QUICK INSTALLATION GUIDE
MAX APP BASED KEYPAD
RESIDENTIAL / COMMERCIAL APPLICATION
Max Cloud App
Welcome to Maximum
Controls
Key Features
App Based Trackable Keypad
Affordable cell data plans (AT&T or Verizon)
16 Zone Control using Wiegand Converters
WIELAND CONVERTER
15 Wireless zone control (1 mile range / 900 MHz)
(with wireless Wiegand Converters)
Push Notification for "Call" button pressed
or Visitor Motion Detected
COMING SOON
CALL
Guest Pass with date and time restriction
Event Log of all transactions
APP BASED KEYPAD
MAX.US.COM
04-18-24 _Rev 1.2
www.max.us.com
Advertisement
Table of Contents
Related Manuals for Maximum Controls MAX APP BASED KEYPAD
Summary of Contents for Maximum Controls MAX APP BASED KEYPAD
- Page 1 QUICK INSTALLATION GUIDE MAX APP BASED KEYPAD RESIDENTIAL / COMMERCIAL APPLICATION Max Cloud App Welcome to Maximum Controls Key Features App Based Trackable Keypad Affordable cell data plans (AT&T or Verizon) 16 Zone Control using Wiegand Converters WIELAND CONVERTER 15 Wireless zone control (1 mile range / 900 MHz) (with wireless Wiegand Converters) Push Notification for “Call”...
-
Page 2: Table Of Contents
TABLE OF CONTENT www.max.us.com www.max.us.com Max Keypad Overview Entry gate application Pedestrian door application Setting up Max Cloud App Setup a new gate site with App Program Keypad greetings message Program Keypad call button message Add a new user on App Program keycodes with restrictive times Program timers Cell date activation setup... - Page 3 MAX APP BASED KEYPAD OVERVIEW www.max.us.com www.max.us.com DOME ANTENNA Vandal proof ENCLOSURE Tamper resistant zinc die-cast front door KEY LOCK Vandal proof LCD DISPLAY Welcome to Maximum Sunlight readable display (for Controls greeting, help and other messages) SPEAKERS SIDE LEDs...
-
Page 4: Entry Gate Application
ENTRY GATE APPLICATION ENTRY GATE USING APP BASED KEYPAD Welcome to Maximum Controls BASED KEYPAD CALL Wiring Transponder Device Install transponder device as shown Transponder Wiegand Receiver +12V Wiring Power Input Connect 12VDC, APP BASED KEYPAD 1A power transformer to Power Input port of Max Keypad... -
Page 5: Pedestrian Door Application
PEDESTRIAN DOOR APPLICATION www.max.us.com Wiring Solenoid Lock www.max.us.com Install Solenoid Lock SOLENOID LOCK as shown below EXIT PUSH BUTTON Wiring Exit Push Button Install request to Exit Push Button as shown Select "Realy Strike TIme" using rotary switch Select #2s-30s: to open gate using Relay Strike... - Page 6 PEDESTRIAN DOOR APPLICATION PEDESTRIAN DOOR www.max.us.com www.max.us.com Welcome to Maximum Controls CALL Welcome to Maximum Controls CALL Based Keypad Wiring Power Input Connect 12VDC, 1A power transformer CARD to Power Input port READER of Max Keypad (polarity does NOT matter) +12V APP BASED KEYPAD Verify POWER...
-
Page 7: Setting Up Max Cloud App
SETTING UP MAX CLOUD APP www.max.us.com www.max.us.com SCAN QR CODES “MAX Cloud App” TO DOWNLOAD Getting Max Cloud App Max Cloud App is available for download on: How to install Max Cloud App on android phones 4. Confirm the 2. Type Max installation Cloud App in Max Cloud App... - Page 8 Enter the IMEI# of the App Based Keypad Please double check your entry to ensure cell connectivity IMEI# is located on the inside of Max App Based Keypad Set up ADMIN for the gate site Add the name and cell # of the person who will...
- Page 9 PROGRAM KEYPAD GREETING & CALL BUTTON www.max.us.com www.max.us.com Press Settings icon in the main menu Setup greeting message Go to the GREETING area and type the message you want to display for your visitors. Limited to 32 characters. Welcome to Dana Golf Courses Greeting Welcome to Dana Golf Courses...
-
Page 10: Program Keypad Call Button Message
PROGRAM CALL BUTTON MESSAGE www.max.us.com www.max.us.com Setup Call Button Go to the Call Button area and type the message that may instruct the visitor to call a specific phone number (i.e. facility manager or home owner) using their personal cell phone. Example CALL button message: “CALL (949) 000-0000 on your phone”... -
Page 11: Add A New User On App
ADD A USER ON APP www.max.us.com www.max.us.com www.max.us.com www.max.us.com Press Users icon in the main menu Then Press Add a User in the following menu User Name Enter Name of your visitor, Rose then assign a 5 digit keycode Keycode 26709 Program Wiegand Keycode Facility... - Page 12 PROGRAM KEYCODES WITH RESTRICTIVE TIME ZONES www.max.us.com www.max.us.com Assign a timer (OPTIONAL) Choose one of six timer schedules Timer These time restrictions apply to both keycode and Wiegand keycode If you choose No Timer Keycode has no time restriction Press the back button [<] on the top left of the screen to confirm create a user SCAN CODE Watch video...
-
Page 13: Program Timers
PROGRAM TIMERS www.max.us.com www.max.us.com Press Timers icon in the main menu Choose the Timer option Choose the Timer option you want to setup from the you want to setup from the list of timers list of timers... -
Page 14: Cell Date Activation Setup
Please have in hand the SIM Card (AT&T or Verizon) provided with Max App Based Keypad and IMEI# Please double check your entry to ensure cell connectivity IMEI# is located on the inside... - Page 15 Setting up account information a.- Under Marketplace subscription plans choose as a provider Maximum Controls b.- Choose a subscription Plan c.- Follow instructions on the site to complete set up your account information and submit Enter your login info Will take you to our secure portal https://www.iotactivate.com,...
- Page 16 www.max.us.com www.max.us.com Activate SIM card My Services and a.- Go to Equipment and click over the plan and provider you want to connect b.- Go to Activate a new subscription c.- Enter the ICCID information located on the back of the SIM Card provided Please double check d.- Enter the IMEI# that is ocated...
- Page 17 www.max.us.com www.max.us.com...
-
Page 18: App Based Keypad
QUICK INSTALLATION GUIDE MAX APP BASED KEYPAD RESIDENTIAL / COMMERCIAL APPLICATION APP BASED KEYPAD RADIO RFID RECEIVER TRANSPONDER Welcome to Maximum Controls CARD MAX CLOUD APP READER CALL MAX WIEGAND CONVERTER MAX WIEGAND CONVERTER MAX KEYPAD Access Point # 3...
