Sony XM-SD22X Marketing Specifications

XM-SD22X
Key Features
1200W max power
200W x 2 RMS into 4 ohms,
20Hz-20kHz @ 0.1% THD
250W x 2 RMS into 2 ohms,
20Hz - 20kHz @ 0.15% THD
500W x 1 RMS into 4 ohms,
20Hz - 20kHz @ 0.15% THD
Variable 50 - 300 Hz low pass
filter
CEA-2006 Power Compliant
1200W max power
200W x 2 RMS into 4 ohms,
20Hz-20kHz @ 0.1% THD
Specifications
Audio
Frequency Response: 5-50k Hz
Input Level: 1.2-12V (Speaker level
input)
Power
Power Consumption (in
Operation): 1200 Watts
Output Power: Bridged into 4 ohms,
THD%- 500, 0.15%
Current Drain: 48A
Dimensions
Weight: 11 lbs, 1 oz (5 Kg)
Measurements: 11 x 2 1/4 x 15
7/8" (279 x 57 x 403mm)
UPC Code: 027242664784
250W x 2 RMS into 2 ohms,
20Hz - 20kHz @ 0.15% THD
500W x 1 RMS into 4 ohms,
20Hz - 20kHz @ 0.15% THD
Variable 50 - 300 Hz low pass
filter
40 Hz EQ boost
MOSFET output stage &
power supply
RCA & speaker level inputs
Line level thru-put
CEA-2006 Power Compliant
2-Year limited warranty
Amplifier
