LinkAYL LK-CP611 Manual

LK‐CP611 CONTROL PANEL
Feature
 Controller is used for window opener, curtain motor 24VDC motor control
 Power indicator/reset, Open/Stop/Close buttons with backlight
 Cascade control can be cascaded with LK‐UP2，LK‐FP3，LK‐CP6/CP7/CP8 control
panel that achieves windows of zone control and group control
 Can handle external input signal of Manual Switch, Remote Control, Timer
Smoke/Gas/Wind & Rain /Temperature & Humidity Sensors
 Output fire feedback signal to fire centre
 Compatible with Linkayl remote, with stroke memory function
 Built‐in switching power supply 10/15/20 / 25A
Model List
Power Control
Model
(W) Method
LK‐CP611‐10A 240
LK‐CP611‐15A 360
1 way single
LK‐CP611‐20A 480
LK‐CP611‐25A 600
Input Volt Output Temp
(V) Volt (V) (℃)
‐20
DC24
～
AC110/AC230
DC12
+65
Application
Model
LK‐CP611‐10A
LK‐CP611‐15A
LK‐CP611‐20A
LK‐CP611‐25A
Key & LED
Led/Key
L1 / K1
Size
(mm)
L2 / K2
L3 / K3
272(L)
L4 / K4
228(W)71
(H)
LK‐SCE‐D LK‐LCD LK‐TC LK‐L LK‐L‐S
8 5 2 5
12 7 3 7
16 10 5 10
20 12 6 12
Color Status
Blue On / Off
Green On / Off / Flash
Red
Yellow
LK‐L38A LK‐L38A
600N/1000N 1500N
5 5 3
7 7 5
10 10 6
12 12 8
Function
AC power indicator, Reset
Open
Stop
Close
