LK‐FP3 Fire Control Panel

Feature
 The control panel is used for the control of electric window opener to achieve
natural ventilation and fire smoke removal
 Panel with open/stop/close auto/manual selection buttons and LED indicators
 Single channel 1‐4 group(s) output
 Can be cascade control with LK‐CP6/7/8 controllers to  achieve the windows of
single control, partition control and group control
 Can  handle  external  input  signals  of  Manual  Switch,  Remote  Control,  Timer,
Smoke/Gas/ Rain /Temperature & Humidity Sensors
 Output fire feedback signal to fire centre
 Compatible with all Linkayl remote
 Output DC24V 30A‐80A
 Size 500*400*200mm















LED & KEY

LED/KEY  Symbol
Color
L1
Run
Red
L2
Power
Green
L3
Linkage
Red
Burst flash, buzzer alarm after receiving a fire signal
L4
Auto
Green
K1
A/M
Green
Default is automatic mode, press it to manual mode
K2
Open
Red
K3
Stop
Red
K4
Close
Red
K5


Description
Normally on when motor running
Power indicator
Auto mode on, manual mode off
Open
Stop
Close
Reset switch, on the mother board


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK-FP3 and is the answer not in the manual?

Questions and answers

Summary of Contents for LinkAYL LK-FP3

  • Page 1  Can  handle  external  input  signals  of  Manual  Switch,  Remote  Control,  Timer,  L4  Auto  Green Auto mode on, manual mode off  Smoke/Gas/ Rain /Temperature & Humidity Sensors  K1  A/M  Green Default is automatic mode, press it to manual mode   Output fire feedback signal to fire centre  K2  Open  Open   Compatible with all Linkayl remote  K3  Stop  Stop   Output DC24V 30A‐80A  K4  Close  Close   Size 500*400*200mm  K5      Reset switch, on the mother board ...
  • Page 2: Wiring Description

    Wiring Description  Terminals  Symbol  Description  Symbol  Description  AC Live wire  Manual switch stop  L  MU  AC Null wire  Manual switch down  N  MS  AC Earth wire  Manual switch GND  E  MD  Manual switch GND  24V+  DC24V Positive  MG  Slave control up  24V‐  DC24V Negative  SI+  Slave control down  M1 + / M1 ‐  Motor Group 1 P/N  SI‐  Fire signal input  M2 + / M2 ‐  Motor Group 2 P/N  FI  Rain sensor down  M3 + / M3 ‐  Motor Group 3 P/N  WRD  Timer up  M4 + / M4 ‐  Motor Group 4 P/N ...
  • Page 3: Operating Mode

    Operating mode  Remote control   Control panel has automatic and manual modes, the default is automatic mode   The  controler  encodes  by  433MHz  learning  code,  can  store  10  sets  of   In  automatic  mode,  the  controller  receives  all  external  signals  and  can  shield  transmission codes  the external signal by switching     In manual mode, the controller shields the fire signal and receives other inputs  Matching Code     Power the controler on  Output Time  ...
  • Page 4: Signal Control

    Signal and Priority  Cascaded Control  Priority  1  2  3  4  5   Can  be  used  as  a  master  controler,  a  slave  controler  or  play  a  dual  role  of  Signal  Manual Signal  Fire Signal  R Signal  Time Signal T/H Signal    master & slave controler at the same time.    Panel buttons  temperature   As a master controler, connects to the motors or slave controlers to drive them  Manual switch  Smoke sensor Wired ...
  • Page 5: Installation Instruction

    Installation instruction  Troubleshooting   Please read the following instructions carefully before installing this product  No.  Symptom  Solution   Installing  this  product  must  comply  with  the  effective  local  electricity  1. Check the connection of wires  specifications    1  LED flashes, receiver shut down  2. Check the receiver setting   The control system must be installed by the professional    1. Make sure battery installed well   The main power must be cut off before wiring to ensure safe operation  2  LED on the transmitter is off or weak  2. Change the battery   The control box can not be installed outdoors  The transmitter and the receiver work  1. Check the wiring of motor   The maximum output power of the control box can not exceed the rated total  3  well, the motor does not work ...
