IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturer's recommendations may result in property damage, serious injury, and/
or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understood the safety information
contained in this manual.
1.
Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2.
Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3.
This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including fire.
4.
Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of
the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without
losing eye contact with the roadway.
5.
Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an air bag
deployment area may reduce the effectiveness of the air bag or become a projectile that could cause serious personal injury or death.
Refer to the vehicle owner's manual for the air bag deployment area. It is the responsibility of the user/operator to determine a suitable
mounting location ensuring the safety of all passengers inside the vehicle particularly avoiding areas of potential head impact.
6.
It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),
people, vehicles or other obstructions.
7.
The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.
Never take the right-of-way for granted. It is the vehicle operator's responsibility to be sure they can proceed safely before entering an
intersection, drive against traffic, respond at a high rate of speed, or walk on or around traffic lanes.
8.
This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specifications:
Extreme Voltage: 10-16VDC
Temperature: -40C to 65C
Max Current @
12VDC Nominal (A)
ED3724XX-L
ED3724XX-R
ED3736XX-L
ED3736XX-R
ED3760XX-L
ED3760XX-R
ED3772XX-L
ED3772XX-R
Installation and Operation Instructions
Max Power @
12VDC Nominal (W)
0.5
6.4
0.5
6.4
0.7
9.2
0.7
9.2
1.1
13.8
1.1
13.8
1.3
16.6
1.3
16.6
Outliner Series
Page 1 of 16

Advertisement

loading
Need help?

Need help?

Do you have a question about the Outliner Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ecco Outliner Series

  • Page 1 Installation and Operation Instructions Outliner Series IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user. WARNING! Failure to install or use this product according to manufacturer’s recommendations may result in property damage, serious injury, and/...
  • Page 2 2013-2019 FORD EXPLORER The Running Board lights for the 2013-2019 Ford Explorer fit under the vehicle’s running board and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1. From under the vehicle: Test fit the provided brackets to achieve the location needed for the mounting hole on the vehicle. Mark all four (4) hole positions needed.
  • Page 3 2015-2020 CHEVY TAHOE / 2014-2019 CHEVY SILVERADO The Running Board lights for the 2015-2020 Chevy Tahoe / 2014-2019 Chevy Silverado fit under the vehicle’s running board and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1.
  • Page 4 Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 Figure 6 Page 4 of 16...
  • Page 5 2017 & 2019 DODGE RAM SERIES The Running Board lights for the 2017 & 2019 Dodge Ram Series fit under the vehicle’s rocker panels and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1.
  • Page 6 2020 CHEVY SILVERADO The Running Board lights for the 2020 Chevy Silverado fit under the vehicle’s rocker panels and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1. Mount the brackets to the light unit using the provided screws (See Figure 1). Step 2.
  • Page 7 2015-2020 FORD F-SERIES The Running Board lights for the 2015-2020 Ford F-150 fit under the vehicle’s doors and above the running board (if equipped) and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1.
  • Page 8 2019+ FORD RANGER The Running Board lights for the 2019+ Ford Ranger fit under the vehicle’s doors and above the running board (if equipped) and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1.
  • Page 9 2017 FORD FUSION The Running Board lights for the 2017 Ford Fusion fit under the vehicle’s rocker panels and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1. Mount the brackets to the light unit using the provided screws (See Figure 1). Step 2.
  • Page 10 2016 FORD TAURUS The Running Board lights for the 2016 Ford Taurus fit under the vehicle’s rocker panels and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1. Mount the brackets to the light unit using the provided screws (See Figure 1). Step 2.
  • Page 11 Figure 2 Figure 1 Figure 3 Page 11 of 16...
  • Page 12 2018 DODGE DURANGO The Running Board lights for the 2018 Dodge Durango fit under the vehicle’s rocker panels and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1. Mount the brackets to the light unit using the provided screws (See Figure 1). Step 2.
  • Page 13 2020 FORD EXPLORER The Running Board lights for the 2020 Ford Explorer fit under the vehicle’s rocker panels and provide a lateral facing signal from the side of the vehicle. Installtion and Mounting Instructions: Step 1. Mount the brackets to the light unit using the provided screws. (See Figure 1) Step 2.
  • Page 14: Wiring Instructions

    Wiring Instructions: Red - Positive (12V) Black - Negative White - Steady Secondary Color Override (Cut white wire for all models WITHOUT white lights) Yellow - Synchronized Function Blue - Pattern Select to negative Green - Phase Select to positive(with Synchronized Function activated using yellow wire) Red/White - Dim Control to positive **To be able to run steady secondary color without having red wire activated, a diode will need to be installed according to the diagram.
  • Page 15: Troubleshooting

    Troubleshooting: PROBLEM QESTIONS POSSIBLE CAUSE SOLUTION Module Not Operating a. Bad power/ground connection a. Fix connection b. Defective module b. Replace module Single Function Fix wire connection for the corresponding function Bad connection for that function not working No functions a.
  • Page 16: Warranty

    833 West Diamond St Boise, Idaho 83705 Customer Service USA 800-635-5900 UK +44 (0)113 237 5340 AUS +61 (0)3 63322444 ECCOESG.com An ECCO SAFETY GROUP™ Brand www.eccosafetygroup.com © 2019 ECCO, Inc. all rights reserved. 920-0570-02 Rev. C Page 16 of 16...
