OVER-ALL
MODEL : S1920, S1921, S1925 / S1900, S1901, S1905 / S1910, S1911, S1915
GROUND INSTALLATION
REMOTE DRIVER (REM)
A- UNCLIP THE FIXTURE FROM ITS BASE USING THE WEDGE TOOL (INCLUDED).
B- USING THE HOLES ON THE FIXTURE BASE, PREPARE SURFACE FOR INSTALLATION.
C- INSTALL (3) ANCHORS (NOT INCLUDED) INTO THE SURFACE.
A
FIXTURE
HEAD
WEDGE TOOL
(INCLUDED)
FIXTURE
BASE
C
ANCHORS
(NOT INCLUDED)
CONDUIT
INS-508
INSTRUCTIONS SHEET
B
CONDUIT
FIXTURE BASE
B
MODEL
MICRO
MINI
OVER-ALL
Last update: December 07, 2020
9320 Boul. St-Laurent, suite 100, Montréal (Québec) Canada H2N 1N7
P.: 514.523.1339 F.: 514.525.6107 www.sistemalux.com
PAGE: 1 of 4
B
⁄
3
"
16
(5,20mm)
¼"
(6,30mm)
¼"
(6,30mm)
CL - R0
