Dimensions; Cylinder - Danfoss Maneurop NTZ Series Application Manuallines

Application Guidelines

1 cylinder

Schrader
1/4"
98
25
109
35°
68
Suction 147
Discharge 142
159
NTZ048
NTZ068
8
FRCC.PC.046.A4.02

Dimensions

ø 224
Oil equalisation
3/8"
68
PTC crankcase heater
118
33°
Threaded oil
sight glass
39
141
123
17
17°
Rotolock connections size
Suction Discharge
1"1/4 1"
Suction rotolock
1"1/4
333
353 (NTZ068-1)
Discharge rotolock
1"
68
Silent block
Terminal box
IP rating: 55 (with cable gland)
Pipe sizing
Suction Discharge
5/8"
82
Spade connectors
1/4" AMP-AWE
Earth M4-12
Knock-out Ø 21 mm
Rotolock valve
Suction
1/2" V09
263
HM8-40
23
15
Ø 21 mm
Discharge
V06
