Garmin GC 14 Installation Instructions

Getting Started
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
Mounting Considerations
You can mount the camera upside-down or sideways. You can reverse the camera image to use in rearview
mode. See your chartplotter owner's manual for instructions.
You should mount the camera in a location where it is
• not an obstacle in doorways or walkways.
• not exposed to extreme temperatures.
• not exposed to gas or oil.
• not exposed to radioactivity.
• not facing into direct sunlight or a direct reflection of sunlight.
Tools Needed
• 1 A fuse or circuit breaker
3
• Drill and 2 mm ( / in.) drill bit
32
Mounting the Camera
1 Secure the template
3
2 Using a 2 mm ( / in.) drill bit, drill the pilot holes.
32
3 Adjust the dome base
4 Secure the dome base to the mounting location using the included tapping screws
5 Insert the camera
6 Secure the set screws
April 2021
INSTALLATION INSTRUCTIONS
to the mounting location.
to the correct orientation for your desired camera tilt.
into the dome base.
into the dome front
GC 14
™
WARNING
using the included wrench.
GUID-F3AB61D3-A701-4DF6-A841-B96657F5BE46 v3
.
