ULTRALINK UL2000M
In this chapter, different control elements of your ULR2000 will be described, explained in detail, and
you will get useful information on how to use them.
POWER
To power the ULR2000 on or off, keep the POWER button pressed for at least 2 seconds. To disconnect
the unit from the mains, please unplug the power supply. Make sure the wall power supply is easily
accessible whenever you use the ULR2000. If you mount it in a rack, make sure that you can easily
unplug the wall power supply or an all-pole disconnect switch.
Please keep in mind: The POWER switch does not entirely separate the unit from the mains.
Please disconnect the power cord from the mains if you won
VOLUME
The output signal level of the receiver can be set using the VOLUME control. If you run the ULR2000
in a setup with balanced connections, a maximum signal level of 12.5 dBu is possible; in setups with
unbalanced connections, the maximum signal level is 6.5 dBu.
We would like to point out that high volume levels may cause distortion and high signal
levels in other equipment to which your ULR2000 is connected (e.g. mixing console or
headphones). High volume levels may damage your hearing and/or your headphones/
speakers. Please turn the VOLUME control all the way to the left (very low output signal)
before turning the ULR2000 on. Always make sure that an appropriate volume is set.
DISPLAY
All important parameters are shown in the display (ch. 2.1.2).
SET
The SET button has 2 functions:
Press this button to bring up the menu.
To confirm the values you set in the menu, press the SET button.
UP and DOWN
These two buttons let you navigate the menu and change the values shown in the display (e.g. frequency,
channel number, preset number).
If the ULR2000 is in the basic setting (menu not selected), pressing the
buttons changes the transmission channel within the selected preset.
The UP and
is carried out perpetually if the button is kept pressed; for example, setting a carrier frequency
can be simplified this way).
6

2. ULR2000 RECEIVER

2.1 Control elements and connections

2.1.1 The front

Fig. 2.1: ULR2000
DOWN buttons have a repeat functionality with many function (i.e. the action
2. ULR2000 RECEIVER
's front side
'
t be using the unit for a while.
UP and the DOWN
