admin 2. Device IP Network settings in LAN site IP Address : 192.168.1.254 Subnet Mask : 255.255.255.0 3.

  • Page 21: Lan And Wan Port Addresses

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router If you ever forget the password to log in, you may press the RESET button to restore the factory default settings.. 3.4.2 LAN and WAN Port Addresses The parameters of LAN and WAN ports are pre-set in the factory. The default values are shown below.

  • Page 22: Configuring With The Web Browser

    Chapter 3 Configuration VPI/VCI, IP address, Subnet mask, Gateway address, and IPoA Domain Name System (DNS) IP address (it is fixed IP address). 3.6 Configuring with the Web Browser Open the web browser, enter the local port IP address of this BIPAC-741 GE V2.0, which defaults at 192.168.1.254, and click “Go”, a user name and password window prompt will appear.

  • Page 23: Status

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router At the configuration homepage, the left navigation pane where bookmarks are provided links you directly to the desired setup page, including: Status (ARP Table, PPTP Status, IPSec Status, Email Status, Event Log, Error Log and UPnP Portmap) Quick Start Configuration (LAN, WAN, System, Firewall, VPN, Virtual Server &...

  • Page 24: Quick Start

    Chapter 3 Configuration When you click the UPnP Portmap, it displays the Virtual Servers (or Port Mappings) that created by UPnP protocol implemented in Windows. 3.6.2 Quick Start If you use this device to access the Internet through the ISP, this web page is enough for you to configure this router and access the Internet without a problem.
  • Page 25 Billion BIPAC-741 GE V2.0 ADSL Firewall Router It supports two Ethernet IP addresses in the LAN. With this function, the ADSL router can support two different LAN subnets to access the Internet at the same time. Usually, there is only one subnet in LAN, there is no need to configure a Secondary IP address.
  • Page 26 Chapter 3 Configuration Port # Connection Type: Five options to choose from: auto, 10M half-duplex, 10M full-duplex, 100M half-duplex or 100M full-duplex. Sometimes, there are Ethernet compatibility problems with legacy Ethernet devices. You can configure different types to solve the compatibility issues.

  • Page 27: Wan

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router If you check DHCP Relay Agent and click Next, then you will have to enter the IP address of the DHCP server which will assign an IP address back to the DHCP client in the LAN. Click Apply to enable this function.
  • Page 28 Chapter 3 Configuration Username: Enter the username provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive). Password: Enter the password provided by your ISP. You can input up to 128 alphanumeric characters (case sensitive). Service Name: This item is for identification purpose. If it is required, your ISP will provide you the information.

  • Page 29: System

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router A Domain Name System (DNS) contains a mapping table for domain name and IP addresses. In the Internet, every host has a unique and friendly name such as www.yahoo.com and an IP address. As the IP Address is hard to remember, the DNS converts the friendly name into its equivalent IP Address.
  • Page 30 Chapter 3 Configuration The router does not have a real time clock on board; instead, it uses the simple network time protocol (SNTP) to get the current time from the SNTP server from the outside network. Please choose your local time zone, click Enable and click the Apply button. You will get the correct time information after you ready establish a connection to the Internet.

  • Page 31: Firewall

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router 3.6.3.4 Firewall There are five items under the Firewall section: General Settings, Packet Filter, Intrusion Detection, MAC Address Filter and URL Filter. When you click General Settings, you get the following figure. Firewall: When you enable the Firewall function, you can select one of the firewall security policies.
  • Page 32 Chapter 3 Configuration You may configure to filter inbound (incoming) and outbound (outgoing) packets based on PORT or IP address. If it is based on PORT, click Port Filters for more options. You may filter the packets based on PORT and packet type (TCP or UDP or any). For example, the protocol number 1 means ICMP. You may enter 1 to protocol number of Raw IP Filtering web page.
  • Page 33 Billion BIPAC-741 GE V2.0 ADSL Firewall Router Enable: Set True to enable this Intrusion detection. Use BlackList: Set True to use router’s default backlist to protect router. Use Victim Protection: Set True to enable Victim protection. Victim Protection Duration: Input numbers. DoS Block Duration: Input numbers.
  • Page 34 Chapter 3 Configuration When you click the URL Filter, you get the following figure. The URL filtering function enables you to block unwanted websites from accessing inappropriate material from the entire enterprise. Enable / Disable: Check Enable / Disable radio button to active / disable, respectively the URL filter function.
  • Page 35 Billion BIPAC-741 GE V2.0 ADSL Firewall Router The ADSL Router allows the administrator to block some WEB URLs containing certain keywords in this page. For example, if the keyword “xxx” is listed, the URL http://www.new.site.com/xxx.html would be blocked, even if it is not included in the domain filtering list.

  • Page 36: Vpn

    Chapter 3 Configuration To add a domain name, enter its host name, such as www.bad-site.com into the text field under Domain and select either Trusted Domain or Forbidden Domain, then click Apply. The specified domain will be shown in the Domain List. DO NOT include http://, ONLY the sub- domain is allowed.
  • Page 37 Billion BIPAC-741 GE V2.0 ADSL Firewall Router Type: Check Dial Out to be a client, check Dial In to be a server. When this network router acts as a client, please input the remote Server IP Address (or Hostname) to establish a connection. When this network router acts as a server, please input the Private IP Address Assigned to Dial in User address.
  • Page 38 Chapter 3 Configuration Netmask: Enter the subnet mask of peer network based on above Peer Network IP setting. Username: If you are a Dial-Out user (client), enter the username provided by your Host. If you are a Dial-In user (server), enter your own username. Password: If you are a Dial-Out user (client), enter the password provided by the your Host.
  • Page 39 Billion BIPAC-741 GE V2.0 ADSL Firewall Router Connection Name: Give a name for this connection. Local Network: Set the IP address, subnet or address range of the local network. Single Address: The IP address of the local host. Subnet: The subnet of the local network. For example, IP: 192.168.1.0 with netmask 255.255.255.0 specifies one class C subnet starting from 192.168.1.1.

  • Page 40: Virtual Server

    Chapter 3 Configuration Perfect Forward Secrecy: Enable this to change encryption keys during the second phase of VPN negotiation. This function will provide better security, but extends the VPN negotiation time. Pre-shared Key: This is a string from 4 characters to 128 characters. Both sides should use the same key.

  • Page 41: Advanced

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router Being a natural Internet firewall, this network router protects your network from being accessed by outside users. When it needs to allow outside users to access internal servers, e.g. Web server, FTP server, E-mail server or News server, this modem can act as a virtual server. You can set up a local server with specific a port number that stands for the service, e.g.
  • Page 42 Chapter 3 Configuration Destination: Enter the destination subnet IP. Netmask: Subnet mask of destination IP addresses based on above destination subnet IP. Gateway: Enter the gateway IP address which the packet is forwarded to. Interface: Enter the interface which the packet is forwarded to. Cost: This is the same meaning as Hop.
  • Page 43 Billion BIPAC-741 GE V2.0 ADSL Firewall Router The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname. This dynamic IP address is the WAN IP address. For example, to use the service, you must first apply for an account from this free Web server http://www.dyndns.org/.
  • Page 44 Chapter 3 Configuration Automatically dial-out for checking emails: When the function is enabled, your ADSL router will connect to your ISP automatically to check emails if your Internet connection dropped. Please be careful when using this feature if your ADSL service is charged by time. Click Device Management to protect and obtain system control while allowing device monitoring.

  • Page 45: Save Configuration To Flash

    Billion BIPAC-741 GE V2.0 ADSL Firewall Router UPnP Port: Its default setting is 2800. It is highly recommended for users to use this port value. You may wish to modify this port value, only if this value conflicts with other ports already being used.

  • Page 46: Chapter 4

    Chapter 4 Troubleshooting If the ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider. This could save you time and effort but if the symptoms persist, then consult your service provider. Problems Starting Up the BIPAC-741 GE V2.0 Problem Corrective Action...

  • Page 47: Appendix A

    APPENDIX A Specification IP, NAT, PPTP, ARP, ICMP, DHCP, PPPoE, PPPoA, IPoA, Protocols PPTP client, RIP1/2 RJ-45, 4 ports 10/100Base-T LAN switch LAN Port RJ-11, 1 ADSL port WAN Port Power, System, LAN 1 to 4, MAIL, PPP and ADSL LED Indicators 12V DC @ 1A Input Power...

  • Page 48: Product Support

    APPENDIX B Product Support Most problems can be solved by using the Troubleshooting in Chapter 4. If you cannot resolve the problem with the Troubleshooting Chapter, please contact the dealer where you purchased this product. You can also call the Billion Support line at 1300 139159 or email support at support@billion.com.au You can also download the latest firmware and utilities from the Billion Australia website at http://www.billion.com.au...
