Owners &
Installation
Alterra F175B-2 Freestanding Wood Fire
Model: F175B-2
PLEASE KEEP THESE INSTRUCTIONS FOR
FUTURE REFERENCE
WARNING:
Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to this manual. For assistance or
additional information consult an authorised installer, service agency or
the distributor.
FOR YOUR SAFETY
Do not store or use petrol or other flammable vapours and liquids in the
vicinity of this or any other appliance.
Installation and service must be performed by an authorised installer or
service agency.
FPI - FIREPLACE PRODUCTS AUSTRALIA PTY LTD.
919-096f
May-05-2021
1 CONQUEST WAY HALLAM VICTORIA 3803
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Fireplace Products Alterra F175B-2
Summary of Contents for Regency Fireplace Products Alterra F175B-2
- Page 1 Owners & Installation Alterra F175B-2 Freestanding Wood Fire Model: F175B-2 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult an authorised installer, service agency or the distributor.
- Page 2 Thank-you for purchasing a REGENCY FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area.
-
Page 3: Table Of Contents
table of contents Data Badge ................4 MAINTENANCE Unit Dimensions ..............5 Maintenance ................10 INSTALLATION Creosote ................10 Residential Installation ............6 - Ways to Prevent & Keep Units Free of Creosote ..10 Safety Guidelines and Warnings ...........6 Glass Maintenance ..............10 Brick Installation ..............6 Door Latch Adjustment ............10 Side Panel Installation ............7 Wood Storage ..............10... -
Page 4: Data Badge
Wood Fire. We have printed a copy of the contents here for your review. the unit and if there is a difference, the label on the unit is the correct one. MAKE: REGENCY TYPE: FREESTANDING WOODFIRE Model: ALTERRA F175B-2 Serial Number TESTED BY: TEST REPORT NUMBER: HCMG/15/030 HRL TECHNOLOGY PTY LTD. -
Page 5: Unit Dimensions
dimensions DIMENSIONS 726mm 152mm 773mm 461mm 34mm 460mm 430mm 721mm Regency Alterra Freestanding Wood Fire... -
Page 6: Installation Residential Installation
installation RESIDENTIAL even reduced heat output. Too tall a flue may 10) Do not use grates or andirons or other prompt excessive draft which can result in methods for supporting fuel. Burn directly INSTALLATION very short burn times and excessive heat on the base or bricks where supplied. -
Page 7: Side Panel Installation
installation SIDE PANEL INSTALLATION Install side panels with screws as shown in diagram. Diagram 1 - Side Panel Install FAN INSTALLATION A 2 speed fan is supplied and needs to be fitted to the rear of the unit with screws supplied. Diagram 2 - Fan Wiring Diagram Diagram 1 - Fan Install Regency Alterra Freestanding Wood Fire... -
Page 8: Clearance To Combustibles
installation MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALS Universal Default (1) Special (2) 475mm 475mm 160mm 160mm 175mm 175mm 160mm 160mm 78mm 78mm 300mm 300mm 875mm 875mm 969mm 969mm * Wall clearance taken from rear shield (not fan). Floor Protection A combustible floor must be protected by non-combustible material (like tile, concrete board, or as defined by local codes) extending beneath the heater as follows;... -
Page 9: Operating Instructions Operating Instructions
operating instructions FIRST FIRE OPERATING automatically controlled by the selection on the fan speed switch and the temperature of INSTRUCTIONS the heater. The thermodisc in the fan speed When your installation is completed and inspected circuit ensures that the heater achieves a high you are ready for your first fire. -
Page 10: Maintenance
maintenance CREOSOTE 11)Some cracking and popping noises may be MAINTENANCE experienced during the heating up process. These noises will be minimal when your unit When wood is burned slowly, it produces tar and It is very important to carefully maintain your fire- reaches temperature. -
Page 11: Parts List
parts list PARTS LIST PARTS LIST HEATER ASSEMBLY STOVE ASSEMBLY Part# Description Part# Description 1391000 Firebox Assembly 1390005 Black Left Panel 1391600 Air Slide 1390008 SS Left Panel 1141800 Secondary Air Tube 1390009 Rear Shield Pins (2) 4030214 M6x30 Hex Bolt 1390001 8010108 Brick Set... -
Page 12: Warranty Warranty
WARRANTY warranty Limited Warranty FPI Fireplace Products International Ltd. (“the manufacturer”) through its wholly owned subsidiary, Fireplace Products Australia Pty Ltd (for Australia and New Zealand customers) and sold under the Regency® brand of fireplace products (collectively referred to herein as “FPI”), extends this Limited Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. - Page 13 WARRANTY warranty If after three (3) years the catalytic converter fails to function, a prorated warranty will provide for replacement at the following fee schedule to be paid by the consumer*: Year 4.....$90* Year 5.....$100* Year 6.....$110* * Prices subject to change without notice. Conditions (1) and (2) above also apply for prorated warranty periods. AFTER YEAR SIX (6), THE CONSUMER MUST PURCHASE ANY CATALYTIC CONVERTERS THAT NEED REPLACEMENT AT THE CURRENT RETAIL PRICE, AND WILL BE RESPONSIBLE FOR ANY LABOUR COSTS TO REMOVE AND/OR SERVICE.
- Page 14 WARRANTY warranty The original purchaser is responsible for annual maintenance of the unit, as outlined in the owner’s manual. As outlined below, the warranty may be voided due to problems caused by lack of maintenance. Annual maintenance records should be retained. Exclusions: This Limited Warranty does not extend to paint, rust or corrosion of any kind due to a lack of maintenance or improper venting, combustion air provision, corrosive chemicals (i.e.
- Page 15 WARRANTY warranty Limitations of Liability: 1. Exclusion of implied terms The customer may have the benefit of consumer guarantees under the Australian Consumer Law. To the maximum extent permitted by law, all terms, conditions or warranties that would be implied into this Warranty or in connection with the supply of any goods or services by the supplier under law or statute or custom or international conventions are excluded.
- Page 16 WARRANTY warranty How to Obtain Warranty Service: Customers should contact the authorised selling dealer to obtain warranty service. In the event the authorised selling dealer is unable to provide warranty service, please contact FPI by mail at the address listed below. Please include your name, address, purchase date, selling dealer, serial #, type of unit, a brief description of the problem, email and telephone contact information, and a copy of your original tax invoice.
- Page 17 WARRANTY warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 18 Regency Alterra Freestanding Wood Fire...
- Page 19 Regency Alterra Freestanding Wood Fire...
- Page 20 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ © Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
