Maximum Controls MAX Quick Installation Manual page 12

RESIDENTIAL / COMMERCIAL APPLICATION
INTEGRATED ACCESS CONTROL INTEGRATED ACCESS CONTROL
RADIO
RECEIVER
Max Wiegand Converter
Access Point # 3
• Wiegand Keycodes with optional time zone restrictions
• Keypad Keycodes with optional time zone restrictions
• Virtual Transmitters (App Users) with optional time restrictions
• Guest Passes with date and time restrictions
• Auto Open / Close Timer to set daily recurring schedule for gate operator
• Text Alerts on App for gate status, gate tamper and sensor fail events
• EVENT LOG to track gate site events on App. Events tracked includes:
- Max Cloud App OPEN commands
- Guest Pass OPEN commands
- Keypad keycode entries
- Wiegand keycodes scans
- All programming changes
• ERROR LOG to monitor and diagnose gate operator issues remotely
(949) 699-0220
QUICK INSTALLATION GUIDE
MAX KEYPAD
CARD
READER
Max Keypad
Access Point # 2
Max Hub can support up to 16 access points
using Max Keypads and/or Max Wiegand Converter Units
www.max.us.com
10530 Lawson River Ave., Fountain Valley, CA 92708
| maxsales.us@gmail.com
RFID
Transponder
Max Keypad
RS485 COMM LINK
Access Point # 1
| MAX.US.COM
ONLINE
COMM
LINK
CELL
Max Cell Hub
LINK
POWER
MAX CELL HUB
RS485
(-) (+) GND
5V
12-07-20 _Rev 2.6
