Maximum Controls MAX Quick Installation Manual page 5

MAX CELL HUB
MAX CELL HUB
5V
(-)
5
Select "Access PT#" using rotary switch
Select #1-14: to open gate using
Keypad relay
CELL
LINK
POWER
ONLINE
COMM
LINK
CELL
LINK
POWER
RS485
(-) (+) GND
RS485
(-) (+) GND
5V
GND
(-) (+)
(+)
PEDESTRIAN DOOR APPLICATION
SOLENOID LOCK
Gnd
GND
(-)
(+)
NO
COM
NO
RTE
GND
3
Wiring Solenoid Lock
Install Solenoid Lock
as shown below
S
E S
P R
I T
E X
t o
EXIT PUSH BUTTON
4
Wiring Exit Push Button
Install request to Exit
Push Button as shown
12-10-20 _Rev 2.7
