Amerex 570 Owner's Service Manual

Class-d portable extinguisher
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

DO NOT PRINT THIS PAGE FOR ACTUAL MANUAL. INTERNAL USE ONLY.
PART
NUMBER
MANUAL OWNERS SERVICE B570
08220
#
1
THIS COVERSHEET FOR INFORMATIONAL PURPOSES ONLY - DO NOT PRINT THIS PAGE IN MANUAL.
2
DESCRIPTION: MANUAL OWNER'S SERVICE FOR MODEL B570 PORTABLE EXTINGUISHER
3
ACTUAL PRINTED MATERIAL TO CONSIST OF ATTACHED
4
OVERALL SIZE OF PRINTED DOCUMENT PAGES: 8-1/2" X 11" ON 20 LB PAPER
5
PRINTED MATERIAL TO MATCH ATTACHED IN SADDLE STITCHED BOOKLET FORM
6
PRINT MATERIAL IS TO BE HOLE PUNCHED 3 EACH 1/4" HOLES DOWN LEFT SIDE FOR STD 3-RING BINDER
7
CURENT REVISION DATE: 4/20
REV
G
ADD TO PUBLISHER : GENERAL UPDATES
H
REFRESHED LAYOUT DESIGN; REVISED TITLE
THIS DRAWING IS THE EXCLUSIVE AND CONFIDENTIAL PROPERTY OF
AMEREX CORPORATION. IT SHALL NOT BE DUPLICATED, USED OR
DISCLOSED TO OTHERS WITHOUT THE EXPRESS WRITTEN CONSENT
PN 08220
TITLE
DRAWING CHANGE
DATE CREATED
7-18-98
NOTES
BY
JH
CT
CREATED BY
MS
ECN#
DATE
B000492
10-29-15
B002026
4/30/20
REV.
H
04/2020
