Summary of Contents for EWIKON Multi 5
- Page 1 Operating manual for Multi 5 hotrunner controllers...
-
Page 2: Table Of Contents
Table of Contents General Information Safety Instructions............3 General Instructions............3 Controller Start-Up................4 Front Panel..............4 Setting Setpoints & Activating Control Zones....5 Function Keys............... 5 Alarm Indicators............6 Programming Menu............6 Changing Settings............7 Soft-Start Ramp............7 Manual Mode..............8 Specifications ..................9 Connections Alarm Connector............9 10-Pole................10 24-Pole................11 Important operating instructions! Read carefully! -
Page 3: Safety Instructions
Safety Instructions - Please read these Operating Instructions carefully prior to using your EWIKON Multi 5 controller! - Always withdraw the mains plug before performing any service work on the controller, particularly before opening the housing. - Always disconnect the controller from the mains before replacing fuses. -
Page 4: Start-Up
Start-Up After verifying that all cables are intact and have been properly connected, connect the mould to the controller. If required, a connection can also be made to the machine by using the optional alarm connector. Connect the mains cable to the power supply, then switch on the controller by means of the main switch located on the rear panel. Select the desired setpoint. -
Page 5: Setting Setpoints & Activating Control Zones
Setting Setpoints & Activating Control Zones Button Command Display / Result Display setpoint Upon pressing this button, the setpoints are displayed in the zone windows of the active zones (or "OFF" for the non-active zones). The button indicator lights up. Zone identification "ALL"... -
Page 6: Alarm Indicators
Alarm Indicators Earth fault Lights up if the heating-element-to-earth resistance drops below 100 kW, the power supply is interrupted two-pole in addition. Thermocouple Lights up in the event of sensor breakage; at the same time, "- - -" is shown in the zone window. In automode, the information displayed alternates between "... -
Page 7: Changing Settings
Changing Settings Button Command Display / Result For more Change "ALL" is displayed in the dialog window, while the zone than 3s settings numbers are shown in the zone windows. Select zone The number of the selected zone is displayed in the dialog window (or "ALL"... -
Page 8: Manual Mode
Manual-Mode ATTENTION: In this mode the hotrunner is not controlled and not switched off in case of overtemperature. So overtemperature and damaging is possible! Button Command Display / Result Display setpoint Upon pressing this button, the setpoints are displayed in the zone windows of the active zones (or "OFF"... -
Page 9: Specifications
Specifications Housing: Metal half-shell housing MULTI 5: approx. 250 x 200 x 420 (WxHxD) MULTI 10: approx. 470 x 200 x 420 (WxHxD) MULTI 20: approx. 470 x 330 x 420 (WxHxD) Connection: Load and Sensor (T/C) separate; 10-, 24-pole (depending on the number of zones provided) -
Page 10: 10-Pole
Connections Multi 5 10-pole Zone Load T / C 1 / 6 1(+) / 6(-) 2 / 7 2(+) / 7(-) Housing height 3 / 8 3(+) / 8(-) 4 / 9 4(+) / 9(-) 83 93 Fixing 5 / 10... -
Page 11: 24-Pole
Connections Multi 10, 20 24-pole Zone Load T / C Connector 1 1 / 13 1(+) / 13(-) 2 / 14 2(+) / 14(-) 3 / 15 3(+) / 15(-) 4 / 16 4(+) / 16(-) 5 / 17 5(+) / 17(-) Housing height 6 / 18 6(+) / 18(-) - Page 12 EWIKON Heißkanalsysteme Your EWIKON-partner: GmbH & Co. KG Siegener Straße 35 35066 Frankenberg Tel: (+49) 64 51 / 50 10 Fax: (+49) 64 51 / 50 12 02 E-mail: info@ewikon.com www.ewikon.com...
