Sony XM-GTX1302 Marketing Specifications

2/1 channel gtx amp
Hide thumbs

Advertisement

Quick Links

XM-GTX1302
2/1 channel GTX amp
1
130 Watts x 2 RMS (20Hz-20kHz, <1%THD+N, at 4 Ohm, 14.4V)
Maximum power output of 280 Watts per channel at 4 Ohm.
170 Watts x 2 RMS (20Hz-20kHz, <1%THD+N, at 2 Ohm, 14.4V)
Maximum power output of 400 Watts per channel at 2 Ohm.
340 Watts x 1 RMS (20Hz-20kHz, <1%THD+N, at 4 Ohm mono, 14.4V)
This unit can be used as a bridging amplifier with a maximum
output of 800 Watts at 4 Ohms.
Direct connection (High Level Input) can be made with the speaker
output of your car audio unit if it is not equipped with RCA line output.
Hi-Level Sensing power On feature allows the unit to be activated
without need for remote connection.
Built in 80Hz 18 dB/Oct LPF (Low Pass Filter) enables users to
concentrate the power on lower frequencies.
Built in 80Hz 12 dB/Oct HPF (Hi-Pass Filter) enables users to block low
frequencies to improve the audio systems efficiency.
Variable 0-10 dB 40Hz bass boost provides additional bass
response at lower frequencies.

Advertisement

loading

  Related Manuals for Sony XM-GTX1302 Marketing

  Summary of Contents for Sony XM-GTX1302 Marketing

  • Page 1 XM-GTX1302 2/1 channel GTX amp 130 Watts x 2 RMS (20Hz-20kHz, <1%THD+N, at 4 Ohm, 14.4V) Maximum power output of 280 Watts per channel at 4 Ohm. 170 Watts x 2 RMS (20Hz-20kHz, <1%THD+N, at 2 Ohm, 14.4V) Maximum power output of 400 Watts per channel at 2 Ohm. 340 Watts x 1 RMS (20Hz-20kHz, <1%THD+N, at 4 Ohm mono, 14.4V) This unit can be used as a bridging amplifier with a maximum output of 800 Watts at 4 Ohms.
  • Page 2: Specifications

    Harmonic Distortion (THD) plus noise, at a frequency range (for general purpose amplifiers) of 20 Hz to 20,000 Hz. © 2010 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, Quick-BrowZer, Walkman, Xpl ōd, ZAPPIN, and the Sony and Xplōd logos are trademarks of Sony.
