Beltronics LaserPro 904 Installation Instructions

Laser defense system
Hide thumbs Also See for LaserPro 904:

Advertisement

Quick Links

M
E
T
S
Y
S
E
Contents of this box includes:
• 2 - weather-proof front Laser Transceivers with "Y" connector
• Weather-proof rear Laser Transceiver with 30" cable
• Pre-assembled mounting brackets to each Laser Transceiver
• 6 - LED Control Display with in-dash or under dash mounting brackets
• 3-port Interface "hub" to make all connections
• Tie-wraps
• Screws
• Spirit level
Ultimate Performance. Proven Technology.
2422 Dunwin Drive
Mississauga, Ontario
Canada L5L 1J9
www.beltronics.com
Questions: 800-939-7373
LaserPro 904 is a trademark of BELTRONICS USA, Inc.
Features and specifications subject to change without notice.
Technology
Proven
Performance.
Ultimate
.
Instructions
Installation
System
Defense
904
LaserPro
S
N
E
F
E
D
R
E
Printed in Canada
Important! Important! Important!
Installation Order of Each Component
LP904
Model
Laser
Please familiarize yourself with all components before installation. In addition,
it is suggested (depending on the vehicle) the 3-port interface "hub" be installed
first (under the vehicle's dash) and wire it to a 12-volt switched circuit. Before
installing the other components, plug each component into the appropriate outlet
in the 3-hole interface "hub" to confirm LaserPro™ 904 is functioning properly.
Installation Warning
It is highly recommended that a professional install LaserPro™ 904.
S
A
L
Installation of LaserPro™ 904 requires experience and expertise in
automotive electronics. Attempting to install LaserPro™ 904 without
expertise in automotive electronics installation could cause personal injury
and or damage to LaserPro™ 904.
If your vehicle is damaged during installation, its safety systems may be
compromised which could cause personal injury or property damage.
Improper installation may void LaserPro™ 904's warranty.
Installation
Since Laser signals do not pass through objects, including plastic, it is important
that the front transceivers be mounted with a clear, unobstructed view of the road
ahead, and completely level.
272004-20
