Daewoo Cyclone Freedom Pro User Manual page 10

Replacing the Filters in Your Cordless Vacuum Cleaner
7
8. Finally place the Motor Housing (10) onto the
Dust Compartment (4) and rotate clockwise
until the alignment mark lines up with the
locked symbol as shown circled right.
Care and Use of your Cordless Vacuum Cleaner
• Always disconnect the cleaner from the mains charger before cleaning.
• Clean outside of the cleaner with a clean damp cloth. Never clean with harsh or abrasive
cleaners.
• Do not submerge the cleaner or its charger in water or any other liquids.
• Empty the Dust Compartment (4) as soon as the 'MAX' mark has been reached.*
• Wash the Conical Hepa and Cyclonic Filters (2) regularly – see table below.
• Allow the filters to thoroughly dry out for 24 hours before reassembly and use.
*WARNING do not continue to use your vacuum cleaner once the 'MAX' mark has been
reached as permanent damage may occur to the appliance.
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Freedom Pro 22.2V Cordless Vacuum
7. First replace the Cyclonic Filter (2) into
the Dust Compartment (4), ensure that
the two arrows on the cyclonic filter and
the Dust Compartment (4) line up as
shown circled left.
Next replace the Conical Hepa Filter (2)
inside the Cyclonic Filter, rotate the filter
clockwise towards the 'LOCK' position as
shown circled left.
FLR00040
User Manual
10
