INSTALLATION, OPERATING & SERVICING INSTRUCTIONS
Wheeled
Models 450, 451, 452 ( 25 Cu. Ft. Nitrogen Cylinder 16" wheels)
Models 467, 468, 469 (110 Cu. Ft. Nitrogen Cylinder 16" wheels)
Models 470, 471, 472 (110 Cu. Ft. Nitrogen Cylinder 36" wheels)
Stationary
Models 481, 482, 483 ( 23 Cu. Ft. Nitrogen Cylinder)
Models 484, 485, 486 (110 Cu. Ft. Nitrogen Cylinder)
All fire extinguishers should be installed, inspected and maintained in
accordance with the National Fire Protection Association standard titled
"Portable Fire Extinguishers", NFPA-10 and the requirements of local
authorities having jurisdiction.
When maintenance is indicated it should be performed by trained
persons having proper equipment.
vessels and must be treated with respect and handled with care. They
are mechanical devices and require periodic maintenance to be sure that
they are ready to operate properly and safely.
recommends that the maintenance of portable fire extinguishers be done
by a trained professional – your local authorized Amerex Distributor.
Amerex Corporation makes original factory parts available to insure
proper maintenance – USE OF SUBSTITUTE PARTS RELEASES
AMEREX OF ITS WARRANTY OBLIGATIONS.
machined surfaces and threads that are manufactured to exacting
tolerances. O-rings, hoses, nozzles, and all metal parts meet precise
specifications and are subjected to multiple in-house inspections and
tests for acceptability. There are substitute parts available that may be
incorrectly labeled as UL component parts, some are advertised as
Amerex type. None of these meet UL requirements and all of them void
the Amerex extinguisher warranty and UL listing.
SUBSTITUTE.
RECHARGE FIRE EXTINGUISHERS IMMEDIATELY AFTER ANY USE
REFERENCES IN THIS MANUAL:
NFPA-10 Portable Fire Extinguishers
CGA C-1 Methods for Hydrostatic Testing of
Compressed Gas Cylinders
CGA C-6 Standard for Visual Inspection of
Compressed Gas Cylinders
AMEREX CORPORATION – P.O. BOX 81 – TRUSSVILLE, ALABAMA 35173-0081
Phone: 205/655-3271
e-mail:
sales@amerex-fire.com
Printed in U.S.A.
OWNERS SERVICE MANUAL
NO. 05605
Fire extinguishers are pressure
AVAILABLE FROM:
National Fire Protection Association
1 Batterymarch Park, P.O, Box 9101
Quincy, MA 02269-9101
Compressed Gas Association, Inc.
4221 Walney Road, 5
Chantilly, VA 20151-2923
Fax: 800/654-5980
Web Page:
http://www.amerex-fire.com
Amerex strongly
Amerex parts have
DO NOT
th
Floor
0M05605H Rev.10/11
