- Page 1 Keysight E6953A V2X Test Solution with 802.11p, DSRC and ITS-G5 Installation & User Guide...
- Page 2 227.7103-5 (c), as applicable in any Do not proceed beyond a WARNING technical data. notice until the indicated conditions are fully understood and met. Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 3 The Mains wiring and connectors shall be compatible with the connector CAUTION used in the premise electrical system. Failure, to ensure adequate earth grounding by not using the correct components may cause product damage, and serious injury. Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 4 This product is designed for use in Installation Category II and Pollution CAUTION Degree 2 environment. Use the Keysight supplied power cord or one with the same or better electrical NOTE rating. Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 5: Omniair Conformity
OmniAir Conformity The Keysight E6953A V2X Test Solution with 802.11p, DSRC and ITS-G5 is an OmniAir certified test equipment provider. For more information, see the URL below: https://omniair.org/certified-products/keysight-v2x-test-solution/ Keysight E6953A V2X Test Solution Installation & User Guide... -
Page 6: Electrical Safety Compliance
Electrical Safety Compliance SAFETY Complies with European Low Voltage Directive 2014/35/EU – "IEC/EN 61010-1, 3rd Edition – "Canada: CAN/CSA C22.2 No. 61010-1-12 – "USA: ANSI/UL std no. 61010-1, 3rd Edition Keysight E6953A V2X Test Solution Installation & User Guide... -
Page 7: Emi And Emc Compliance
During the warranty period, Keysight Technologies will, at its option, either repair or replace products that prove to be defective. For warranty service or repair, this product must be returned to a service facility designated by Keysight Technologies. -
Page 8: Where To Find The Latest Information
URL: www.keysight.com/find/E6953A Is Your Product Software Up-to-Date? Keysight will periodically release software updates to fix known defects and incorporate product enhancements. To search for software updates for your product, go to the Keysight Software Manager website at: www.keysight.com/find/softwaremanager... -
Page 9: Table Of Contents
..........32 Keysight E6953A V2X Test Solution Installation & User Guide... - Page 10 ........64 Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 11 Keysight E6953A V2X Test Solution Installation & User Guide Introduction Overview References...
-
Page 12: Introduction
Introduction Overview Welcome to the Installation and User Guide for the Keysight E6953A DSRC V2X Test Solution. This guide provides the basic steps for getting started as well as provides additional helpful information. This guide covers the installation of the... -
Page 13: References
2 M9420A/21A VXT Vector Transceiver Getting Started Guide https://www.keysight.com/main/ redirector.jspx?action=ref&cname=EDITORIAL&ckey=2674468&lc=eng&cc= GB&nfr=-32487.1180858.00 3 KS8400A Test Automation Platform Developer's System https://www.keysight.com/en/pd-2747943-pn-KS8400A/ test-automation-platform-developers-system?cc=US&lc=eng 4 TAP Training: Introduction to using TAP https://www.keysight.com/upload/cmc_upload/All/ TAP_Training_1_GUI_Lab.pdf 5 OmniAir Test Specifications https://github.com/certificationoperatingcouncil/COC_TestSpecs Keysight E6953A V2X Test Solution Installation & User Guide... - Page 14 Introduction THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 15 Keysight E6953A V2X Test Solution Installation & User Guide Installation Hardware Installation Hardware Functionality PXIe V2X Transceiver Card (E9653-35200) Software Installation Software Components Compatibility Test System Time Synchronization Licensing...
-
Page 16: Installation
Installation Hardware Installation The Keysight E6953A V2X test solution is a combination of Keysight PXI HW components: – PXIe Vector Transceiver Instrument (M9421A) – PXIe V2X Transceiver card (E9653-35200) – PXI Switch card (M9155C) – PXI Frequency reference card (M9300A) -
Page 17: Hardware Functionality
Allows Test System to perform testing for IEEE802.11p, IEEE1609.2/3/4 PXI Switch card (M9155C) and SAEJ2945/1 automatically. PXI Frequency Reference (M9300A) Provides reference signals (10MHz or 100MHz) the M9421A VXT Standard System Cabling Keysight E6953A V2X Test Solution Installation & User Guide... - Page 18 Installation Below is the complete setup for standard system cabling for Keysight E6953A V2X test solution. Figure 2-2 Standard system cabling for Keysight E6953A V2X test solution Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 19: Pxie V2X Transceiver Card (E9653-35200)
Environmental Limits: Table 2-3 List of environmental limits Opening Temperature 0°C to 40°C Humidity 10 ~85% @40°C, non-condensing Vibration Vibration (5 ~ 500Hz) 1Grms Cooling Cooling: 2FAN (12cm / 85CFM each) Keysight E6953A V2X Test Solution Installation & User Guide... -
Page 20: Certificate Update
Once the certificate files are unzipped, create the certificate using the commands below. As an example, the RSU certificate will be created below: – cd rsu – mkdir output – certadm add - binary rse - 0/trustedcerts/pca Keysight E6953A V2X Test Solution Installation & User Guide... - Page 21 Commands for creating the certificate for Transceiver card are follows: Use the following commands after unzipping the OBU certificate files. NOTE – cd obu – mkdir output – certadm add - binary obu/[file name that located in obu directory]/ trustedcert/pca Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 22 It is possible to check what files were created from the above command by using the ls output command. The acf certificate files for OBU needs to be copied to the appropriate directory as below: /root/wave/7.4.27/aerolink/certificates Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 23: Software Installation
Installation Software Installation The SW components required for the E6953A V2X test solution are installed separately. Please install the components in the following order: 1 Install the VXT SW M9420A/21A VXT Vector Transceiver WLAN Measurement application. Installation steps can be found in the... - Page 24 Installation The Tap Plugin Manager can be used to either install or view the status of each of the plugin components. Figure 2-3 TAP Plugin Manager Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 25: Software Components Compatibility
Keysight IO Libraries 17.2.20828.2 Only the versions of the SW components shown here have been tested as a NOTE complete system. Changes to individual components may cause unexpected results and is not recommended. Keysight E6953A V2X Test Solution Installation & User Guide... -
Page 26: Test System Time Synchronization
1 Check time accuracy against atomic time. Launch the browser and go to https://time.is. The website will give the accuracy of your system time as shown below: Figure 2-4 Accurate time shown on Time.is Keysight E6953A V2X Test Solution Installation & User Guide... - Page 27 Figure 2-5 Time sync command prompt 3 After the above command, restart the test system and check your time against https://time.is again. The time is then synchronized and testing can proceed. Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 28: Licensing
– KS83204B-1FP/1TP V2X OmniAir DSRC Protocol (1609.2/3/4, J2945/1) test suite – KS83205B-1FP/1TP V2X TCI Interface support The license status of the TAP Plugins can be seen using the TAP Plugin manager: Figure 2-6 License status in TAP Plugin Manager Keysight E6953A V2X Test Solution Installation & User Guide... - Page 29 Keysight E6953A V2X Test Solution Installation & User Guide User Guide Introduction Test Step Selection Global Settings Test Step Settings Test Plan Cable Loss Calibration...
-
Page 30: User Guide
The V2X Test Solution test steps are enabled by the V2X Tap Plugin and allow the selection of the following test cases to either be run individually, as a group or as part of the test plan. Figure 3-1 Adding a new step Keysight E6953A V2X Test Solution Installation & User Guide... - Page 31 To select a test step either double click or click the Add button. This will make the test step available to configure its settings and run either individually or as part of a group of tests. Figure 3-2 Common parameters and settings for all test steps Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 32: Global Settings
Use the +/- keys to add a VXT instrument. Configure the VISA Address. This is typically TCPIP0::127.0.0.1::hislip1::INSTR. The hislip number can be found on the VXT SW application under the System > IOConfig > SCPI LAN menu. Keysight E6953A V2X Test Solution Installation & User Guide... - Page 33 The VISA I/O timeout is the value used to timeout SCPI interactions. In the event a measurement is configured to take 50 seconds (500 bursts at 100 mS intervals) then this timeout must be set accordingly. Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 34 User Guide Figure 3-5 Setting the timeout accordingly Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 35 Figure 3-6 Adding a DSRC instrument Optionally, a Keysight M9155C RF Switch can be added into the system to allow for dynamic switching of the Receive and Transmit paths. This is particularly useful if the Tx/Rx paths are configured with different attenuation settings. When...
- Page 36 Receive and Transmit paths The VISA address of this instrument can be selected using the dropdown list. Use the Keysight Connection Expert Utility to best identify the switch to use. Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 37: Duts (Device Under Test)
User Guide DUTs (Device Under Test) DUTs can be added in a similar manner (Settings->Bench->DUTs) as Instruments in the previous section. Figure 3-8 DUT settings Keysight E6953A V2X Test Solution Installation & User Guide... - Page 38 – TCI V2X DUT If the V2XTCI Tap Plugin is licensed and loaded then the selection of a TCI capable DUT is possible. This generic DUT control mechanism allows V2X configuration of devices from multiple manufacturers. The following TCI settings are available Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 39 – IP Address (Ipv4) - This field sets the Ipv4 address of the IUT. The test system TCI interface uses this value to communicate with the DUT. – TCP Port - This field sets the UDP port number for TCI communication. Default value is “13001”. Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 40 Settings->V2X panel. Figure 3-11 The V2X settings panel This V2X settings panel also contains the common SA (Spectrum Analyzer) save screen control which is applicable to all 802.11p V2X Transmitter test steps. Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 41: Connections
VXT ports (RFIn, RFOut or RFHD) to "Port 2" which is the Antenna port on the DUT in use. A choice of either a Direct connection or Via the RF switch is Keysight E6953A V2X Test Solution Installation & User Guide... - Page 42 VXT on a per port basis. This means that different compensation can be applied to RFIn, RFOut and RFHD and these settings will only be applied when the port is selected. Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 43: Test Step Settings
Each of the Test Steps have a number of configurable parameters as shown below. Note that not all setting parameters are applicable to every test case e.g. Channel number applies to all test cases. Figure 3-14 Step Settings Keysight E6953A V2X Test Solution Installation & User Guide... - Page 44 If the PXI Switch (M9155C) is present in the system, then it will be shown instead of the VXT RF Input/Output field and the Test Step will dynamically route the RF path accordingly. Figure 3-15 Step Settings with PXI Switch (M9155C) present Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 45: Channel Number Invalid
160 to 190 in even numbers. Choose any value in this range other than the Channel Number (Valid) as your invalid channel number. Figure 3-16 Step Settings with Channel Number (Invalid) Keysight E6953A V2X Test Solution Installation & User Guide... -
Page 46: Test Plan
V2X OmniAir 80211p Single Channel Data Rate.TapPlan V2X OmniAir 80211p.TapPlan V2X OmniAir DSRC 16092.TapPlan V2X OmniAir DSRC 16093.TapPlan V2X OmniAir DSRC 16094.TapPlan V2X OmniAir DSRC 29451.TapPlan V2X OmniAir DSRC 29451 Restart.TapPlan Keysight E6953A V2X Test Solution Installation & User Guide... - Page 47 802.11p test steps in V2X OmniAir 80211p Abbreviated Test Plan Each of the Test Steps e.g. TP-80211-TXT-PHY-BV-01 (Spectrum Mask) is executed within a Channel/Data Rate loop so it will "run" many times using the channel and data rate settings. Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 48: Cable Loss Calibration
A Cable Calibration test step is included in the V2X Utilities to measure the cables loss in the system. These measured values are not automatically applied to the Cable Loss table (Figure 3-21) but can be manually added. Figure 3-18 Cable Calibration test step Keysight E6953A V2X Test Solution Installation & User Guide... - Page 49 – Path 2 (used for Transmitter testing): – VXT RFHD -> RF Switch -> VXT RFIN DSRC Waveform generated from the RFHD port and channel power is Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 50 4.351232529 dB loss and the “V2X DUT” to VXT RFIN loss was measured as 4.664007664 dB loss. These values should be added into the Cable Loss table. Figure 3-21 Cable Loss table Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 51 User Guide Re-run the Cable Calibration test for the results as shown below: Figure 3-22 Cable Calibration test re-run results Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 52 Tx Power Accuracy If needed this test can be re-run across all the frequency range (channels 172 -184) and additional entries can be made into the Cable Loss table (Figure 3-21). Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 53 Keysight E6953A V2X Test Solution Installation & User Guide Results Result Viewer 802.11p Test Result 1609.2/3/4 and SAEJ2945/1 Test Result Test Report Generation...
-
Page 54: Results
Results), but not the Session Log file name (Settings > Engine)). Additionally, Windows environment variables can be used (enclosed by % symbols): SessionLogs/SessionLog %USERNAME% %SESSIONNAME% .txt Figure 4-1 Set the File Path the results content will be saved to Keysight E6953A V2X Test Solution Installation & User Guide... -
Page 55: 802.11P Test Result
For each Receiver test the user can also enable a capture of the Spectrum Analyzer screen. Figure 4-2 Enable screen capture of the Spectrum Analyzer screen Figure 4-3 Screen capture of the results Keysight E6953A V2X Test Solution Installation & User Guide... -
Page 56: 1609.2/3/4 And Saej2945/1 Test Result
1609.2/3/4 and SAEJ2945/1 Test Result Detail step results for each Protocol test (1609.2/3/4 and J2945/1) are shown in the Log Panel. Figure 4-4 Detail step results are shown in Log Panel Keysight E6953A V2X Test Solution Installation & User Guide... -
Page 57: Test Report Generation
As shown in the previous sections of this guide, TAP provides the capability to save all test results in a CSV format. Keysight provides, as part of the V2XFramework plugin bundle, a report generation utility which parses the CSV file(s) content and creates an overall test report document in Microsoft Word format. - Page 58 The “Generate” button will not be available until all the fields have been entered with valid data. Please note that the report file extension must be a .docx Figure 4-7 V2X Report Generation Utility with data Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 59 After generating the report, a pop up is generated to inform the user that the process is complete. This may take a few minutes to complete, depending on the size of the CSV files. Figure 4-8 Confirmation pop up Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 60 This appears in the generated test report as: Figure 4-9 Generated test report The overall result of the test case is logical, therefore if any of the child test step result fails, the overall test will also fail. Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 61 Spectrum analyzer screen shot The CSV file of 802.11p PHY Transmitter test contains the Windows directory path that links to the saved SA image. This image will be included in the test report document. Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 62 Results THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight E6953A V2X Test Solution Installation & User Guide...
-
Page 63: Appendix
Keysight E6953A V2X Test Solution Installation & User Guide Appendix Service and Support... -
Page 64: Service And Support
Singapore 800 810 0189 0120 (421) 345 1 800 375 8100 Hong Kong Korea Taiwan 800 938 693 080 769 0800 0800 047 866 Other Asian Countries: (65) 6375 8100 www.keysight.com/find/contactus Keysight E6953A V2X Test Solution Installation & User Guide... - Page 65 Luxembourg Switzerland 0805 980 333 0800 80 53 53 +32 800 58580 *0.125 €/minute United Kingdom Netherlands Germany 0800 0260 637 0800 0233 200 0800 6270 999 Other Unlisted Countries: www.keysight.com/find/contactus Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 66 Appendix THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight E6953A V2X Test Solution Installation & User Guide...
- Page 67 This information is subject to change without notice. Always refer to the English version at the Keysight website for the latest revision. © Keysight Technologies 2019 First Edition, January 2019 Printed in Malaysia www.keysight.com...
