NetVanta ADSL Network Interface Module (ADSL over ISDN) P/N 1200889E1/L1
Quick Start Guide
ADSL NIM C
OMMANDS
retrain
Forces the modem to retrain.
snr-margin [showtime monitor l training monitor] <margin>
Enables monitoring and sets the minimum signal-to-noise (SNR) ratio
during training and showtime. Use the no form of this command to
disable monitoring.
showtime monitor Enables margin monitoring to retrain the ADSL
interface if the specified minimum margin is
violated during showtime.
training monitor Enables margin monitoring to retrain the ADSL
interface if the specified minimum margin is
violated during training.
<margin> Sets the minimum SNR margin in dB. Range is
1 to 15.
training-mode [G.DMT | G.LITE | Multi-Mode | T1.413 | ADSL |
ADSL2+ | READSL2]
Configures the ADSL training mode. This setting must match the service
provider's DSLAM.
G.DMT Specifies ANSI full-rate mode. This is the only
training mode valid on the ADSL Annex B.
ATM C
OMMANDS
snmp trap link-status
Controls the Simple Network Management Protocol (SNMP) variable
ifLinkUpDownTrapEnable (RFC2863) to enable (or disable) the interface
to send SNMP traps when there is an interface status change. Use the
no form of this command to disable this trap.
See the AOS Command Reference Guide on the
ADTRAN OS System Documentation CD for a
complete list of ATM commands.
Quick Start Guide, 61200889E1-13D, July 2006
For more detailed documentation, visit us online at www.adtran.com.
ATM S
UB
access-policy <policyname>
Assigns a specified access policy for the inbound traffic on an interface.
Use the no form of this command to remove an access policy association.
<policyname>
dynamic-dns [dyndns | dyndns-custom | dyndns-static] <hostname>
<username> <password>
Configures Dynamic DNS service provided by Dynamic Network Services,
Inc. (www.dyndns.org).
dyndns
dyndns-custom
dyndns-static
encapsulation [aal5mux | aal5snap]
Configures the encapsulation type for the ATM Adaption Layer (AAL) of the
ATM Protocol Reference Model.
aal5mux
aal5snap
oam-pvc managed <frequency>
Enables end-to-end F5 Operation, Administration, and Maintenance (OAM)
loopback cell generation and OAM management for an ATM interface. Use
the no form of this command to disable generation of OAM loopback cells.
<frequency>
oam retry <up-count> <down-count> <retry-frequency>
Configures parameters related to OAM management for an ATM interface.
Use the no form of this command to disable OAM management
parameters.
<up-count>
<down-count>
<retry-frequency>
ADTRAN Technical Support +1-256-963-8716
-I C
NTERFACE OMMANDS
Identifies the configured access policy using an
alphanumeric descriptor (all access policy descriptors
are case-sensitive).
Allows you to alias a dynamic IP address to a static
hostname in various domains. This service is provided
for up to five hostnames.
Gives complete control over an entire domain name. A
web-based interface provides two levels of control
(basic or advanced) over the domain. Can be used
with both static and dynamic IPs.
Allows a hostname such as yourname.dyndns.org to
point to your IP address. This service is provided for
up to five hostnames.
Specifies encapsulation type for multiplexed virtual
circuits. A protocol must be specified.
Specifies encapsulation type that supports LLC/SNAP
protocols.
Specifies the time delay between transmitting OAM
loopback cells. Range is 0 to 600 seconds.
Specifies number of consecutive end-to-end F5 OAM
loopback cell responses that must be received in order
to change a PVC connection state to up. Range is
1 to 255.
Specifies number of consecutive end-to-end F5 OAM
loopback cell responses that are not received in order
to change a PVC state to down. Range is 1 to 255.
Specifies frequency (in seconds) that end-to-end F5
OAM loopback cells are transmitted when a change in
the up/down state of a PVC is being verified. Range is
1 to 600.
